Ikan RECOIL-RLD Manuale utente

RECOIL-RLD

RECOIL RELOADED Camera Stabilizer QUICKSTART GUIDE

Whats included

www.ikancorp.com 713-272-8822

Checked by

Recoil Body

Long Baseplate

Short Riser Baseplate

Rubber Grip Bar (ELE-GB-R & ELE-GB-135)

Long Thumb Screw

Safety Strap

2 x Cork Strips

RECOIL-RLD

RECOIL RELOADED Camera Stabilizer QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

For smaller cameras, the Short Riser Baseplate and Grip Bar can be added as shown.

DSLR camera mounted on the

Short Riser Baseplate with

Rubber Grip Bar.

Long Thumb Screw

Long Baseplate

Rubber Grip Bar

Buckle

Adjustable Strap

Short Riser Baseplate

RECOIL-RLD

RECOIL RELOADED Camera Stabilizer QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.

• The components and maintenance service fee will be charged if the warranty period has expired.

Free Service will not be Provided in the Following Situations: (** Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.

Panasonic camera mounted on the Long Baseplate.

(For certain Panasonic cameras the included camera screw

may be too long to properly hold the camera. For this reason

we have included two strips of cork to place on the recoil base

to lift the camera to the proper height.)

Larger cameras can be utilized with either the Short Riser Baseplate or the Long Baseplate.

Some camera may need a small washer to completely snug the camera to the Long Baseplate.

Canon camera mounted on the

Short Riser Baseplate.

Chest plate can be folded or extended as necessary to

accommodate different body sizes. Adjustable tension knob

controls the amount of give in the plate. Turn clockwise to

tighten or counter clockwise to loosen – When transporting,

fold the chest plate into the shoulder pad and tighten the

tension knob.
