Huawei DG8045-50 Manuale utente

DG8045-50

Quick Start

Issue 01

Date 2021-04-23

HUAWEI TECHNOLOGIES CO., LTD.

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and

the customer. All or part of the products, services and features described in this document may not be

within the purchase scope or the usage scope. Unless otherwise specied in the contract, all statements,

information, and recommendations in this document are provided "AS IS" without warranties, guarantees

or representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every eort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: https://www.huawei.com

Email: [email protected]

Contents

1 Placing the Device................................................................................................................... 1

2 Connecting Cables................................................................................................................... 3

3 Indicator Description.............................................................................................................. 4

4 Ports and Buttons.................................................................................................................... 6

5 FAQs............................................................................................................................................ 8

DG8045-50

Quick Start Contents

1 Placing the Device

Do not install the DG8045-50 outdoors or in an outdoor cabinet.

Keep 10 cm clearance on all sides to ensure adequate ventilation.

DG8045-50

Quick Start 1 Placing the Device

It is recommended that the computer and DG8045-50 be put far away from

electric appliances that generate strong magnetic or electric elds, such as

microwave ovens.

NO TE

● You can also place the DSL home gateway horizontally on the desk.

● The appearance shown in this document may be dierent from the actual appearance

of the product. The actual product provided by the carrier prevails.

DG8045-50

Quick Start 1 Placing the Device

2 Connecting Cables

1 Telephone jack on the

wall

2 Splitter 3 Telephone

4 STB 5 Desktop computer 6 Power adapter

7 USB device 8 Laptop computer

a Line port b Telephone port c Modem port

NO TE

Some accessories are not delivered with the DG8045-50. Prepare them by yourself.

DG8045-50

Quick Start 2 Connecting Cables

3 Indicator Description

Indicator Status Description

POWER Steady green The DSL home gateway is powered on.

O The DSL home gateway is powered o or

faulty.

DSL Steady green A DSL connection has been set up and

activated.

Blinking green A DSL connection is being activated.

O No DSL connection has been set up, or the

DSL connection is faulty.

Internet Steady green The DSL home gateway is connected to the

Internet in router mode, but no data is being

transmitted.

Blinking green The DSL home gateway is connected to the

Internet in router mode, and data is being

transmitted.

O ● The DSL home gateway is in bridge mode.

● The DSL home gateway is working in

routing mode, but the connection to the

Internet has not been set up.

WLAN Steady green The WLAN function is enabled, but no data is

being transmitted.

Blinking green The WLAN function is enabled, and data is

being transmitted.

O The WLAN function is disabled.

DG8045-50

Quick Start 3 Indicator Description

Indicator Status Description

WPS Steady green The DSL home gateway is connected to a

wireless client, such as a computer with a

wireless network adapter, over the WLAN

using the Wi-Fi protected setup (WPS)

function. The WPS indicator is steady on for

300 seconds.

Blinking green The DSL home gateway is attempting to

connect to a wireless client over the WLAN

using the WPS function. The WPS indicator

blinks for 120 seconds or less.

O The WPS function is disabled or faulty.

LAN1–LAN4 Steady green The LAN port is connected to an Ethernet

device (such as a computer) with a network

cable, but no data is being transmitted.

Blinking green The LAN port is connected to an Ethernet

device with a network cable, and data is being

transmitted.

O The LAN port is not connected to any Ethernet

device.

USB Steady green The DSL home gateway is connected to a USB

device, but no data is being transmitted.

Blinking green The DSL home gateway is connected to a USB

device, and data is being transmitted.

O The DSL home gateway is not connected to

any USB device.

NO TE

If the DG8045-50 is not powered on or the power switch is turned o, all indicators are o.

DG8045-50

Quick Start 3 Indicator Description

4 Ports and Buttons

No. Item Description

1 DSL Connects to a DSL lter or telephone socket.

2 LAN1–LAN4 Connects to Ethernet devices, such as computers, set-top

boxes (STBs), and switches.

3 Power Connects to a power adapter.

4On/O Powers the DSL home gateway on or o.

DG8045-50

Quick Start 4 Ports and Buttons

No. Item Description

5 Reset Restores the DSL home gateway to its default settings or

resets the DSL home gateway.

● To restore the DSL home gateway to its default

settings, press and hold the Reset button for more

than 6s after the DSL home gateway is powered on,

and then release the button. After the DSL home

gateway is restored to its default settings, all

customized data will be lost. Therefore, use this

function only when necessary.

● To reset the DSL home gateway, press and hold the

Reset button for not more than 6s after the DSL home

gateway is powered on.

6 USB Connects to a USB device.

7 WLAN/WPS ● Starts WPS negotiation. Press this button (less than

3seconds) to start WPS negotiation.

● Enables or disables the WLAN function. Press this

button(more than 3 seconds) to enable the WLAN

function.

DG8045-50

Quick Start 4 Ports and Buttons
