i3 International Ax52 Series Manuale utente
Ax52 Dome Camera Series
Instruction Manual
Before attempting to connect or operate this product, please read these
instructions carefully and save this manual for future use.
CONTENTS
SAFETY INFORMATION...
..................................................
PRODUCT OVERVIEW .......................................................
SPECIFICATION................................................................
INSTALLATION..................................................................
2
4
6
8
Rev. 141120
When installing your Annexxus system, be sure to avoid:
• excessive heat, such as direct sunlight or heating appliances
• moisture, dust, and smoke
• strong magnetic elds
• close to sources of powerful electromagnetic radiation, such
as radios or TV transmitters
• close to humid or excessively dusty places
• where exposed to mechanical vibrations
• close to uorescent lamps or objects reecting light
• under unstable light sources (may cause ickering)
• temperatures below 10° Celsius or 14° Fahrenheit and
above 50° Celsius or 122° Fahrenheit for AX41C1M
Power Supply
• Ensure the supplied voltage meets the power consumption
requirements of this camera before powering the camera on.
Incorrect voltage may cause irreparable damage to the video
camera and will effectively void the camera warranty
Cleaning
• For maximum optical clarity, the camera dome or lens must
remain clean. Use a soft, dry cloth to remove nger prints or dust
from the dome cover.
• Use a blower to remove dust from the lens.
• Clean the body with a soft, dry cloth. If it is very dirty, use a
cloth dampened with a small quantity of neutral detergent, then
wipe dry.
• Do not use volatile solvents such as alcohol, benzene, or
thinners, as they may damage the surface nishes.
Servicing
• To avoid electrical shock and to preserve the product warranty,
DO NOT disassembles the camera. Refer servicing to qualied
personnel only.
SAFETY INFORMATION
2
SAFETY INFORMATION
The triangle symbol with lightning arrow indicates
that ungrounded “Hazardous Voltage” exists within
the unit. The voltage level may cause personal
electric shock hazards.
The triangle symbol with exclamation mark
indicates that there are important operation and
maintenance instructions in the Instruction Manual.
3
PRODUCT OVERVIEW
1. Key Features
High Denition Images
Clear and detailed HD quality images in all conditions. Unlike other
megapixel cameras, AX52 offers higher resolutions and better frame
rates. Blurry images are reduced and individuals and objects of
interest come with perfect clarity.
Triple Streaming
The AX52 Network Camera is designed to show extreme image
detail. H.264/MPEG4/MJPEG triple streaming allows you to choose
the appropriate code for your bandwidth.
Cost-saving H.264 Support
The AX52 supports the H.264 compression standard. H.264 greatly
reduces the size of video without compromising image quality.
Storage and bandwidth are reduced.
4
PRODUCT OVERVIEW
5
2. Camera Overview
• Power In (Red+/Black-): power connector,
DC12V/AC24V
• RJ-45 Ethernet Connector: network connection. Support
PoE (Power over Ethernet) cable.
• BNC: video output
• Audio Out (Green): audio output
• Audio In (Red): audio input
• Alarm Out (Orange): alarm signal output port /Reserved
(Green)/ Reserved (Yellow)/
2.0 Camera Parts and Denitions
• GND: ground (electricity) in electrical circuits/Alarm In 1 (Red): alarm signal input port/Alarm In 2 (Brown):
alarm signal input port
• Reset: use an appropriate tool to press the button to reset the camera (Hold for 5 seconds to reboot
camera. Hold longer than 5 seconds to load default settings)
Note: If PoE (Power over Ethernet) connector is used, it eliminates need for Power In cable.
