HP StorageWorks 8B - FC Entry Switch Manuale utente

user's guide

version 3.0

quickloop

www.hp.com

Notice

Edition: E1201

Hewlett-Packard Company makes no warranty of any kind with

regard to this material, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

This document contains proprietary information, which is protected

by copyright. No part of this document may be photocopied,

reproduced, or translated into another language without the prior

written consent of Hewlett-Packard. The information contained in

this document is subject to change without notice.

Use, duplication, or disclosure by government is subject to

restrictions as set forth in subdivision (c) (1) (ii) of the Rights in

Technical Data and Computer Software Clause at DFARS

252.227.7013.

Warranty

If you have any questions about the warranty for this product,

contact your dealer or local Hewlett-Packard sales representative.

Trademarks

BROCADE, the Brocade B weave logo, Brocade: the Intelligent

Platform for Networking Storage, SilkWorm, and SilkWorm

Express, are trademarks or registered trademarks of Brocade

Communications Systems, Inc. or its subsidiaries in the United

States and/or in other countries.

All other brands, product or service namesare or may be trademarks

or service marks of, and are used to identify products of services of

their respective owners.

Safety notices

Any servicing, adjustment, maintenance, or repair must be

performed only by authorized service-trained personnel.

QuickLoop User’s Guide iii

Contents

Preface

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v

Related Publications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v

System Requirements and Compatibility. . . . . . . . . . . . . . . . . . . . . . . . vii

Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Getting Software Updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Chapter 1 Introducing QuickLoop

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

QuickLoop Basics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Address Translation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Combining QuickLoop and Zoning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Chapter 2 Using QuickLoop

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Administering QuickLoop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Web Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Telnet Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

QuickLoop Topology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

QuickLoop Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Dual-switch QuickLoop . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

QuickLoop Initialization. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

iv QuickLoop User’s Guide

Sample Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Configuration 1: Emulating a Hub . . . . . . . . . . . . . . . . . . . . 2-7

Configuration 2: Dual-switch QuickLoop . . . . . . . . . . . . . . 2-8

Configuration 3: Long Wave Laser Connection. . . . . . . . . . 2-9

Configuration 4: Mixed QuickLoop Mode and Fabric Mode 2-10

Error Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11

Switch Level Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11

Port Level Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11

Glossary

Index

QuickLoop User’s Guide v

Preface

Zoning is a standard feature on the HP Surestore FC 1Gb/2Gb Switch 8B and FC 1Gb/2Gb Switch

16B products. It is also available on the HP Surestore FC 1Gb/2Gb Entry Switch 8B if the Zoning

license is installed. QuickLoop is a standard feature on the HP Surestore FC 1Gb/2Gb Entry Switch

8B, FC 1Gb/2Gb Switch 8B, and FC 1Gb/2Gb Switch 16B products. QuickLoop and Zoning are

supported on switches running Fabric OS version 3.0.1b or later.

About This Guide

This guide provides the following information about the QuickLoop features:

Related Publications

Related product information can be found in the following publications.

Provided with the FC Entry Switch 8B and FC Switch 8B:

•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Getting Started

Guide (A7346-90902)

•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Documentation

CD (A7346-11001)

Chapter 1

Introducing QuickLoop Provides an overview of QuickLoop.

Chapter 2

Using QuickLoop Provides information about configuring and using

QuickLoop.

vi QuickLoop User’s Guide

Provided on the FC Entry Switch 8B and FC Switch 8B Documentation CD, and at the HP Web site

at http://www.hp.com/support/fc8B:

•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Getting Started

Guide (A7346-90902)

•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Installation and

Reference Guide

•Fabric OS Reference Manual, version 3.0

•Fabric OS Procedures Guide, version 3.0

•Fabric OS Version 3.0.1b Release Notes

•Fabric Watch User’s Guide, version 3.0

•QuickLoop User’s Guide, version 3.0

•Web Tools User’s Guide, version 3.0

•Distributed Fabrics User’s Guide, version 3.0

•Zoning User’s Guide, version 3.0

•MIB Reference Manual, version 3.0

•ISL Trunking User’s Guide, version 3.0

•Advanced Performance Monitoring User’s Guide, version 3.0

•Merging Heterogeneous Fabrics Instructions

Provided with the FC 16B:

•HP Surestore FC 1Gb/2Gb Switch 16B Quick Start Guide (A7340-96002)

•HP Surestore FC 1Gb/2Gb Switch 16B Documentation CD (A7340-11001)

Provided on the FC 1Gb/2Gb Switch 16B Documentation CD and at the HP Web site at

http://www.hp.com/support/fc16B:

