Quidway® NetEngine 20E Router RPU

http://datacomm.huawei.com

Quidway® NetEngine 20E Router Routing Process Unit

Overview

The routing process unit (RPU) is the main control board of an NE20E router. It consists of

PowerPC processor, system controller bridge, memory and other accessories. This board can be

used to control ports, manage equipment and process software protocols.

The RPU has two GE interfaces, each of which can provide electrical or optical interfaces. To use

the two GE interfaces at the same time, you need to select the same type of interface (electrical or

optical). The system identifies the interfaces according to the connection wire (cable or fiber).

In addition, the RPU provides one Console port, one AUX port and one 10/100 BASE-TX

debugging network port and reserves an interface for CompactFlash CARD.

Specifications

Refer to the table below for specifications of RPU.

Module Interface Description

RT-NE20E-RPU-512M RJ45/SFP RPU providing 512 M memory and two FE/GE

interfaces

Interface properties

Refer to the table below for properties of a Console port.

Property Description

Connector type RJ45

Interface type RS-232

Baud rate 9600 bps ~ 115200 bps

Default value: 9600 bps

Quidway® NetEngine 20E Router RPU

http://datacomm.huawei.com

Refer to the table below for properties of anAUX port.

Property Description

Connector type RJ45

Interface type Asynchronous EIA/TIA-232

Baud rate 300~115200bps

Protocols supported

PPP

SLIP

Refer to the table below for properties of a 10/100 BASE-TX Ethernet port.

Property Description

Connector type RJ45

Frame formats

supported

Ethernet_II

Ethernet_SNAP

IEEE 802.2/IEEE 802.3

Working mode 10/100 Mbps adaptive

Full duplex/Semi-duplex

Protocols supported IP

Refer to the table below for properties of a 10/100/1000 Ethernet interface.

Property Description

Connector type RJ45/SFP optical module

Amount of interfaces 2 1

Frame formats

supported Ethernet_II

Ethernet_SNAP

Working mode 10/100/1000 Mbps adaptive

Full duplex

Protocols supported IP

Technical parameters

Refer to the table below for technical parameters of the RPU.

Quidway® NetEngine 20E Router RPU

http://datacomm.huawei.com

Parameter Description

Silk-screen RPU

Power consumption (W) 60W

Size (mm) 399.15mm (W) x 236mm (D) x 35.06mm (H)

Height 35.06mm
