OPERATING INSTRUCTION MANUAL

S-55B

Manual Hydraulic Cutting Tool

www.huskietools.com

@huskietoolsinc

linkedin.com/company/huskie-tools

youtube.com/user/huskietools

facebook.com/huskietools

Connect with us!

www.huskietools.com

SPECIFICATIONS

S-55B

Output: 13Ton

Weight: 17 lbs.

Size: 24”L

Jaw Opening: 2”

CUTTING CAPACITIES

Wire Rope 26mm, 1”

Soft Steel Bolts 32mm, 1-1/4”

Rebar, Ground &

Anchor Rod 20mm, 2/4”

Cu/Al Wire 50mm, 2”

ACSR 50mm, 2”

Standard Guy Wire 20mm, 3/4”

Telephone & Lead

Sheathed Cable Do Not Cut

Chain Do Not Cut

www.huskietools.com

GENERAL INFORMATION

The following steps are guidelines for safe operation of the Huskie cutters. Please take the time to

review them as these are helpful hints that have been accumulated over the years.

1. Stay within the maximum cutting limits of each tool as listed in the specications.

2. Try to keep the cutter head clean. When cleaning, use a spray lubricant to avoid a build up of dirt

and sand which will damage the cutter head.

3. Stop pumping when the blade reaches the extreme end of its advance. If the material being cut

(usually wire rope or soft cables) seems to be cut but does not break free of the tool, this indicates

that the blade is jammed on a small piece of cable. Refer to “troubleshooting” on page three to

free the blade.

4. All Huskie tools require proper care. Occasional cleaning and degreasing in solvent, and

sharpening blade and cutter head, will keep these tools operating without problems.

5. The most common problem encountered is blade breakage. Ninety-nine percent of all breakage

occurs because the cutter head is not securely latched before cutting. If the latch is not secured,

the blade will push open the cutter head and damage both the body head and blade. This causes

the outside ear of the blade to break on an angle. In some cases the whole cutter head may crack

in half. Cutting material that is not specied may also cause blade damage. In time these blades

will fatigue and crack and must then be replaced.

6. There may be a residue of oil present on new tools when they are removed from the original

shipping container

7. If tool is jammed, avoid beating directly on the tool with a hammer, especially avoid attening the

piston cylinder. Use a hammer in conjunction with a block of wood or soft material to free the

blade.

8. All tools can be reconditioned and overhauled. Call factory and obtain an RGA # for returning

tools.

9. If the cutters are used under water, wash them down and lubricate after each use. This whole

operation takes less than ve minutes. It may be helpful to paint new tools with a light color,

corrosion resistant paint.

www.huskietools.com

GENERAL INSTRUCTIONS CONTINUED

10. Always return tools to their carrying

bag to protect them from sand and

dirt. Extra bags can be purchased.

11. Always carry a spare blade,

preferably attached to the carrying

bag.

12. Use clear hydraulic uid MV-32

available from your dealer or HTI.

13. When cutting, keep area clear of

spectators as hardened metals may

y apart when severed.

14. Always cut the material at a 90

degree angle to the blade. Any other

angle may cause the blade and head

shear to fracture. See illustration

at right.

www.huskietools.com

TROUBLESHOOTING GUIDE

1. Problem: Small wire strands or pieces of cable or debris get jammed between the cutter head and

blade, not allowing the blade to retract.

Solution: A) Hold release lever down while tapping on the ram with a block of wood and a ham-

mer. If this does not work or tool continues to hang up, proceed to step “B”.

B) Remove blade screw and release the ram. Then disassemble cutter head and remove burrs

from both blade and head shear, using a at grinding stone on the rolled edge. Do not sharpen like

a knife – leave cutting edge at! See illustration on previous page.

2. Problem: Blade is advanced under pressure with no load and the release lever seems to be stuck.

Solution: A) Use both hands to depress lever using body weight and the ground or other strong

surface for support. If this does not work, proceed to step “B”.

B) Lay tool at on the ground or other strong surface and hit release lever with a block of wood and

a hammer to release pressure.

3. Problem: Tool will not advance when handle is pumped.

Solution: A) Remove body handle and check oil reservoir for proper uid level. The oil should be

to the top of the reservoir when the cap is removed. Be sure the tool is fully retracted before

removing cap.

B) After storing for a long period of time, or occasionally when the tool is new, a check ball may be

stuck not allowing it to advance. Invert the tool and rap the cutter head sharply on the ground.

