SecuriTEST User’s Manual

Table of Contents

Before Using SecuriTEST................................... 2

SecuriTEST Safety Precautions ........................ 3

Battery Charging Precautions ............................ 5

Standard Accessories.......................................... 8

Names & Functions.............................................. 9

General Specifications ...................................... 14

Meter Specifications .......................................... 15

Digital Multi-Meter .............................................. 23

PTZ Controller..................................................... 30

UTP Cable Tester............................................... 36

View Information................................................. 38

Before Using SecuriTEST

WARNING

Read the “Safety Information” portion of the manual

before using the SecuriTEST CCTV tester.

This manual is for users of the IDEAL SecuriTEST multi-

function CCTV tester. The manual describes the

operation and function of the various features of

SecuriTEST.

It is highly recommended that operators read the entire

manual before using SecuriTEST to prevent damage to

the tester or injury to the operator.

WARNING

SecuriTEST Safety Precautions

When using the Digital MultiMeter function to measure

voltage or current, be sure that the input does not

exceed the capabilities of the tester. Overloading the

tester can cause damage or personal injury.

When measuring current of unknown values, always

begin with the 10A mode, then step down to the 400mA

input if necessary.

Environmental Limitations

Temperature: -10 to 50 degrees C

14 to 122 degrees F

Relative Humidity: 0-90%, non-condensing

DC input voltage: 12V +/-10%, 1A

1. SAFETY INFORMATION

Do not use the unit in damp conditions or environments

where explosive gases may be present.

Do not handle the unit with wet hands.

Avoid dropping or causing mechanical shock to the unit.

Do not expose the ports to liquids and avoid exposure to

dust.

Use only specified replacement fuses.

Do not use damaged test leads with the DMM.

Do not measure resistance on powered circuits.

When using the DMM function, set the proper mode

before connecting to the circuit under test.

When measuring resistance, make certain that the circuit

is de-energized before connecting the test leads to the

circuit.

1. SAFETY INFORMATION

WARNING

Battery Charging Precautions

SecuriTEST is capable of

recharging NiMH batteries

installed in its battery

compartment.

To charge the batteries attach

the included 12V adapter to the

handset and set the main

power switch to the ON

position. Charging time takes 8

hours. Although the charge

LED will light regardless of the

position of the power switch,

charging will only occur with the

switch in the ON position.

Operation time is approximately

3-4 hours on a fully charged set

of batteries.

When using alkaline batteries

the tester can run for

approximately 2 hours on a new

set of batteries.

When using alkaline batteries,

set the switch inside the battery

compartment to OFF to prevent

accidental charging of alkaline

batteries.

- Battery Precautions -

The following batteries can be used with SecuriTEST:

> AA size alkaline batteries

> AA size rechargeable nickel metal hydrogen

(Ni-MH) batteries

When charging batteries in SecuriTEST:

Place both the MAIN POWER and the CHARGE

SWITCH to the “ON” position. The charge LED will light

when the MAIN POWER SWITCH is in either position,

but the batteries will charge only when the switch is set

to “ON”.

The CHARGE SWITCH is located on the upper part of

battery compartment. (Refer to the figure below)

The performance of batteries can be very different,

depending on manufacturers. Please use any reputable

brand for best performance. Do not mix batteries of

different manufacturers when charging batteries. Make

sure not to reverse the polarization of the batteries. Do

not short-circuit or disassemble batteries. Make sure to

check the polarization, voltage and current ratings before

charging batteries. Immediately disconnect the charger

should an abnormal situation arise.

FEATURES

SecuriTEST is a portable device for testing and

troubleshooting various functions of CCTV cameras. It

includes functions to test video image quality, control

PTZ operation, analyzes various PTZ protocols,

generates video test patterns, test UTP cables and

includes a full-function Digital MultiMeter.

All functions are controlled through the front keypad and

on-screen display for quick and easy setup of fixed and

PTZ camera systems.

2. SecuriTEST Introduction

Video Tester ►Displays the output signal from the

connected CCTV camera. Used to

adjust aim and adjust and

troubleshoot cameras.

►Video signal generator mode:

Outputs color bars and Red, Blue

and Green screens to allow

technicians to configure monitors

and troubleshot cameras by sending

a known good video signal down a

questionable coax run. Supports

both PAL & NTSC video signal

formats.

MultiMeter ►Measures resistance, AC/DC

voltage and current, and provides

continuity beep and display hold

functions.

PTZ Controller ►The PTZ controller tests the

movement of the dome and allows

manual zoom and manual focus

control of the camera. Supports

various RS-485 and RS-422

protocols to allow operation with a

variety of camera manufacturers.

UPT Cable Tester►The UTP cable check tests

unshielded cables for continuity,

opens, shorts and mis-wired pairs.

Standard Accessories

The following items are included with the SecuriTEST

CCTV Tester.

•SecuriTEST Handset

•User’s Manual

•DMM Test Lead Set (Red, Black)

•AC Adapter with international plug adapters

•Rechargeable AA Nickel Metal Hydride

(Ni-MH) Battery (6ea)

•Neck Strap

•UTP test Terminator

•BNC Video Cable

•Car Power Jack (12VDC)

Names & Functions
