Bring acclaimed Infinity sound

to the great outdoors.

INFH1308 Outrigger 12/20/04 9:32 AM Page 1

250 Crossways Park Drive,Woodbury, NY 11797 USA 516.674.4INF (4463) Fax 516.682.3523 www.infinitysystems.com

© 2004 Harman International Industries, Incorporated Printed 12/04 Part No. OUTRIGGERLIT

Designed, edited and digitally produced by Harman Consumer Group Marketing & Design Center, Woodbury, NY.

Infinity is a registered trademark of Harman International Industries, Incorporated.

Infinity continually strives to update and improve existing products, as well as create new ones.

The specifications and construction details herein are therefore subject to change without notice.

OUTRIGGER AND

OUTRIGGER JR.

INDOOR/OUTDOOR/MARINE

LOUDSPEAKERS.

Great for marine use.

SPECIFICATIONS:Outrigger Jr. Outrigger

Frequency Range 80Hz – 20kHz 60Hz – 20kHz

(± 3dB)

Recommended 5 – 60 watts 10 – 80 watts

Amplifier Power Range

Sensitivity 86dB 86dB

(2.8V @ 1 meter)

Nominal Impedance 8 ohms 8 ohms

Low-Frequency Driver 4" (102mm) 5-1/4" (133mm)

High-Frequency Driver 1/2" (13mm) dome tweeter 1" (25mm) dome tweeter

Operating – 4˚F to 140˚ F (–20˚ C to 60˚C) – 4˚F to 140˚F (–20˚ C to 60˚ C)

Specifications at any humidity level at any humidity level

Dimensions 8-1/4" x 6-1/2" x 7" 10" x 8" x 7"

(H x W x D) (210mm x 165mm x 178mm) (254mm x 203mm x 178mm)

Weight 4.4 lb (2kg) 8.2 lb (3.7kg)

Infinity Outrigger outdoor loud-

speakers are an excellent way to

bring acclaimed Infinity sound

to the great outdoors. Enjoying

your favorite music by the pool

or on the boat is easy, thanks to

the Outriggers’ weatherproof design.

These are true two-way systems –

all of the recorded detail and

nuance of music is accurately

reproduced. With waterproof

drivers and rugged, inert-mineral-

filled polypropylene enclosures,

as well as noncorroding aluminum,

brass and stainless-steel parts,

the Outriggers are designed to

handle the rigors of outdoor use

for a long, long time.And they’re

versatile.You can position these

speakers vertically or horizontally

on a wall (using the included

mounting bracket), shelf or table

for any environment or application.

Outrigger and Outrigger Jr. –

get great Infinity sound, rain

or shine, inside or out.

INFH1308 Outrigger 12/20/04 9:32 AM Page 2
