iHome iWBT1 Manuale utente
instruction manual
Model: iWBT1
Questions? Contact Customer Service at 1-800-288-2792
CHARGE
BEFORE
USE
Bluetooth
Clip-On Speaker
with rechargeable battery
and speakerphone
iWBT1 IB (English)
Size: 90 x 120 mm
Color: 1C + 1C (Black text on white paper)
Date: Jun. 11, 2015
1
Contents
What’s Included ................................................................. 2
Controls & Indicators.......................................................3
Getting Started: Charging ............................................4
Using the Universal Bracket.........................................5
Pairing a Device .............................................................6-7
Listening to Bluetooth Audio......................................7
Aux-out Audio via Bluetooth ......................................8
Using the Speakerphone...............................................9
Consumer Product Safety......................................10-11
FCC Information ...............................................................12
Troubleshooting............................................................... 13
Warranty.............................................................................. 14
2
Introduction
Thank you for purchasing the iHome iWBT1 Bluetooth
rechargeable clip-on speaker. This product is designed
for high quality wireless audio on the go.
Please read these instructions fully and save for future
reference.
What’s included
• iWBT1 Bluetooth Clip-On Speaker
• USB charge cable
• Universal bracket
• Travel pouch
USB charging
cable
iWBT1 Bluetooth
Clip-on Speaker
Universal bracket
Travel pouch
3
Controls and indicators
TOP
BOTTOM RIGHT
Multi Function Button
Volume Up/
Next Track Button
Volume Down/
Previous Track
Button
LED Indicator
Microphone
Speaker
Audio out/
Charge Port
4
Getting Started
CHARGING
Charge unit before use.
For first time use, charge for about 3 hours.
1. Move the cover from the Audio/Charging Port
and connect the 3.5mm plug on the included
charging cable.
2. Connect the USB end of the charging cable to a
USB power source, such as a computer or USB
adaptor. The LED indicator turns RED while the
unit is charging then turns off when charging is
complete. Unit can operate up to 8 hours once
fully charged.
Computer USB port
Computer
connected to
working outlet
NOTE: to save battery power, the unit will
power off automatically after 5 minutes if no
audio is detected.
5
Getting Started
USING THE UNIVERSAL BRACKET
1. Insert Universal Bracket into opening slot of unit
as shown
2. Clip unit with bracket inserted to desired flat
surface (car visor, etc.) making sure controls are
accessible.
6
Using Bluetooth
PAIRING A DEVICE
Pairing is the set-up process to introduce your
Bluetooth-capable device to the iWBT1. Once your
device is paired, the iWBT1 can recognize it and you
can play your audio through it.
1. Turn on your Bluetooth device and make it
discoverable by turning on Bluetooth mode
(check in Options or Settings on device).
2.
Make sure unit is OFF. Press and hold the
Multi-function Button for 8 seconds. The LED
indicator will flash blue and red and tones will
sound, indicating pairing attempt.
3. “iHome iWBT1” should appear on your device’s
Bluetooth menu. Tap to select. If prompted for
a password, enter “1234”.
4. When pairing is successful, 2 beeps will sound
and the LED indicator will flash 3 times every 4
seconds indicating the iWBT1 is ready to play
music. There should also be an indication on
your device.
8 SECS
7
Using Bluetooth
PAIRING A DEVICE (continued)
LISTENING TO BLUETOOTH AUDIO
• If no device is paired within 3 minutes the iWBT1
will default to previous mode.
•
Once the iWBT1 is paired to a device, it will
attempt to connect to the most recently paired
device when the device is within range (about
30 feet).
•
If no device is connected, press the
Multi-function Button to attempt to connect to
last connected device.
• To pair with other devices, follow steps above.
1. Press and hold the Multi-function Button for 4
seconds to turn the iWBT1 ON. The LED
indicator will flash blue and a tone will sound.
2.
Tap the Multi-function Button to play the
current track on your device, and again to pause.
3.
Tap the – or + Buttons to lower or raise speaker
volume. Hold longer for previous or next track.
4.
Press and hold the Multi-function Button for 4
seconds to turn the iWBT1 OFF. The LED
indicator will flash red and a tone will sound.
4 SECS 4 SECS
ON PLAY OFF
8
Using Bluetooth
AUX OUT AUDIO VIA BLUETOOTH
Stream audio to iWBT1 connected via audio cable to speaker
The iWBT1 allows you to play music from your paired
Bluetooth device through any speaker or audio
device that has a standard 3.5mm aux line-in jack.
1. Connect a standard 3.5 mm audio cable (not
included) from the Audio Out/Charge Port on the
iWBT1 to the aux/line-in jack on the speaker.
Turn on the speaker and adjust volume to mid level.
2. Follow directions under “Listening to Bluetooth
Audio” on the preceding page to play, pause and
navigate tracks. You may be able to use controls
on your speaker, too.
3. Press and hold the Multi-function Button for 4
seconds to turn the iWBT1 OFF. The LED
indicator will flash red and a tone will sound.
TIP: Plug in any headphone for stereo audio
9
USING THE SPEAKERPHONE
The iWBT1 allows you to answer, end and ignore
calls, mute calls, transfer calls between a paired
phone and the unit, and to switch between calls.
1. Press and hold the Multi-function Button for 4
seconds to turn the iWBT1 ON. The LED indicator
will flash blue and a tone will sound.
• To answer a call, tap the Multi-function Button.
Tap again to end the call.
• To ignore a call, press and hold the Multi-function
Button for 2 seconds
• To transfer an active call from iWBT1 to your
phone, press and hold the Multi-function Button
for 2 seconds. Repeat to transfer it back to
iWBT1.
• Call waiting: To place a current call on hold and
answer a new one, double click the
Multi-function Button. Repeat to switch back to
the first call.
•
To mute the microphone, double click the
Multi-function Button. Repeat to unmute
• To adjust speaker volume, tap the – or + Buttons
2.
Press and hold the Multi-function Button for 4
seconds to turn the iWBT1 OFF. The LED
indicator will flash red and a tone will sound.
