Quidway® S3500 Series Security Intelligent Switches Product Specification

http://www.huawei.com/products/datacomm/ 1

Quidway® S3500 Series Security Intelligent Switches

Product Specification

Software Specifications

Feature S3528G/S3528P S3552G/S3552P/S3552F S3552F-HI

Performance

Switching

capacity 12.8Gbps 17.6Gbps 17.6Gbps

Switching

Fabirc 32Gbps 32Gbps 32Gbps

Throughput 9.53Mpps 13.1Mpps 13.1Mpps

Layer 2 Switching

MAC Address 12K MAC addresses

Latency <10µs

VLAN 4K VLANs (IEEE 802.1Q)

GVRP (GARP VLAN Registration Protocol)

Support Port-Based VLAN, Protocol-Based VLAN, IP Subnet-Based VLAN

Link

Aggregation Support FE (Fast Ethernet) port aggregation

Support GE (Gigabit Ethernet) port aggregation

Supports maximum of 6 groups aggregation (each group can contain up to eight

FE ports or up to two GE ports)

Traffic control IEEE 802.3x full-duplex flow control

Back pressure flow control for half-duplex

STP/RSTP/

MSTP IEEE 802.1D Spanning Tree Protocol (STP)

IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)

IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)

MCE N/A N/A Support

Layer 3 Switching

IP Routing 512 Route Interfaces

4K IP Router

Static Routing

RIP (Routing Information Protocol), v1 and v2;

supports Split Horizons

OSPF (Open Shortest Path First), v1 and v2;

BGP4 (Boarder Gateway Protocol)

ECMP(Equal Cost Multi-path): 3 paths

512 Route Interfaces

64K IP Router

Static Routing

RIP (Routing Information

Protocol) v1 and v2

supports Split Horizons

OSPF (Open Shortest

Path First) v1 and v2

BGP4 (Boarder Gateway

Protocol)

IS-IS (Intermedia System

Quidway® S3500 Series Security Intelligent Switches Product Specification

http://www.huawei.com/products/datacomm/ 2

Feature S3528G/S3528P S3552G/S3552P/S3552F S3552F-HI

- Intermedia System)

ECMP(Equal Cost

Multi-path) : 3 paths

Multicast

256 Multicast Routes

IGMP (Internet Group Management Protocol)

snooping on Layer 2 interfaces

IGMP v1 and v2

GMRP (GARP Multicast Registration Protocol)

PIM-DM (Protocol Independent Multicast-Dense

Mode)

PIM-SM (Protocol Independent Multicast-Sparse

Mode)

2K Multicast Routes

IGMP (Internet Group

Management Protocol)

snooping on Layer 2

interfaces

IGMP v1 and v2

GMRP (GARP Multicast

Registration Protocol)

PIM-DM (Protocol

Independent

Multicast-Dense Mode)

PIM-SM (Protocol

Independent

Multicast-Sparse Mode)

Network

Protocol

DHCP Relay (Dynamic Host Configuration Protocol Relay)

TP (Network Time Protocol)

DHCP Server

DHCP Client

TCP/IP protocol stack

ARP

Resilience VRRP (Virtual Router Redundancy Protocol)

Convergence

Priority

Queues Eight hardware queues per port

QoS (Quality of

Service) / ACL

(Access

Control List)

Support 1K flow rules

Flow-based QoS profiles

Ingress and Egress:

• DSCP (Diffserv Code Point)

• Type of Service (ToS)

• Local precedence: physical port, source/destination MAC address,

VLAN information, Ethernet type, Layer 3 protocol, source/destination

IP address, DSCP, datagram type

Support CAR (Committed Access Rate)

Flow control granularity:

• 8Kbit/s increments

• Rate-limiting based on port

ACLs for traffic classification:

• 128 flows per GE port

• 64 flows per FE port

Quidway® S3500 Series Security Intelligent Switches Product Specification

http://www.huawei.com/products/datacomm/ 3

Feature S3528G/S3528P S3552G/S3552P/S3552F S3552F-HI

WRED (Weighted Random Early Detect/Discard)

Support flexible queuing algorithms:

• SP (Strict Priority) Queuing

• WRR (Weighted Round Robin)

• SP + WRR

Security

Network Login

IEEE 802.1X user authentication

Support Portal authentication

SSH v1.5(Secure Shell)

Dynamic VLAN, Guest VLAN

DHCP Relay Security

RADIUS/HWTACACS

PEAP (Protected Extensible Authentication Protocol)/TLS (Transport Layer

Security)

Management

System

Configuration

and

Management

Support CLI (Command Line Interface) configuration mode

Management Support Configuration via the console port

Support Local/remote configuration via Telnet

Support Remote configuration via modem dial-up

Support System configuration with SNMP v1, 2, and 3

Support RMON (Remote Monitoring) v1 1, 2, 3 and 9 groups of MIB

Support Quidway network management system

Support WEB management system

Support Hierarchical alarms

Support System log

Support HGMP (Huawei Group Management Protocol) v2

Support HGMP v1 Server

System

maintenance

Detailed alarm/debug information

Support Ping and Traceroute

Support remote maintenance via Telnet

Support HGMP v1 Server

Hardware Specifications

Port

Configuration S3528G S3552G S3528P S3552P S3552F/S3552F-HI

Fixed ports

(1) 24 10/100M

BASE-TX

Ethernet ports

(2) 1 console

port

(1) 48 10/100M

BASE-TX

Ethernet ports

(2) 1 console

port

(1) 24 10/100m

BASE-TX

Ethernet ports

(2) 1 console

port

(1) 48 10/100M

BASE-TX

Ethernet ports;

(2) 1 console

port

1 console port

Quidway® S3500 Series Security Intelligent Switches Product Specification

http://www.huawei.com/products/datacomm/ 4

Port

Configuration S3528G S3552G S3528P S3552P S3552F/S3552F-HI

Extended

Slot

4 GIBC

extended

module slots

4 GIBC

extended

module slots

4 SFP

extended

module slots

4 SFP

extended

module slots

(1) 1*4 GBIC extended

module slots

(2) 6 extended module

slots supporting 3

kinds of FE extended

module with 8 ports

in front

Extended

Module

(1) GBIC-T

(2) GBIC-SX(0.55km)

(3) GBIC-LX(10km)

(4) GBIC-LH30(30km)

(5) GBIC-LH40(40km)

(6) GBIC-ZX70(70km)

(7) GBIC-STACK

(1) SFP-T

(2) SFP-SX(0.55km)

(3) SFP-LX(10km)

(4) SFP-LH30(30km)

(5) SFP-LH40(40km)

(6) SFP-ZX70(70km)

(1) GBIC-T

(2) GBIC-SX (0.55km)

(3) GBIC-LX (10km)

(4) GBIC-LH30 (30km)

(5) GBIC-LH40 (40km)

(6) GBIC-ZX70 (70km)

(7) GBIC-STACK

(8) 8*100Base-TX

(RJ-45) module

(supports 100m)

(9) 8*100Base-FX

(LC) module (multi

mode supports 2km)

(10) 8*100Base-FX

(LC) module

(single mode

supports 15km)

Attribute S3528G/S3528P S3552G/S3552P S3552F/S3552F-HI

Outline dimensions

(mm)（H×W×D）42mm x 436mm x

240mm 42mm x 436mm x

360mm 86mm x 436mm x

390mm

Weight 4kg 5kg 6kg

RPS redundancy power Support Support Support

Maximum system

power consumption 40W 45W 54W

Input voltage AC : 100V～240V , 50/60Hz

DC: -40 ~ -60V

Noise parameter S3528P/G: 52.5dBA

S3552P/G: 53.0Dba

S3552F: 56dBA

Quidway® S3500 Series Security Intelligent Switches Product Specification

http://www.huawei.com/products/datacomm/ 5

Attribute S3528G/S3528P S3552G/S3552P S3552F/S3552F-HI

Environment Working temperature: 0°C ~ 45°C

Storage temperature: -40°C ~ 70°C

Relative humidity: 10%~90%, non-condensing