•HP Surestore FC 1Gb/2Gb Switch 16B Quick Start Guide (A7340-96002)

•HP Surestore FC 1Gb/2Gb Switch 16B Installation and Reference Guide

•Fabric OS Reference Manual, version 3.0

•Fabric OS Procedures Guide, version 3.0

•Fabric OS Version 3.0.1 Release Notes

•Fabric Watch User’s Guide, version 3.0

•QuickLoop User’s Guide, version 3.0

•Web Tools User’s Guide, version 3.0

•Distributed Fabrics User’s Guide, version 3.0

•Zoning User’s Guide, version 3.0

•MIB Reference Manual, version 3.0

•ISL Trunking User’s Guide, version 3.0

•Advanced Performance Monitoring User’s Guide, version 3.0

•Merging Heterogeneous Fabrics Instructions

Information about Fibre Channel standards and Fibre Channel in general can be found on the Fibre

Channel Industry Association Web site, located at http://www.fibrechannel.com.

QuickLoop User’s Guide vii

System Requirements and Compatibility

Compatibility with other Products

Fabric OS version 3.0.1b or later can be installed and run on the FC Entry Switch 8B, FC Switch

8B, and FC 16B products.

The FC Entry Switch 8B, FC Switch 8B, and the FC 16B switch running Fabric OS version 3.0.1b

or later can operate in the same fabric with the HP Brocade 2400/2800 and FC 6164 switches

running the a2.4.1 or later versions of Fabric OS.

For more information about configuring FC Entry Switch 8B, FC Switch 8B, FC 16B, HP Brocade

2400/2800, and FC 6164 products to operate in the same fabric, contact your switch supplier.

Getting Help

For information for the FC Entry Switch 8B and FC Switch 8B, visit the HP Web site at

http://www.hp.com/support/fc8B.For the most current technical support information for the FC

16B, visit the HP Web site at http://www.hp.com/support/fc16B. This includes hardware and

software support, all repairs, and spare components.

Be prepared to provide the following information to the support personnel:

•Switch serial number

•Switch world wide name

•Output from the supportShow telnet command

•Detailed description of the problem

•Topology configuration

•Troubleshooting steps already performed

Getting Software Updates

For information on obtaining software updates contact your HP account representative or technical

support.

viii QuickLoop User’s Guide

QuickLoop User’s Guide 1-1

Chapter

Introducing QuickLoop

This chapter provides the following information:

•Overview on page 1-1

•QuickLoop Basics on page 1-1

•Address Translation on page 1-2

•Combining QuickLoop and Zoning on page 1-2

Overview

QuickLoop allows arbitrated loops to be attached to a fabric. Without modifying their drivers,

private target on the arbitrated loops can be accessed by public or private hosts elsewhere on the

fabric.

Devices attached to QuickLoop communicate with all other devices attached to the same

QuickLoop. However, private devices attached to QuickLoop communicate only with devices

within the same QuickLoop. Public devices in an arbitrated loop mode are considered private

devices when connected to QuickLoop ports.

Zoning enables the set of storage devices visible to specific hosts can be carefully administered.

The QuickLoop and Zoning combination allows a private host to fully participate in a Storage Area

Network (SAN).

QuickLoop Basics

QuickLoop is a unique Fibre Channel topology that combines arbitrated loop and fabric topologies.

An arbitrated loop supports communication between devices that are not fabric-aware. Such

devices are called private devices, and arbitrated loops are sometimes called private loops.

QuickLoop allows an FC Entry Switch 8B, FC Switch 8B, or FC 16B switch to emulate a hub

environment, while offering the additional benefit of connectivity to a fabric.

A QuickLoop consists of multiple private arbitrated looplets (a set of devices connected to a single

port) that are connected by a fabric. All devices in a QuickLoop share a single AL_PA bit-map and

behave as if they are in one loop. This allows private devices to communicate with other devices

over the fabric, provided they are in the same QuickLoop.

A particular QuickLoop can be configured to consist of selected devices or looplets connected to

the ports of one switch, or to a cascaded switch pair.

1-2 QuickLoop User’s Guide

Introducing QuickLoop

QuickLoop provides a possible migration path starting with deploying a single private loop and

later deploying a fabric-based SAN. In this scenario, QuickLoop-enabled switches can be used to

replace hubs when the SAN is first deployed and has only private devices attached. Then, as the

SAN grows, fabric switches can be added without any detrimental effect to the QuickLoop-enabled

switches.

