IEI Technology IMBA-H310 Manuale utente

ATX Motherboard Supports 14nm LGA1151 8th/9th Generation Intel®

Core™ i9/i7/i5/i3, Celeron®and Pentium®Processor, DDR4,

Triple Independent Displays, Dual GbE LAN, USB 3.2 Gen 1,

SATA 6Gb/s, HD Audio and RoHS

IMBA-H310

Quick Installation Guide

Version 1.0

September 16, 2020

Package List

IMBA-H310 package includes the following items:

1 x IMBA-H310 single board computer

1 x I/O shielding

2 x SATA cable

1 x QIG

Specifications

CPU:

LGA1151 socket supports 8th/9th generation Intel®Core™

i9/i7/i5/i3, Celeron®and Pentium®processor

System Chipset:Intel®H310

Memory:

Two 288-pin 2666/2400 MHz dual-channel DDR4 SDRAM

un-buffered DIMM slots (system max. 64 GB)

BIOS: AMI UEFI BIOS

Graphics Engine:

Intel®HD Graphics Gen 9 engine with 16 low-power execution

units supports DX2015, OpenGL 5.X and OpenCL2.x, ES 2.0

Display Output:

Triple independent display

1 x DVI-D (up to 2560x1600@60Hz)

1 x VGA (up to 1920x1200@60Hz)

1 x iDP (up to 4096x2304@60Hz)

Super IO: Fintek 81866

EC: IT8528E

Ethernet:

LAN1: Intel®I219LM PHY

LAN2: Intel®I211AT PCIe Ethernet controller

Audio:

Realtek ALC662 HD Audio codec supports 5.1-channel

(line-in, line-out, mic-in)

External I/O Interface:

4 x USB 3.2 Gen 1 (5Gb/s)

2 x USB 2.0

2 x RS-232

1 x PS/2 keyboard/mouse

Internal I/O Interface:

1 x KB/MS (1x6 pin)

1 x LPT (2x13, p=2.54mm)

3 x RS-232 (2x5, p=2.54mm)

1 x RS-232/422/485 (2x5, p=2.54mm）

2 x USB 2.0 (2x4, p=2.54mm)

4 x SATA 6Gb/s (no RAID)

Front Audio: 2x5-pin header

Front Panel: 1 x Front panel (2x7 pin, power LED, HDD LED,

speaker, power button, reset button)

LAN LED: 2 x LAN LED (1x2 pin)

SMBus:1 x SMBus (1x4 pin)

I²C: 1 x I²C (1x4 pin)

Expansion:

1 x PCIe x16 slot (Gen 3)

1 x PCIe x4 slot (Gen 2)

4 x PCI slots

Digital I/O: 8-bit digital I/O (4-bit input / 4-bit output)

TPM:1 x 20-pin (2x10) header

Watchdog Timer:

Software Programmable, supports 1~255 sec. System reset

Fan Connector:

1 x CPU smart fan (1x4 pin)

2 x System smart fan (1x3 pin)

Chassis intrusion: 1 x 2-pin header

Power supply: ATX/AT power supply

Power Consumption: [email protected], [email protected], 12V@3.08A,

[email protected] (Intel®Core™i5-8500 up to 3.00 GHz CPU with

20 GB 2400/2133 MHz DDR4 memory)

Operation Temperature: -20°C ~ 60°C

Storage Temperature: -30°C~70°C

Operation Humidity: 5% ~ 95%, non-condensing

Weight (GW/NW): 1200g/700g

Dimensions: 244 mm x 305 mm

Ordering Information

IMBA-H310-R10:

ATX motherboard supports 14nm LGA1151 8th/9th Generation Intel®

Core™ i9/i7/i5/i3, Celeron®and Pentium®processor, DDR4, triple

independent displays, dual GbE LAN, USB 3.2 Gen 1, SATA 6Gb/s,

HD Audio and RoHS

IMBA-H310-ECO-R10:

