Atomising Vacuum
Nozzle System
Manual
Page 2
Preliminary Note:
A Word about Water and Atomising Systems
All atomising humidifiers operate based on the principle that water in the form of very fine aerosol
droplets may be atomised and subsequently evaporated.
Because tap water contains various components in addition to pure water (H2O), solids remain
behind after evaporation, such as calcium or other minerals. These form a fine dust in the area of
evaporation. The build up of dust can be prevented by using fully demineralised water. Reverse
osmosis systems, for example, are well-suited for this type of water treatment.
When drinking water is used, mineral deposits may form on the tip of the nozzle. These deposits
must be removed during regular maintenance. Maintenance work can be reduced by using fully
demineralised water.
Consult your HygroMatik specialists. We will answer any questions you may have concerning
water and advise you on the installation and initial operation of your HygroMatik atomising sys-
tem.
Copyright HygroMatik GmbH
VN e October 2011
Information in this manual is subject to change or alteration without prior notice.
WARNING! All work to be performed by trained personnel only. All electrical installa-
tion and servicing of the electrical components of this unit to be performed by quali-
fied electricians only. Disconnect power supply before installation and servicing!
Page 3
1. Introduction................................................................................................................5
1.1 Directions for Use.......................................................................................................5
1.2 Typographic Distinctions............................................................................................7
1.3 Documentation...........................................................................................................7
2. Safety Notes ...............................................................................................................8
2.1 Overview....................................................................................................................8
2.2 Guidelines for Safe Operation....................................................................................9
2.3 Disposal after Dismantling .........................................................................................10
3. Transport ....................................................................................................................11
3.1 General information....................................................................................................11
3.2 Packaging ..................................................................................................................11
3.3 Temporary storage.....................................................................................................11
4. Operation and Installation.........................................................................................12
4.1 Basic Requirements..................................................................................................12
4.2 Sequence of Operation..............................................................................................12
4.3 Vacuum Nozzle Type VN...........................................................................................13
4.3.1 Vacuum Nozzle.......................................................................................................13
4.3.2 Vacuum Nozzle Technical Specifications ...............................................................14
4.4 Control Unit Type CU-1..............................................................................................15
4.4.1 Operation with hygrostat.........................................................................................16
4.4.2 VN Nozzle Self-Cleaning.........................................................................................16
4.4.3 Operation and Display.............................................................................................17
4.4.4 Setting the Cleaning Interval...................................................................................18
4.4.5 Control Unit Technical Specifications......................................................................19
4.5 Pilot Valve Type PV ...................................................................................................20
4.5.1 Pilot Valve Mode of Operation ................................................................................20
4.5.2 Pilot Valve Technical Specifications........................................................................21
4.6 Vacuum Valve Type VV8...........................................................................................21
4.6.1 Vacuum Valve Mode of Operation..........................................................................23
4.6.2 Vacuum Valve Technical Specifications .................................................................24
4.7 Adiabatic Humidification.............................................................................................24
4.8 Atomisation Output.....................................................................................................25
4.8.1 Output Table ...........................................................................................................25
4.8.2 Droplet Size.............................................................................................................26
5. Installation..................................................................................................................27
5.1 General Installation Instructions.................................................................................27
5.2 Installation of System Components............................................................................30
5.2.1 Installation of the Control Unit.................................................................................30
5.2.2 Hygrostat................................................................................................................31
5.2.3 Vacuum Nozzle.......................................................................................................32
5.2.4 Vacuum Valve Type VV8........................................................................................32
5.2.5 Pilot Valve Type PV ................................................................................................34
5.2.6 Plastic Hosing .........................................................................................................34
5.3 Checklists...................................................................................................................35
5.4 Example of Installation...............................................................................................37
6. Water Installation.......................................................................................................39
6.1 Installing the Water Installation..................................................................................39
7. Compressed Air Connection.....................................................................................40
Page 4
7.1 Installing the Compressed Air Connection................................................................. 40
8. Electrical Installation................................................................................................. 41
8.1 Electrical Installation.................................................................................................. 41
8.2 Checklist Prior to Initial Operation ............................................................................. 41
8.3 Wiring Diagram.......................................................................................................... 42
9. Maintenance............................................................................................................... 43
9.1 Maintenance and Maintenance Checks..................................................................... 43
9.2 Maintenance Checks and Adjustments ..................................................................... 43
9.3 Cleaning and Maintenance........................................................................................ 44
9.4 Cleaning the Vacuum Nozzle .................................................................................... 44
9.5 Cleaning the Air Filter................................................................................................ 45
9.6 Cleaning the Water Filter........................................................................................... 46
9.7 Cleaning the Vacuum Valve ...................................................................................... 47
9.8 Dismantling................................................................................................................47
10. EC Declaration of Conformity................................................................................. 48
11. Spare Parts............................................................................................................... 49
12. Fax Form - Order for spare parts ........................................................................... 51
13. Exploded view and sectional drawing................................................................... 52
13.1 Exploded view of vacuum nozzle............................................................................. 52
13.2 Sectional Drawing Vacuum Valve Type VV8........................................................... 52
14. Index ......................................................................................................................... 53
15. Technical data.......................................................................................................... 55
Page 5
1. Introduction
Dear Customer,
HygroMatik vacuum nozzle systems represent the latest in
humidification technology.
They will impress you with their safety, ease of use and econo-
mical operation.
In order to operate your HygroMatik nozzle system safely, pro-
perly and efficiently, please read these operation instructions.
Employ your nozzle system only in sound condition and as
directed. Consider potential hazards and safety issues and fol-
low all the recommendations in these instructions.
If you have additional questions, please contact us:
Tel.: +49-(0)4193/895-0 (switchboard)
Tel.: +49-(0)4193/895-293 (technical hotline)
Fax: +49-(0)4193/895-33
e-mail: [email protected]
1.1 Directions for Use
The HygroMatik nozzle system with vacuum nozzles atomises
water with compressed air using injector technology and is inten-
ded for direct room humidification.
Warning: Use compressed air of breathable air quality only!
This meets Class 1 standards as specified in DIN ISO 85
Class 1 compressed air as specified by DIN ISO 8573-1
residual oil content 0,01 mg/m³
maximum dirt particle size 0,1 µm
Page 6
Note: The air filter for the nozzle system has a pore size of 5
µm; it acts as protection for the nozzle system against impurities
in the plumbing. To achieve breathable air quality, an extra filter
is required.
HygroMatik vacuum nozzles operate with drinking water. Fully
demineralised water must be used to prevent calcium and mine-
ral dust. Usage of fully demineralised water also lengthens main-
tenance intervals.
For the nozzle system, the following connections are needed at
the customer installation site:
Connections:
compressed air: 5-10 bar, 10/8 mm hosing
water: 2-4 bar, 10/8 mm hosing
electricity: 230V/1Ph/50 Hz
Proper usage also entails following HygroMatik's instructions for
installation, dismantling, reassembly, initial operation and opera-
tion and maintenance, as well as disposal procedures.
Only qualified, authorized personnel may operate or service the
unit.
Workers who transport or service the unit must have read and
understood the relevant sections of the operating instructions,
especially the section "Safety Notes." In addition, staff must
receive safety training about potential hazards from the operator.
Place a copy of the operating instructions at the location where
the unit is operated.
.
Page 7
1.2 Typographic Distinctions
•preceded by a bullet: general specifications
» preceded by an arrow: Procedures for servicing or
maintenance that should or must be performed in
the indicated order.
Installation step which must be checked off.
1.3 Documentation
Retention
Please retain these operating instructions in a secure, always
accessible location. If the product is resold, turn the documenta-
tion over to the new operator. If the documentation is lost, please
contact HygroMatik.
Versions in Other Languages
These operating instructions are available in several languages.
If interested, please contact HygroMatik or your HygroMatik dea-
ler.
Page 8
2. Safety Notes
2.1 Overview
These safety notes are required by law. They promote work-
place safety and accident prevention.
Warnings and Safety Symbols
The safety symbols below identify sections containing warnings
about hazards or potential dangers. Please familiarize yourself
with these symbols.
Warning: Failure to observe this warning may result in serious
injury or death and/or damage to the unit.
Danger, Hazardous Voltage: Hazardous electrical current! Fai-
lure to observe this warning may result in injury or even serious
injury or death
Warning: Failure to follow these instructions may result in
damage to the unit due to electrostatic discharge. The electronic
components of the humidifier control are very sensitive to elec-
trostatic discharges. In order to safeguard these components
during installation and servicing, steps must be taken to protect
against ESD.
Note: Materials and consumables must be handled and/or dis-
posed of as required by law.
Note: Appears before explanations or cross-references which
refer to other sections of the operating instructions.
Page 9
2.2 Guidelines for Safe Operation
Overview
Observe all safety information and warnings which appear on
the nozzle system.
In case of a malfunction, switch off the nozzle system immedia-
tely and prevent a restart. Repair malfunctions promptly.
After any repair work, have qualified personnel check the safe
operation of the nozzle system.
Use original spare parts only.
Additional national safety regulations also fully apply to the ope-
ration of this nozzle system.
Accident Prevention Regulations
Warning: Comply with the accident prevention regulation
Accident Prevention Regulation Electrical Systems and Equip-
ment (VBG 4/BGVA2) to prevent injury to yourself and others.
Operating the Nozzle System
Do not perform any work which compromises the safety of the
nozzle system.
Regularly check that all safety and monitoring devices are func-
tioning normally.
Do not remove or disable safety devices.
Installation, Dismantling, Maintenance and Repair of the
Nozzle System
When performing maintenance or repair work on nozzle system
components, switch off power, shut off pressure and close off
water supply.
Attaching or installing additional components is permitted only
with the written consent of the manufacturer.
Page 10
Electrical
Warning: Work on the electrical system must be performed by
qualified personnel.
If the electrical power supply malfunctions, switch off the control
unit immediately.
Use only original fuses with the appropriate amperage rating.
Regularly check the control unit's electrical equipment. Promptly
repair any faults, such as loose connections or damaged wiring.
After proper electrical installation or repair, test all safety mecha-
nisms (such as grounding resistance).
The control of theHygroMatik Nozzle System is IP55-protected.
Installing a humidifier in a room without water discharge requires
safety devices to protect against water leakages.
2.3 Disposal after Dismantling
Note: The operator is responsible for the disposal of nozzle sys-
tem components as required by law.
Questo manuale è adatto per i seguenti modelli
3
Indice
Manuali Unità di controllo popolari di altre marche
Festo
Festo Compact Performance CP-FB6-E Manuale elenco delle parti
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Manuale utente
JS Automation
JS Automation MPC3034A Manuale utente
JAUDT
JAUDT SW GII 6406 Series Guida rapida
Spektrum
Spektrum Air Module System Manuale utente
BOC Edwards
BOC Edwards Q Series Manuale utente