Address Translation

Address translation is transparent and requires no actions on the part of the user. It is achieved

through hardware translative mode (also known as phantom mode), in which a device not

physically located in a looplet is made addressable by a unique AL_PA in that looplet.

There are two hardware translative modes available to a QuickLoop-enabled switch:

•Standard translative mode

Allows public hosts to communicate with private target devices across the fabric. Standard

translative mode is available as an integral part of Fabric OS, and does not require QuickLoop.

•QuickLoop mode

Allows private hosts to communicate with private target devices across the fabric when

configured in the same QuickLoop. Also allows private host to communicate with public target

in the same QuickLoop.

In mixed mode individual ports within a switch are set by configuration commands to one of the

above two modes.

The switch automatically determines and sets the appropriate mode, based on factory defaults and

configurations currently in effect.

Combining QuickLoop and Zoning

QuickLoop can be used in conjunction with Zoning.

In addition to zoning fabrics, QuickLoop Zoning also allows you to zone QuickLoops, enhancing

management of a Fibre Channel Arbitrated Loop (FC-AL) in a legacy environment.

In QuickLoop Zoning, devices within a QuickLoop can be partitioned off within that QuickLoop to

form QuickLoop zones; in other words, a QuickLoop zone is a subset of QuickLoop and can

include only devices in QuickLoop.

Fabric zones and QuickLoop zones are independent of each other; both types of zones can co-exist

in the same zone configuration. Hosts in a QuickLoop can see only targets contained within a

QuickLoop.

Zoning adds the following features:

•Devices from multiple QuickLoops can be added to the definition for a fabric zone.

Even an identical AL_PA from two different QuickLoops could be configured under a fabric

zone. Zoning can correctly direct traffic to the different devices.

•Additional control over access to QuickLoop devices.

Fabric devices in a zoned fabric can only access the QuickLoop (and fabric) devices that are in

the same zone.

Altri manuali per StorageWorks 8B - FC Entry Switch

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali HP Magazzinaggio

HP Surestore 64 - Director Switch Manuale utente

HP StorageWorks DAT320 USB Manuale di istruzioni

HP Compaq Presario,Presario 4400 Guida

HP StorageWorks XP1024 Manuale utente

HP P2000 G3 Guida di riferimento rapido

HP STORAGEWORKS ALL-IN-ONE STORAGE SYSTEM Manuale utente

HP mv2040 Manuale utente

HP StorageWorks XP10000 - Disk Array Manuale utente

HP StorageWorks P4000 Series Manuale utente

HP StorageWorks 4000/6000/8000 - Enterprise Virtual... Manuale di istruzioni

HP SSD Manuale utente

HP 330834-B21 - StorageWorks Ultrium 460 Tape Library Drive... Manuale del prodotto

HP HP 7936 Istruzioni per l'installazione

HP StorageWorks P4000 Series Manuale utente

HP C4405A - Colorado 14GB Tape Drive Manuale utente

HP 9130K Manuale utente

HP LTO-4 FH Manuale utente

HP StoreOnce 2700 Manuale dell'operatore

HP P6080-63001 - Maxtor DiamondMax Plus 40 GB Hard... Manuale utente

HP 624192-B21 Istruzioni utente

HP D2220sb Manuale utente

HP 330834-B21 - StorageWorks Ultrium 460 Tape Library Drive... Manuale utente

HP LTO-4 Ultrium 1760 Manuale del prodotto

HP Surestore 6164 - Switch Manuale utente

Manuali Magazzinaggio popolari di altre marche

QNAP

QNAP TS 32PXU Series Manuale utente

LaCie

LaCie RUGGED RAID Manuale utente

Freecom

Freecom CLS DOCK Manuale utente

PNY

PNY Attache P-FD64MBATT3 Manuale utente

OLT

OLT 6x6 Maximizer Manuale utente

Transcend

Transcend JetFlash 160 Manuale utente

LaCie

LaCie RUGGED MINI Manuale utente

Thunderbolt

Thunderbolt 600 Manuale utente

Panasonic

Panasonic LB-DH8 series Manuale

Intel

Intel RAID High Availability Manuale utente

LaCie

LaCie 12big Thunderbolt 3 Manuale utente

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuale utente

Panasonic

Panasonic LKM-F931-1 Manuale utente

Tabernus

Tabernus Enterprise Erase E2400 Manuale utente

Rocstor

Rocstor COMMANDER 3F series Manuale utente

Western Digital

Western Digital Ultrastar Data60 Manuale utente

Dell

Dell PowerVault MD3600f Series Manuale utente

CFI

CFI TERA STOR SATA RAID IV Manuale utente
