IEI Technology ISP-9652 Manuale utente

Socket P Intel® Core™2 Duo MB, GME965/GLE960 with

800/533MHz FSB, VGA, CF, 6 Intel® GbE Lan with Dual

group Lan-Bypass function, USB2.0, SATAII, RoHS

ISP-9652/9602

Quick Installation Guide

Version 1.0

Feb. 22, 2010

Package Contents

ISP-9652/9602 package includes the following items

z1 x ISP-9652/9602 Single Board Computer

z3 x SATA cable

z1 x Mini Jumper Pack

z1 x Utility CD

z1 x QIG(Quick Installation Guide)

Specifications

zCPU :

Socket P Intel® Core™ 2 Duo Processor with 800MHz FSB

Socket P Intel® Celeron® M Processor with 533MHz FSB

zSystem Chipset :

Intel® GME965 + ICH8M for ISP-9652

Intel® GLE960 + ICH8M for ISP-9602

zBIOS : AMI Flash BIOS

zFSB :

800 / 533MHz FSB for ISP-9652

533MHz FSB for ISP-9602

zSystem Memory :

Two 240-pins 667/533MHz dual-channel DDR2 SDRAM DIMM

Supported (max. 4GB) for ISP-9652

Two 240-pins 533MHz dual-channel DDR2 SDRAM DIMM Supported

(max. 2GB) for ISP-9602

zEthernet :

LAN1~LAN6: Six Intel® 82574L PCIe GbE Controller(PCIe x1

Interface)

2 x LAN By-Pass Function Gruop(with Relay Control)：

By-Pass Group 1: LAN1/LAN2

By-Pass Group 2: LAN3/LAN4

zI/O Interface :

2 x RS-232 (1 on rear side, 1 on board by pin-header)

10 x USB 2.0 (2 on rear side, 8 on board by pin-header)

3 x SATA II

1 x CF Type II Slot

zDisplay Interface :

CRT/VGA integrated in Intel® GME965/GLE960 (Intel® GMA X3100)

zExpansions :

1 x PCI Slot

1 x PCIe x16 Signal to Golden finger (for ISP-9652 Only)

zSuper I/O : ITE IT8718F

zEmbedded Controller: ITE IT8512E

zWatchdog Timer :

Software Programmable support 1~255 sec. System reset by Super

I/O : ITE IT8718F.

zPower Supply : ATX Power Supply

zPower Consumption :

5V@ 12.9 A, 12V@ 0.14A, 12V_Core@ 12.69A, 3.3V@ 0.47A

(Intel® Core™ 2 Duo T7500 2.2GHz with DDR2 800MHz 2GB DRAM

x2)

zOperation Temperature : 0°C ~ 60°C (32°F ~ 140°F)

zOperation Humidity : 5% ~95% non-condensing

zDimensions : 220mm x 244mm

zWeight : GW: 1000g / NW: 450 g

Ordering Information

ISP-9652-R10 :

Socket P Intel® Core™2 Duo MB, GME965 with 800MHz FSB, VGA, CF, 6

Intel® GbE Lan with Dual group Lan-Bypass function, USB2.0, SATAII,

RoHS

ISP-9602-R10 :

Socket P Intel® Core™2 Duo MB, GLE960 with 533MHz FSB, VGA, CF, 6

Intel® GbE Lan with Dual group Lan-Bypass function, USB2.0, SATAII,

RoHS

19800-000114-RS :

RS-232 Cable with Bracket

CB-USB14-RS: Quad Ports USB Cable with Bracket

CB-USB02-RS: Dual Ports USB Cable with Bracket

32100-088600-RS/ 32102-000100-RS/ 32102-000100-200-RS :

SATA Power cable

CF-479B-RS: CPU Cooler

Jumpers setting and Connectors

LABEL FUNCTION

J_CMOS1 Clear CMOS jumper

USB_C01 External USB Connector

USB23

USB45

USB67

USB68

Internal USB Connectors

COM1 External Serial Port DB-9 Connector

COM2 Internal Serial Port Connector

VGA1 On Board VGA DB-15 Connector

LAN1

LAN2

LAN3

LAN4

LAN Connectors with Bypass Function

LAN5

LAN6 LAN Connectors without Bypass Function

LAN_LED1 External LAN LED connectors

JEC_SET1 EC Function Setting connector

JSPI2 Flash BIOS/EC FW SPI ROM connector

SATA1

SATA2

SATA3 Serial ATA Connectors

CPU_FAN1

SYS_FAN1 CPU / System Fan Connectors

F_PANEL1 PWR、RST Buttons、Indicators and Speaker

CPU12V1 +12V CPU Power Input Connector

ATX1 ATX Power Input Connector

CF1 Compact Flash Slot

PCI1 PCI Slot

BAT1 Battery connector

DIMM1

DIMM2 DDR2 DIMM Slots

J_CMOS1: Clear CMOS Jumper

JP3 DESCRIPTION

1-2

(default) Normal Operation

2-3 Clear CMOS Setup

USB23,USB45,USB67,USB68:

Internal USB Connectors

PIN DESCRIPTION PIN DESCRIPTION

1 VCC(+5V) 2 GND

3 DATA- 4 DATA+

5 DATA+ 6 DATA-

7 GND 8 VCC(+5V)

JSPI2: Flash BIOS/EC FW SPI ROM Connector

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 +3.3V 5 GND

2 CS0# 6 CLK

3 SO0 7 SI

4 N/C 8 N/C

COM2 :

Internal Serial Port Connector (RS-232)

PIN DESCRIPTION PIN DESCRIPTION

1 DCD# 6 DSR#

2 RXD 7 RTS#

3 TXD 8 CTS#

4 DTR# 9 VCC(+5V)

5 GND 10 NC

CPU12V1:+12V CPU Power Input Connector

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 GND 2 GND

3 +12V 4 +12V

CPU_FAN1,SYS_FAN1:

FAN Connectors

PIN DESCRIPTION

1 GND

2 +12V

3 Rotation Signal

4 Control

BAT1 :

Battery Connector

PIN DESCRIPTION

1 BAT+ (+3.3V)

2 BAT- (GND)

F_PANEL1 : PWR、RST Buttons、Indicators and Speaker

PIN DESCRIPTION PIN DESCRIPTION

1 Power LED+ 2 Speaker+

3 N/C 4 N/C

Power

LED 5 Power LED- 6 N/C

7 PWRBTN+ 8 Speaker-

Speaker

PWRBTN 9 PWRBTN- 10 N/C

11 HDLED+ 12 Reset+

HDDLED 13 HDLED- 14 Reset - RESET

JEC_SET1: EC Function Setting Connector

By-Pass Mode/Normal Mode Selection

JEC_SET1(1 – 2)

By-Pass Mode

(Default) Short(Hi)

Normal Mode Open(Low)

JEC_SET1: EC Function Setting Connector

SMBUS ID Selection

JEC_SET1

(3 – 4) JEC_SET1

(5 – 6) JEC_SET1

(7 – 8)

0x60 Open(Low) Open(Low) Open(Low)

0x62 Open(Low) Open(Low) Short(Hi)

0x64 Open(Low) Short(Hi) Open(Low)

0x68 Short(Hi) Open(Low) Open(Low)

0x6A Short(Hi) Open(Low) Short(Hi)

0x6C Short(Hi) Short(Hi) Open(Low)

0x6E

(Default) Short(Hi) Short(Hi) Short(Hi)

System software can send command to Network Bypass MCU through

SMBUS. This jumper selects SMBUS slave address for it.

LAN_LED1: External LAN LED connectors

PIN DESCRIPTION PIN DESCRIPTION

1 CN_L1_LINK_ACT# 14 CN_L1_LED

2 CN_L1_100# 15 CN_L1_1000#

3 CN_L2_LINK_ACT# 16 CN_L2_LED

4 CN_L2_100# 17 CN_L2_1000#

5 CN_L3_LINK_ACT# 18 CN_L3_LED

6 CN_L3_100# 19 CN_L3_1000#

7 CN_L4_LINK_ACT# 20 CN_L4_LED

8 CN_L4_100# 21 CN_L4_1000#

9 CN_L5_LINK_ACT# 22 CN_L5_LED

10 CN_L5_100# 23 CN_L5_1000#

11 CN_L6_LINK_ACT# 24 CN_L6_LED

12 CN_L6_100# 25 CN_L6_1000#

13 N/C 26 N/C

JEC_SET1: EC Function Setting Connector

ACK Count

JEC_SET1

(9 – 10) JEC_SET1

(11 – 12) JEC_SET1

(13 – 14) JEC_SET1

(15 – 16)

1 Second Open(Low) Open(Low) Open(Low) Open(Low)

2 Second Open(Low) Open(Low) Open(Low) Short(Hi)

3 Second Open(Low) Open(Low) Short(Hi) Open(Low)

4 Second Open(Low) Open(Low) Short(Hi) Short(Hi)

5 Second Open(Low) Short(Hi) Open(Low) Open(Low)

6 Second Open(Low) Short(Hi) Open(Low) Short(Hi)

…

16 Second

(Default) Short(Hi) Short(Hi) Short(Hi) Short(Hi)

This jumper sets counting-down interval for SMBUS monitoring.

JEC_SET1: EC Function Setting Connector

HW MCU(EC) Enable/Disable

JEC_SET1(19 – 20)

Enable

(Default) Short(Hi)

Disable Open(Low)

LAN Connectors & Bypass Function

•LAN Bypass Definition

LAN Bypass feature removes a single point of failure so that

essential business communication can continue while a

network failure is diagnosed and resolved. In the event of a

power, hardware or software failure, Hardware Bypass will

automatically activate, allowing network traffic to continue.

Traffic between the LAN and WAN is allowed without

interruption.