ATX motherboard supports 14nm LGA1151 8th/9th Generation Intel®

Core™ i9/i7/i5/i3, Celeron®and Pentium®processor, DDR4, triple

independent displays, dual GbE LAN, USB 3.2 Gen 1, SATA 6Gb/s,

HD Audio, ECO packaging and RoHS

19800-000075-RS:KB/MS cable with bracket, 220mm

32102-000100-200-RS: SATA power cable

19800-003100-100-RS: Dual-port USB cable with bracket, 300mm

32205-000702-100-RS: RS-232 cable, 230mm

CF1156A-RS-R11: High-performance LGA1155/1156 cooler kit, 1U

chassis compatible 73W

CF-115XC-R10: LGA1155/LGA1156 cooler kit, 1U chassis

compatible, 45W

CF-115XD-R10: LGA1155/LGA1156 cooler kit, 1U chassis

compatible, 65W

CF-115XE-R10: High-performance LGA1155/1156 cooler kit, 95W

TPM-IN02-R20: 20-pin Infineon TPM 2.0 module, software

management tool, firmware v5.5

All the drivers and utilities for the

IMBA-H310 are available on IEI

Resource Download Center. Type

IMBA-H310 and press Enter to find all the

relevant software, utilities, and

documentation. To install software from

the downloaded ISO file, mount the file

as a virtual drive to view its content.

IEI Resource Download Center

https://download.ieiworld.com

Jumpers Settings and Connectors

LABEL

FUNCTION

CPU12V1

+12V power connector

ATXPWR1

Additional power connector

ATX1

ATX power connector

BAT1

Battery connector

CHASSIS1

Chassis intrusion connector

CHA_DIMM0,

CHB_DIMM0

DDR4 DIMM sockets

DIO1

Digital I/O connector

CN1

EC debug connector

CPU_FAN1

Fan connector (CPU)

SYS_FAN1, SYS_FAN2

Fan connectors (system)

FRONT-PANEL1

Front panel audio connector

F_PANEL1

Front panel connector

I2C1

I2C connector

DP1

Internal DisplayPort connector

KB_MS1

Keyboard and mouse connector

LED_LAN1, LED_LAN2

LAN LED connectors

LPT1

Parallel port connector

PCI1, PCI2, PCI3, PCI4

PCI slots

PCIEX16

PCIe x16 slot

PCIEX4_1

PCIe x4 slot

PWR_SW1

Power button

COM3, COM4, COM6

RS-232 serial ports

COM5

RS-232/422/485 serial port

S_ATA1, S_ATA2,

S_ATA3, S_ATA4

SATA 6Gb/s drive connector

SMB1

SMBus connector

J_SPI1

SPI flash connector

J_EC1

SPI flash connector, EC

TPM1

TPM connector

USB1

USB 2.0 connector

AUDIO_CV1

External audio connector

LAN1_USB1,

External Ethernet and USB 3.2 Gen 1

LAN2_USB2

connectors

K/M_USB1

External keyboard/mouse and USB 2.0

connectors

COM1/1

External serial port connector

VIDEO1

External VGA and DVI-D connector

J_ATX_AT1: AT/ATX Mode Select Switch

PIN NO.

DESCRIPTION

Short 1 - 2

ATX Mode (default)

Short 2 - 3

AT Mode

J_CMOS1: Clear CMOS Jumper

PIN NO.

DESCRIPTION

Short (default)

Keep CMOS Setup

(Normal Operation)

Open

Clear CMOS Setup

USB SW1, USB SW2: USB Power Setting

BIOS Settings

DESCRIPTION

+5V

Power is not provided to the USB

connectors when the system is in

S3/S4 sleep state

+5VDUAL (default)

Power is provided to the USB

connectors when the system is in

S3/S4 sleep state

Chipset

PCH-IO Configuration

Auto Power Button Function [Disable

(ATX)]

Restore AC Power Loss [Last State]

Power Saving Function(ERP) [Disabled]

USB Power SW1 [+5VDUAL]

USB Power SW2 [+5VDUAL]

> PCI Express Configuration

> SATA Configuration

> HD Audio Configuration

-----------------

J_FLASH1: Flash Descriptor Security Override

PIN NO.

