Ingrasys M2210E Manuale utente
M2210E / V
User’s Manual
Version 1.1
Table of Contents
Important Notices – Read Before Use ............................................................................2
Overview.........................................................................................................................2
Package Contents............................................................................................................3
Installation.......................................................................................................................4
Hardware Installation.......................................................................................................................................................4
Software Installation........................................................................................................................................................8
Discover IP Cameras........................................................................................................................................................ 8
Assigning IP Address to the device ................................................................................................................................. 8
Discovering devices in Windows Network.................................................................................................................... 10
ActiveX add-on Installation........................................................................................................................................... 11
Accessing the camera....................................................................................................13
Viewing the live video................................................................................................................................................... 13
The Live view page........................................................................................................................................................ 15
Video.............................................................................................................................17
Network Configuration .................................................................................................24
Recording ......................................................................................................................29
Event management........................................................................................................34
Configuration of Event Handling...................................................................................................................................34
Examples of Event Handling ......................................................................................................................................... 39
System options ..............................................................................................................41
Troubleshooting ............................................................................................................45
Check firmware version................................................................................................................................................. 45
Upgrade device firmware...............................................................................................................................................45
Recover device settings.................................................................................................................................................. 47
LED Indicators............................................................................................................................................................... 48
Technical Specifications ...............................................................................................49
1
Important Notices
– Read Before Use
This instruction manual is intended for administrators and users of the Ingrasys M2210 Series IP Camera,
including instructions for using and managing the camera on your network. The use of video surveillance
devices can be prohibited by laws that vary from country to country. It is the user’s responsibility to ensure
that the operation of such devices is legal before installing this unit for surveillance purposes.
Heed all warnings
Before installing the IP Camera, please read and follow all the safety and operating instructions to avoid any
damages caused by faulty assembly and installation. The user must adhere to all the warnings on the product
and in this manual.
Liability
Every reasonable care has been taken in the preparation of this instruction manual. We cannot be held
responsible for any technical or typographical errors and reserves the right to make alterations to the product
and manuals without prior notice. We make no warranty of any kind with regard to the material contained
within this manual, including, but not limited to, the implied warranties of merchantability and fitness for a
particular purpose. The user should verify the relevant information is current and complete before placing
orders. All products are sold subject to our terms and conditions of sale at the time of order acknowledgement.
We shall not be liable nor responsible for the applications and resale of its products or bundled software with
statements different from or beyond the specification/parameters stated by us. We are under no obligation to
provide any further technical support service or product/software alteration beyond our representation.
Trademarks
All names used in this manual and products are probably registered trademarks of respective companies.
CE/FCC Statement (EMC)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules which are designed to provide reasonable protection against such interference
when the equipment is operated in a commercial environment. If the equipment is not installed and used in
accordance with the instruction, it generates, uses, and can radiate radio frequency energy which may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause interference, in which case the user at his/her own expense will be required to take whatever measures
may be required to correct the interference.
Overview
Ingrasys M2210 Series is a Full HD, compact IP camera specially designed for buses, trains, and other
vehicles applications. The camera comes with 3-axis mechanism design that allows users to adjust the
camera's viewing angle for increased installation flexibility.
Capable of rugged RJ/M12 Ethernet connector & IP67-rated housing can against shock, vibration, humidity
and dust. The M2210 Series is also embedded with 802.3af compliant PoE, ePTZ and all-in-one mechanism
for easy installation.
2
Package Contents
M2210(E/V) Product CD Quick Installation Guide
Warranty Card Lens Tool VIP Card (Optional)
Hardware Pack
3
Installation
Hardware Installation
Connectors
Connections
Connect the camera to a PoE switch with an Ethernet cable.
4
Install RJ-45 Field Installable Feed-Through Adaptor for M2210E
Assemble RJ-45 field installable through adaptor to achieve system waterproof and vibration proof.
1. Assemble the through the field installable feed-through
adaptor and insert a stripped Ethernet cable.
2. Follow the pin definition to crimp the RJ-45 plug onto
the cable.
3. Connect to M2210E RJ-45 rugged Connector and fully
seal the connector to achieve waterproof and vibration
proof completely.
Install M12 Field Installable Feed-Through Adaptor for M2210V
Assemble M12 field installable through adaptor to achieve system waterproof and vibration proof.
1. Insert a stripped Ethernet cable through the Sealing Nut and Housing of the field installable feed-through
adaptor.
2. Follow the pin definition to weld the cable to the connector.
5
3. Connect to M2210V M12 rugged connector and fully seal the connector to achieve waterproof and vibration
proof completely
Mount Camera
1.
Alignment Sticker on drill holes
2.
Loosen 2 screws and remove the top cover
3. Route the Ethernet cable through the hole and fasten camera on the surface with 4 screws
6
Tuning lens direction and focus
1. Fit the lens adjustment tool to the lens holder to adjust the direction of the lens. The tilt range
is 0°~90° and the pan range is ±60°.
2. Pull out the lens adjustment tool, and turn it around to fit the lens to adjust focus.
3. Replace the top cover to finish installation.
7
Software Installation
Discover IP Cameras
Discovery Tool is a utility provided for not only searching and displaying the available IP cameras information
in a network but also managing the multiple networking settings such as static IP address assignment.
After completing the hardware installation, run ingrasysDiscovery.exe to search for the IP camera installed.
Assigning IP Address to the device
The steps of applying this search tool are described as below.
1. Launch IPCAM Discovery Tool (ingrasysDiscovery.exe)
2. Assign IP address
The selection is based on a single or multiple camera devices.
[Set IP]
This is applied to one specific camera selected from the Device List.
Step1: Select one specific camera device
8
Step2: Input desired IP information
The default settings of account /password are Admin / Admin. If that were been changed, please
enter the set values.
[Auto Set IP]
This is applied to a group of specific cameras selected from the Device List.
Step1: Select specific cameras
Step 2: Input Account / Password
The default account information is Admin / Admin. If the values have been re-set, please enter the
set values.
9