SPECIFICATION
6
Image system
Image sensor 1/3" 2 MP image sensor optimized for low-light performance
Effective pixels Effective 16:9 1920 (H) X 1080 (V)
Image Compression Method Triple Streaming : H.264 / MPEG4 / Motion JPEG
Video Codec / Resolution
H.264 (16:9): 1920X1080(2M) 1280X720
(4:3): 1280x960(SXVGA)
MPEG4 (16:9): 1920X1080(2M) 1280X720
(4:3): 1280x960(SXVGA)
MJPEG (16:9): 1920X1080(2M) 1280X720
(4:3): 1280x960(SXVGA)
Primary Stream Video Compression: H.264 or MPEG-4 or MJPEG
Secondary Stream Video Compression: H.264 or MPEG-4
Third Stream Video Compression: MJPEG
Frame rate up to 15fps(NTSC) and 12.5fps(PAL) at 1920x1080;
up to 30fps(NTSC) and 25fps(PAL) at 1280x720
Len Built-in Mechanical ICR Filter varifocal lens f=3~9mm, F1.2 (Mega pixel
lens)
Electric
Sync system Internal
AES NTSC: 1/10000 s to 1/3.75s (selectable);
PAL: 1/10000 s to 1/3.125s (selectable)
Audio Two-way Mono Audio, Full-duplex, G.711 PCM 8kHz
Alarm 2 Inputs / 1 Output
RS485 Reserved
Day & Night Mode ICR D/N control; Auto/ Forced BW/ Forced Color/ External
Minimum illumination 0.08 Lux @10IRE; 0.3Lux @50IRE
Video port BNC X1, 1.0Vp-p, 75Ω / RCA x 1
TV output NTSC, 720 X 480 @30fps
PAL, 720 X 576 @25fps
Intelligent video Video motion detection
Feature
Exposure mode Auto/Manual
BLC 5 x 5 zones selectable
ATR/D-WDR Digital wide dynamic range
White Balance Auto/Manual
Sharpness 255 level sensitivity
Saturation 255 level sensitivity
Brightness 255 level sensitivity
Contrast 255 level sensitivity
Privacy Zone Yes; customized threshold privacy zone
SPECIFICATION
7
Other Mirror, Flip, System log, Time stamp, Snapshot, Event Management
Primary Stream Bit Rate Control: CBR/VBR
Local Storage
Memory Card Support Micro SD/ Micro SDHC Card up to 32 GB
SD card overwrite Yes
SD card store category Alarm /Ethernet Fail
file format JPEG/ AVI
Recording frame rate range between 1 to 3 fps
Power Supply
Power requirement DC 12V & AC 24V ± 10% / PoE(IEEE 802.3af)
Power consumption 5W Max
Power connector Screwless Terminal block
Environment
Operating temperature -10ºC ~ 50ºC (14ºF ~ 122ºF)
Operating humidity 10~90% RH
Storage temperature -20ºC ~ 60ºC (-4ºF ~ 140ºF)
Network
Ethernet 10/100 base-T Ethernet connection for LAN/WAN
Internet protocol TCP/IP, UDP, HTTP, FTP, DNS, DHCP, NTP, RTP,RTSP, ICMP, uPNP
IP IPv4
Connectors RJ-45
Control interface IE browser 6.0 or above
I/O connector
Alarm port Terminal block 2 in / 1 out
Audio In / Out port 3.5mm Phone Jack x 2
Reset Within 5 sec for rebooting system; more than 5 sec for loading default
Mechanism
Dimensions( xH) O138mm x H102mm (O54inch x H40 inch)
Weight (Camera Only) 1.13kg (2.5lb)
NOTE:The specication is subject to change without notice.
INSTALLATION
8
3. Camera Installation
Use the appropriate brackets and equipment to mount this camera.
After installing the camera, your network camera should be accessed
from your local network.
3.1 Package Content
Item Description
Network Dome Camera x1
Printed Quick Start Guide x1
CD-ROM ( User Manual, Annexxus
Finder )
x1
Guide Pattern Sticker x1
RJ45 Female / Female Coupler x1
(1) Flat Hand Screw (Machine Type) x4
(2) Flat Hand Screw (Tapping Type) x4
(3) Plastic Anchor x4
(4) Plastic Mounting Button x4
(5) Rubber Feet x4
INSTALLATION
9
3.1.5 Camera Installation for ceiling mount and wall mount
Drill the Mounting Location
1. Place the “Guide Pattern Sticker” on the desired location.
2. Drill 4 mounting holes and 1 cable entry hole.
• Mark holes’ positions: secure the metal plate to the ceiling using the
appropriate screws.
• Use the machine type screws if you are attaching the camera to a pendent
mount. Use the tapping type screws for all other surfaces.
• For cement surfaces, insert the “Plastic Anchors” into the holes. For softer
surfaces, do not use the “Plastic anchors”.
• Use the Rubber Feet for surface mounting.
• If using SD card function, insert Micro SD card or Micro SDHC card before
locking the dome cover.
Tapping
Type
Screws
Plastic Anchors
INSTALLATION
10
Adjusting Camera Focus
1. Take off the screw (a.)
Counter Clockwise
Screw (a.)
2. Rotate the dome counter clockwise to unlock and pull free of the housing.
3. Remove the inner liner by gently pulling it free of the two notches in the housing.