DESCRIPTION

Short 1 - 2

Disabled (default)

Short 2 - 3

Enabled

CPU12V1: +12V Power Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

+12V

ATXPWR1: Additional Power Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

+12V

GND

+5V

ATX1: 24-pin ATX Power Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

+3.3V

-12V

GND

+5V

PS_ON

GND

6 +5V 18 GND

GND

Power good

-5V

5VSB

+5V

+12V

+5V

+12V

+5V

+3.3V

GND

CHASSIS1: Chassis Intrusion Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

+3.3VSB

CHASSIS OPEN

DIO1 : Digital Input / Output Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

VCC

Output 3

Output 2

Output 1

Output 0

Input 3

Input 2

Input 1

Input 0

CN1: EC Debug Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

EC_EPP_STB#

EC_EPP_AFD#

EC_EPP_PD0

EC_EPP_PD1

EC_EPP_INIT#

EC_EPP_PD2

EC_EPP_SLIN#

EC_EPP_PD3

GND

EC_EPP_PD4

EC_EPP_PD5

EC_EPP_BUSY

EC_EPP_PD6

EC_EPP_KSI5

EC_EPP_PD7

EC_EPP_KSI4

CPU_FAN1: CPU Fan Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

+12V

FANIO

PWM

SYS_FAN1, SYS_FAN2: System Fan Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

FANIO

+12V (PWM)

GND

FRONT-PANEL1 : Front Panel Audio Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

MIC2-L

GND

MIC2-R

Presence#

LINE2-R

MIC2-JD

FRONT-IO

LINE2-L

LINE2-JD

F_PANEL1: Front Panel Connector

DESCRIPTION

PWR

LED

PWR_LED+

Speaker+

SPKR

N/C

PWR_LED-

N/C

PWR

BTN

PWR_BTN+

Speaker-

PWR_BTN-

RESET

HDD

LED

HDD_LED+

Reset+

HDD_LED-

Reset-

I2C1: I2C Connector (to EC)

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

I2C_DAT

I2C_CLK

+5V

KB_MS1: Keyboard/Mouse Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

VCC

Mouse Data

Mouse Clock

Keyboard Data

Keyboard Clock

GND

LED_LAN1: LAN LED Connector

DESCRIPTION

+3.3V

LAN1_LED_LNK#_ACT

LED_LAN2: LAN LED Connector

DESCRIPTION

+3.3V

LAN2_LED_LNK#_ACT

DP1: Internal DisplayPort Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

DATA_0P

GND

DATA_3N

DATA_0N

CONFIG1

DATA_1P

CONFIG2

GND

AUX_P

DATA_1N

GND

DATA_2P

AUX_N

GND

DP_HPD

DATA_2N

GND

DATA_3P

DP_PWR

LPT1: Parallel Port Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

RSTROBE#

SIO_AFD#

RPD0

SIO_ERR#

RPD1

SIO_INIT#

RPD2

SIO_SLIN#

RPD3

GND

RPD4

GND

RPD5

GND

RPD6

GND

RPD7

GND

SIO_ACK#

GND

SIO_BUSY

GND

SIO_PE

GND

SIO_SLCT

N/C

Altri manuali per IMBA-H310

Indice

Altri manuali IEI Technology Scheda madre

IEI Technology

IEI Technology WAFER-US15WP Manuale utente

IEI Technology

IEI Technology IMBA-8650 Manuale utente

IEI Technology

IEI Technology NANO-QM871 Manuale utente

IEI Technology

IEI Technology KINO-HM551 Manuale utente

IEI Technology

IEI Technology IMB-H810-i2 Manuale utente

IEI Technology

IEI Technology NANO-QM871-i1-i7 Manuale utente

IEI Technology

IEI Technology NANO-HM650 Manuale utente

IEI Technology

IEI Technology IMB-H810-i2-R11 Manuale utente

IEI Technology

IEI Technology Wafer-CX700m Manuale utente

IEI Technology

IEI Technology NOVA-7820 Manuale utente

IEI Technology

IEI Technology NANO-945GSE3 Manuale utente

IEI Technology

IEI Technology IMB-Q354 Manuale utente

IEI Technology

IEI Technology WAFER-6820 Manuale utente

IEI Technology

IEI Technology IMBA-Q170-i2 Manuale utente

IEI Technology

IEI Technology KINO-9653 Manuale utente

IEI Technology

IEI Technology PCIE-Q670-R20 Manuale utente

IEI Technology

IEI Technology KINO-SE-i2 Manuale utente

IEI Technology

IEI Technology PICO-8522 Manuale utente

IEI Technology

IEI Technology NANO-HM551-R10 Manuale utente

IEI Technology

IEI Technology IMBA-X9654 Manuale utente

IEI Technology

IEI Technology KINO-AH612 Manuale utente

IEI Technology

IEI Technology IMB-9454G-R20 Manuale utente

IEI Technology

IEI Technology KINO-9152G4 Manuale utente

IEI Technology

IEI Technology imba-30104 Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente
