Quidway®S5100-EI Series Intelligent and Resilient Switches Product Specification

http://datacomm.huawei.com 1

Quidway®S5100-EI series Intelligent and

Resilient Switches Product Specification

Name S5124P-EI S5148P-EI S5126C-EI S5150C-EI

Fixed port

24 10/100/1000

Mbps electric

ports

4 Gigabit SFP

Combo ports

48 10/100/1000

Mbps electric

ports

4 Gigabit SFP

Combo ports

24 10/100/1000

Mbps electric

ports

4 Gigabit SFP

Combo ports

48 10/100/1000

Mbps electric

ports

4 Gigabit SFP

Combo ports

Extended slot 0 0 2 2

Extended

module

N/A

(1) 1 port stack 10GE Module

(2) 1 port Xenpak 10GE Module

(3) 1 ports XFP 10GE module

Performance

Wire speed

L2 switching

Port Switch

capacity: 48Gbps

Throughput:

35.71Mpps

Port Switch

capacity: 96Gbps

Throughput:

71.42Mpps

Port Switch

capacity: 88Gbps

Throughput:

65.47Mpps

Port Switch

capacity:

136Gbps

Throughput:

101.19 Mpps

Switching

Fabric 48Gbps 96Gbps 88Gbps 136Gbps

Flash 16M 16M 16M 16M

Switching

mode Store and forward

Forwarding

Latency <40µs

Jumbo Frame Support 9K

Attribute S5100-EI

MAC address

table

Address self-learning

IEEE 802.1D standard

Up to 16K MAC addresses

Up to 1k static MAC addresses

Support black hole MAC addresses

VLAN

4k VLAN (IEEE802.1Q)

Voice VLAN

GVRP

Support port-based VLAN

Quidway®S5100-EI Series Intelligent and Resilient Switches Product Specification

http://datacomm.huawei.com 2

Attribute S5100-EI

Support protocol-based VLAN

Support policy-based VLAN

Stack

For S5100-C-EI only:

Up to 16 units in one stacking group

Stacking bandwidth 40 Gbps

Support HGMP V2 stack

Link

aggregation

Support dynamic aggregation of Gigabit Ethernet (GE) ports

Support dynamic aggregation of 10GE ports

dynamic link aggregation through Link Aggregation Control Protocol (LACP)

Support manual link aggregation

Support static link aggregation

Support up to 25 aggregation groups, each supporting 8 GE or 2 10GE ports

Support load balancing and non-load balancing (when lack of hardware

aggregation resources)

Mirroring

Support traffic mirroring

Support VLAN-based mirroring

Support MAC address–based mirroring Support port mirroring

Support multi-source port mirroring

STP/RSTP

/MSTP

IEEE 802.1D Spanning Tree Protocol (STP)

IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)

IEEE 802.1s Multiple Spanning Tree Protocol instances (MSTP)

Support intra-domain maximum-weight spanning trees (up 16 spanning tree

instances)

Support STP Root Guard

Support BPDU Guard

Flow control IEEE 802.3x (full duplex)

Back-pressure based flow control (half duplex)

Broadcast storm

suppression Support port-based broadcast storm suppression

QinQ Support VLAN-VPN or double tag

Support port-based QinQ

Support selective QinQ

Multicast

Support 1K multicast MAC addresses

Support Internet Group Management Protocol (IGMP) Snoopingv1/v2

Up to 256 multicast groups in a VLAN, and up 1,024 multicast groups in the

entire system

Support multicast VLANs

Support dropping known multicast packets

Support outbound packet filtering for known multicast packets

Support manual configuration of multicast MAC addresses

Network

Protocol

DHCP Snooping (Dynamic Host Configuration Protocol Snooping)

DHCP Client

ARP (Address Resolution Protocol)

Quidway®S5100-EI Series Intelligent and Resilient Switches Product Specification

http://datacomm.huawei.com 3

Attribute S5100-EI

NTP (Network Time Protocol)

BOOTP (Bootstrap Protocol)

Convergence

Quality of

service (QoS)/

Access control

list (ACL)

Packet tagging based on 802.1p or DSCP preference

L2~L4 Packet filter providing filtering based on source/destination MAC

address, source/destination IP address, port, protocol, VLAN, VLAN range,

MAC address range, or invalid frame

Mirroring remote ports (Support RSPAN)

Support priority mapping

Support priority marking

Support traffic statistics

Support port trust mode

Each port supports eight queues

Support SP/SDWRR/SP+SDWRR queue scheduling

Support traffic shaping for ports and queues

Support port-based/flow-based rate limiting, with the minimum granularity of 1

kbps

Support numeral-expressed standard ACL

Support numeral-expressed extendedACL

Support numeral-expressed layer 2ACL

Support ACL application

Support real-time update ofACL rules based on time range changes

Security

Network Login

Support hierarchical management and password protection of users

Support Centralized MAC address authentication

Support Port isolation

Support MAC address black hole

Support MAC Address Learning Limit

Prevent unauthorized access to the network by binding of MAC and PORT

Support SSH(Secure Shell) v2

Support Port security

Up to 256 users under a single port

Support port-based and MAC address–based authentication

Support MAC address authentication and Fabric synchronization

Support Trunk port authentication

Support IEEE 802.1X user authentication

Version checking (802.1 X supplicant system)

Guest VLAN

802.1 X PEAP/EAP/TLS/TTLS

802.1X

Automatic QoS

ACL filtering

Uplink speed limiting

AAA & Radius Support AAA authentication

Support RADIUS authentication

Quidway®S5100-EI Series Intelligent and Resilient Switches Product Specification

http://datacomm.huawei.com 4

Attribute S5100-EI

Management/ Maintenance

System

Configuration

and

Management

Support CLI (Command Line Interface) configuration mode

Support Configuration via the console port

Support Local/Remote configuration via Telnet

Support Remote configuration via modem dial-up

Support System configuration with SNMP v1, 2 and 3

Support HGMP V2

Support RMON (Remote Monitoring) v1, 1/2/3/9 groups of MIBs

Web-based network management

System

Maintenance

and debugging

Detailed alarm/debug information output

Support Ping and Tracert

Support remote maintenance via Telnet Modems and SSH

Support NQA

Support System log

Hierarchical alarm management and alarm filtering

Support DLDP (Device Link Detection Protocol)

Loopback detection on ports

Support VCT(Virtual Cable Test)

Information

center Exporting switch synchronization information

Setting the format of time stamps to be sent to log hosts

Description S5124P-EI S5148P-EI S5126C-EI S5150C-EI

Outline

dimension 43.6 × 260 × 440 mm (1.72 × 10.2 ×

17.3 in.) 43.6 × 300 × 440 mm (1.72 × 11.8 × 17.3

in.)

Weight < 4 kg (< 8.8 lb) 4 kg (8.8 lb) 4 kg (8.8 lb) < 5 kg (< 11 lb)

Power supply

S5100-EI series support bothAC and DC power inputs

AC input:

Rated voltage range: 100 VAC to 240 VAC, 50 Hz or 60 Hz

Max voltage range: 90 VAC to 264 VAC, 47 Hz or 63 Hz

DC input:

Rated voltage range: -48 V to -60 V

Max voltage range: -36 V to -72V

Maximum power

consumption 39 W 78 W 54 W 97 W

MTBF (Years) 22.0 21.1 13.3 12.1

Noise parameter 46.7dBA 50.2dBA 50.1dBA 51.5dBA

Environment Operation temperature: 0°C ~ 45°C

Operating humidity: 5% to 85% non-condensing

Relative humidity: 10% ~ 90%, non-condensing
