IKEA SKINANDE Manuale utente
SKINANDE
GB
ENGLISH
Please refer to the last page of this manual for the full list of IKEA
appointed After Sales Service Provider and relative national phone
numbers.
ENGLISH 4
Contents
Safety information 4
Safety instructions 5
Product description 7
Control panel 8
Programmes 8
Options 9
Settings 10
Before first use 12
Daily use 14
Hints and tips 15
Care and cleaning 16
Troubleshooting 18
Technical information 21
ENVIRONMENTAL CONCERNS 22
IKEA GUARANTEE 22
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damages that are the result of incorrect
installation or usage. Always keep the instructions in a safe and
accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Do not let children play with the appliance.
•Keep detergents away from children.
•Keep children and pets away from the appliance door when
it is open.
•Children shall not carry out cleaning and user maintenance of
the appliance without supervision.
ENGLISH 4
General Safety
•This appliance is intended to be used in household and
similar applications such as:
–farm houses; staff kitchen areas in shops, offices and other
working environments;
–by clients in hotels, motels, bed & breakfast and other
residential type environments.
•Do not change the specification of this appliance.
•The operating water pressure (minimum and maximum) must
be between 0.5 (0.05) / 8 (0.8) bar (MPa)
•Obey the maximum number of 13 place settings.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
•Put knives and cutlery with sharp points in the cutlery basket
with the points down or in a horizontal position.
•Do not keep the appliance door open without supervision to
prevent to fall on it.
•Before any maintenance operation, deactivate the appliance
and disconnect the mains plug from the socket.
•Do not use high pressure water sprays and/or steam to clean
the appliance.
•The ventilation openings in the base (if applicable) must not
be obstructed by a carpet.
•The appliance is to be connected to the water mains using
the new supplied hose-sets. Old hose sets must not be
reused.
Safety instructions
Installation
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance where
the temperature is less than 0 °C.
• Follow the installation instruction
supplied with the appliance.
• Make sure that the appliance is installed
below and adjacent to safe structures.
ENGLISH 5
Electrical connection
Warning! Risk of fire and
electrical shock.
• The appliance must be earthed.
• Make sure that the electrical information
on the rating plate agrees with the
power supply. If not, contact an
electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by our
Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains
plug.
• This appliance complies with the E.E.C.
Directives.
• Only for UK and Ireland. The appliance
has a 13 amp mains plug. If it is
necessary to change the fuse in the
mains plug, use fuse: 13 amp ASTA (BS
1362).
Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let the
water flow until it is clean and clear.
• Ensure that there are no visible water
leaks during and after the first use of the
appliance.
• The water inlet hose has a safety valve
and a sheath with an inner mains cable.
Warning! Dangerous voltage.
• If the water inlet hose is damaged,
immediately close the water tap and
disconnect the mains plug from the mains
socket. Contact the Authorised Service
Centre to replace the water inlet hose.
Use
• Do not sit or stand on the open door.
• Dishwasher detergents are dangerous.
Obey the safety instructions on the
detergent packaging.
• Do not drink and play with the water in
the appliance.
• Do not remove the dishes from the
appliance until the programme is
completed. There can be detergent on
the dishes.
• The appliance can release hot steam if
you open the door while a programme
operates.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
Service
• Contact the Authorised Service Centre to
repair the appliance. We recommend
only the use of original spare parts.
• When you contact the Authorised Service
Centre, ensure that you have the
following information that is available on
the rating plate.
Model :
PNC :
Serial Number :
ENGLISH 6
Disposal
Warning! Risk of injury or
suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
Product description
8
7
6
5
4
1
3
2
1Lower spray arm
2Filters
3Rating plate
4Rinse aid dispenser
5Detergent dispenser
6Salt container
7Upper spray arm
8Upper basket
Beam-on-Floor
The Beam-on-Floor is a light that is
displayed on the floor below the appliance
door.
• When the programme starts, a red light
comes on and stays on for the duration
of the programme.
• When the programme is completed, a
green light comes on.
• When the appliance has a malfunction,
the red light flashes.
The Beam-on-Floor goes off
when the appliance is
deactivated.
ENGLISH 7
Control panel
1 2 4 53
1On/off button
2Display
3Delay button
4Programme buttons
5Indicators
Indicators
Indicator Description
Multitab indicator.
Rinse aid indicator. It is always off while the programme operates.
Salt indicator. It is always off while the programme operates.
Programmes
Programme Degree of soil
Type of load
Programme pha-
ses
Consumption values
1)
Duration
(min)
Energy
(kWh)
Water
(l)
2) All
Crockery, cut-
lery, pots and
pans
• Prewash
• Wash from 45
°C to 70 °C
• Rinses
• Dry
40 - 150 0.6 - 1.4 7 - 12
3) Heavy soil
Crockery, cut-
lery, pots and
pans
• Prewash
• Wash 70 °C
• Rinses
• Dry
140 - 160 1.3 - 1.5 13 - 15
ENGLISH 8
Programme Degree of soil
Type of load
Programme pha-
ses
Consumption values
1)
Duration
(min)
Energy
(kWh)
Water
(l)
4) Fresh soil
Crockery and
cutlery
• Wash 60 °C or
65 °C
• Rinses
30 0.9 9
5) Normal soil
Crockery and
cutlery
• Prewash
• Wash 50 °C
• Rinses
• Dry
195 0.932 9.9
6) All • Prewash 14 0.1 4
1)
The pressure and the temperature of the water, the variations of the mains supply, the options and the quantity of
dishes can change the values.
2)
The appliance senses the degree of soil and the quantity of items in the baskets, it automatically adjusts the tem-
perature and the quantity of the water, the energy consumption and the programme duration.
3)
Programme with prolonged rinsing time in high temperature for extra hygienic wash-up. Ideal for baby bottles or
when a family member is ill.
4)
With this programme you can wash a load with fresh soil. It gives good washing results in a short time.
5)
With this programme you have the most efficient use of water and energy consumption for crockery and cutlery with
normal soil. (This is the standard programme for test institutes).
6)
Use this programme to quickly rinse the dishes. this prevents the remaining food to bond on the dishes and bad
odours to come out from the appliance. Do not use detergent with this programme.
Information for test institutes
For all the necessary information for test
performance, send an email to:
Write down the product number (PNC) that
is on the rating plate.
Options
Multitab
Activate this option when you use multi-
tablets that integrate the salt, rinse aid and
detergent functions. They can also contain
other cleaning or rinsing agents.
This option deactivates the release of salt.
The salt indicator does not come on.
With the use of this option the programme
duration is prolonged to increase the
cleaning and drying results with the use of
multi-tablets.
You do not need to activate the Multitab
option every time you start a programme.
Once you have activated the option it will
remain active.
How to activate Multitab
Press at the same time and .
ENGLISH 9
• The indicator comes on = option
activated.
• The indicator goes off = option
deactivated.
What to do if you want to stop using multi-
tablets
Before you start to use detergent, salt and
rinse aid separately do the following
procedure.
1. Deactivate the Multitab option.
2. Set the highest level of the water
softener.
3. Make sure that the salt and rinse aid
containers are full.
4. Start the shortest programme with a
rinsing phase. Do not add detergent
and do not load the baskets.
5. When the programme is completed,
adjust the water softener according to
the water hardness in your area.
6. Adjust the released quantity of rinse aid.
Settings
Programme selection mode and user
mode
When the appliance is in programme
selection mode it is possible to set a
programme and to enter the user mode.
In user mode, the following settings can
be changed:
• The level of the water softener according
to the water hardness.
• The activation or the deactivation of the
acoustic signal for end of programme.
• The activation or deactivation of the
rinse aid dispenser when you want to
use the Multitab option without rinse aid.
These settings will be saved until you
change them again.
How to set the programme selection mode
The appliance is in programme selection
mode when the programme indicator
is on and the display shows the
programme duration.
When you activate the appliance, usually it
is in programme selection mode. However,
if this does not happen, you can set the
programme selection mode in the following
way:
Press and hold simultaneously
and until the appliance is in programme
selection mode.
The water softener
The water softener removes minerals from
the water supply, which would have a
detrimental effect on the washing results
and on the appliance.
The higher the content of these minerals, the
harder your water is. Water hardness is
measured in equivalent scales.
The water softener should be adjusted
according to the hardness of the water in
your area. Your local water authority can
advise you on the hardness of the water in
your area. It is important to set the right
level of the water softener to assure good
washing results.
ENGLISH 10
Altri manuali per SKINANDE
13
Indice
Altri manuali IKEA Lavastoviglie
IKEA
IKEA TILLREDA Manuale utente
IKEA
IKEA W11212416C Manuale utente
IKEA
IKEA RENLIG DW60 Manuale utente
IKEA
IKEA IUD8000R Manuale utente
IKEA
IKEA IUD8000WQ0 Manuale utente
IKEA
IKEA RENODLAD Manuale utente
IKEA
IKEA RENGÖRA Manuale utente
IKEA
IKEA DISKAD Manuale utente
IKEA
IKEA W10532755A Manuale utente
IKEA
IKEA IUD8500BX0 Manuale utente
IKEA
IKEA PROFFSIG Manuale utente
IKEA
IKEA LAGAN Manuale utente
IKEA
IKEA IUD6100YW0 Manuale utente
IKEA
IKEA LAGAN Manuale utente
IKEA
IKEA SKINANDE Manuale utente
IKEA
IKEA DISKAD PROFFSIG Manuale utente
IKEA
IKEA HYGIENISK Manuale utente
IKEA
IKEA RENODLAD Manuale utente
IKEA
IKEA VILLKORLIG Manuale utente
IKEA
IKEA IUD9500VX0 Manuale utente
