HP Pavilion 5219CRF Manuale di istruzioni

Filename: 5219urf 2+ users guide US_ Title: hp pavilion home pc

Template:Normal.dot Author:pamela LastSavedBy:Authur

Revision #: 3 Page: 1 of 12 Printed: 09/01/04 07:19 PM

hp pavilion home pc

5219CRF Installing the Wireless Keyboard and Mouse

Filename: 5219urf 2+ users guide US_ Title: hp pavilion home pc

Template:Normal.dot Author:pamela LastSavedBy:Authur

Revision #: 3 Page: 2 of 12 Printed: 09/01/04 07:19 PM

HP Pavilion home PC 1

Filename: 5219urf 2+ users guide US_ Title: hp pavilion home pc

Template:Normal.dot Author:pamela LastSavedBy:Authur

Revision #: 3 Page: 1 of 12 Printed: 09/01/04 07:19 PM

Installing the Wireless

Keyboard and Mouse Set

The wireless keyboard and mouse set

consists of a receiver (A) that plugs into the

computer, a wireless keyboard (B), and a

wireless mouse (C).

Note: This wireless set is compatible with your

HP Pavilion home PC and not intended

for use with other computers.

Note: You can replace the batteries in the mouse

and keyboard without turning off the

computer. The computer must be on to

change the ID setting on the three units.

2HP Pavilion home PC

Filename: 5219urf 2+ users guide US_ Title: hp pavilion home pc

Template:Normal.dot Author:pamela LastSavedBy:Authur

Revision #: 3 Page: 2 of 12 Printed: 09/01/04 07:19 PM

Getting the Mouse Ready

Note: Do not use rechargeable batteries in the

mouse. Alkaline batteries are recommended.

Install the two AA alkaline batteries

(provided) in the wireless mouse: Turn on

the battery cover from the bottom of the

mouse, and then insert the batteries into the

compartment. Note the battery icons, and

make sure batteries are placed in the

correct direction. Replace the cover.

Note: The red LED turns on indicating the batteries

are installed correctly.

HP Pavilion home PC 3

Filename: 5219urf 2+ users guide US_ Title: hp pavilion home pc

Template:Normal.dot Author:pamela LastSavedBy:Authur

Revision #: 3 Page: 3 of 12 Printed: 09/01/04 07:19 PM

Getting the Keyboard Ready

Note: Do not use rechargeable batteries in the

keyboard. Alkaline batteries are recommended.

1Install the two AA alkaline batteries

(provided) in the wireless keyboard: Remove

the cover (G) from the bottom of the

keyboard, and insert the batteries into the

compartment (H). Note the battery icons,

and make sure batteries are placed in the

correct direction. Replace the cover.

2Adjust the keyboard height by lifting the

adjustment bar (JI).

4HP Pavilion home PC

Filename: 5219urf 2+ users guide US_ Title: hp pavilion home pc

Template:Normal.dot Author:pamela LastSavedBy:Authur

Revision #: 3 Page: 4 of 12 Printed: 09/01/04 07:19 PM

Getting the Receiver Ready

The receiver (A) must be placed upright and

positioned properly to avoid interference

from other electrical equipment.

1Turn off your computer, and disconnect the

power cord and modem/phone cable.

2Connect the receiver cable (L) to the USB

connector on the back of the computer.

HP Pavilion home PC 5

Filename: 5219urf 2+ users guide US_ Title: hp pavilion home pc

Template:Normal.dot Author:pamela LastSavedBy:Authur

Revision #: 3 Page: 5 of 12 Printed: 09/01/04 07:19 PM

3Set the receiver upright and follow these

guidelines.

nA: Minimum 20 cm (8 inches) clearance

between the receiver and other

electronic devices.

nB: Maximum 1.5 m (59 inches) working

distance between the receiver and

wireless mouse or wireless keyboard.

6HP Pavilion home PC

Filename: 5219urf 2+ users guide US_ Title: hp pavilion home pc

Template:Normal.dot Author:pamela LastSavedBy:Authur

Revision #: 3 Page: 6 of 12 Printed: 09/01/04 07:19 PM

nC: Minimum 20 cm (8 inches) clearance between the receiver and the monitor.

nPlace no electronic device between the receiver and wireless mouse or wireless keyboard.

Note: This is one example of the setup. Other setup positions are also possible.

Warning: To avoid causing interference, keep the receiver at least 20 cm (8 inches) away from the

monitor.

HP Pavilion home PC 7

Filename: 5219urf 2+ users guide US_ Title: hp pavilion home pc

Template:Normal.dot Author:pamela LastSavedBy:Authur

Revision #: 3 Page: 7 of 12 Printed: 09/01/04 07:19 PM

Setting Up the Wireless Set

The mouse and keyboard have 255 IDs that

are randomly selected when you press the

ID button. This helps protect against

interference from other wireless devices in

the same area.

Important: The word CONNECT labels the ID button

on the bottom of each unit. To press the ID

button, use a blunt pointed object, like the tip

of a ball point pen.

1 Connect the power cord and

modem/telephone cable to the

computer. Turn on the computer.

Receiver

2 On the bottom of the receiver, press the

ID button (D) once with a blunt pointed

object.

The top activity LED (N, a blue light) on the

receiver will start flashing and will continue

flashing until the next step are completed

or until 30 seconds pass.

Important: If 30 seconds pass before you complete

steps 3, you must repeat steps 2, 3 to set the

IDs.

8HP Pavilion home PC

Filename: 5219urf 2+ users guide US_ Title: hp pavilion home pc

Template:Normal.dot Author:pamela LastSavedBy:Authur

Revision #: 3 Page: 8 of 12 Printed: 09/01/04 07:19 PM

Mouse

3 On the bottom of the mouse, press the

ID button once with a blunt pointed

object.

The mouse sends a new ID and flashes the

mouse sensor LED three times. The

receiver flashes the blue top activity LED

(N) three times and then stops to show it

has accepted the new ID for the mouse.

Note: At this time, when you move the mouse across

a surface, the blue activity LED (N) on the

receiver will go on and off indicating the

mouse and the receiver are working together.

Important: The mouse goes into a sleep or suspend

mode after 20 minutes of inactivity. Click a

button on the mouse to wake it. (Moving the

mouse does not wake it.)