Do this several times, then pump handle to advance the blade.

www.huskietools.com

1. Before cutting, make sure the material being cut is within the proper cutting capacity of the tool

being used.

2. Open cutter head by lifting latch or removing lock pin, depending on the model being used.

3. Insert material between cutter head and blade and secure latch. It is important that you check the

latch for proper engagement before continuing with the cut. Failure to secure the latch can result

in severe tool damage and personal injury.

4. Align the material at a 90 degree angle to the blade. This will ensure a proper cut with minimal

distortion. If the material is cut at any other angle, severe blade damage may occur. Refer to

diagram in the general instructions for proper alignment.

5. Proceed by pumping handle to advance blade. Once blade has made contact with the material,

check alignment once again for proper angle. Continue to pump handle and cut material.

6. Once the cut is made, the release lever on the side of the tool body can be depressed to retract the

blade. On the model S-85 cutter, the pump handle must be rotated 90 degrees clockwise and then

closed to depress release pin located under the handle.

7. These cutters do not have a by-pass cartridge like our compression tools, so they should be

released once the cut is made and not continued to be advanced. If the tool is advanced under

pressure with no load, it is difcult to release the blade. Refer to the troubleshooting on page three

if this condition occurs.

8. Always wear eye protection and any other specied safety equipment when cutting. Be sure sur

rounding area is clear, as hardened metals may y apart when severed.

9. For EHS guy wire or bridge strand, use models S-24CC or S-32CC only! The use of any other S-

series cutter will result in severe blade damage and may cause personal injury.

10. Model S-85 cutter is designed for use on non-ferrous metals only! Do not cut steel or severe tool

damage and personal injury may occur.

S-SERIES OPERATING INSTRUCTIONS

www.huskietools.com

Specifications

Model SP-20 SP-24 SP-24CC SP-32 SP-32CC1 SP-35 SP-40 SP-55 SP-85 SP-100

Output 4.4 Ton 7.8 Ton 7.8 Ton 20 Ton 24 Ton 6.2 Ton 6.28 Ton 13 Ton 2.7 Ton 8.3 Ton

Weight 3 lbs. 6 lbs. 21 lbs. 21 lbs. 26 lbs. 8 lbs. 8.5 lbs. 20 lbs. 16 lbs. 29 lbs.

Length 8”L 11”L 14”L 14”L 13.5”L 14”L 12”L 17”L 19”L 24”L

Jaw

Opening .75” .9” .9” 1.25” 1.25” 1.3” 1.6” 2” 3.3” 4”

Capacities

Wire Ropes 20mm 22mm Do Not Cut 32mm Do Not Cut Do Not Cut 20mm 26mm Do Not Cut Do Not Cut

5/8” 7/8” 1-1/4” 3/4” 1”

Soft Steel

Bolts 14mm 20mm 16mm 32mm 26mm 14mm 16mm 32mm Do Not Cut Do Not Cut

9/16” 3/4” 5/8” 1-1/4” 1” 9/16” 5/8” 1-1/4”

Rebar,

Ground &

Anchor Rod

13mm 16mm 16mm 26mm 26mm 13mm 16mm 20mm Do Not Cut Do Not Cut

1/2” 5/8” 5/8” 1” 1” 1/2” 5/8” 3/4”

Cu & Al

Wire 20mm 22mm Do Not Cut 32mm Do Not Cut 800 MCM 40mm 50mm 76mm 3-1/2”

3/4” 7/8” 1-1/4” 1-1/2” 2” 3”

ACSR 20mm 22mm Do Not Cut 32mm Do Not Cut 336 MCM 40mm 50mm Do Not Cut Do Not Cut

3/4” 7/8” 1-1/4” 1-1/2” 2”

Standard

Guy Wire 14mm 16mm 14mm 22mm 22mm 14mm 16mm 20mm Do Not Cut Do Not Cut

1/2” 5/8” 9/16” EHS 7/8” 7/8” EHS 1/2” 5/8” 3/4”

Chain Do Not Cut Do Not Cut 1/4” Do Not Cut 1/2” Do Not Cut Do Not Cut Do Not Cut Do Not Cut Do Not Cut

Comm.

Cables Do Not Cut Do Not Cut Do Not Cut Do Not Cut Do Not Cut Do Not Cut Do Not Cut Do Not Cut 3.35” 4”

Lead Sheath

Cables Do Not Cut Do Not Cut Do Not Cut Do Not Cut Do Not Cut Do Not Cut Do Not Cut Do Not Cut 3.35” 4”

S-SERIES SPECIFICATIONS

www.huskietools.com
