Intel NUC 11 Performance Manuale utente

Intel® NUC 11 Enthusiast Kit - NUC11PHKi7C

Intel® NUC 11 Enthusiast Mini PC - NUC11PHKi7CAA

User Guide

You may not use or facilitate the use of this document in connection with any infringement or other legal analysis concerning Intel products

described herein. You agree to grant Intel a non-exclusive, royalty-free license to any patent claim thereafter drafted which includes subject

matter disclosed herein.

No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document.

All information provided here is subject to change without notice. Contact your Intel representative to obtain the latest Intel product

specifications and roadmaps.

The products described may contain design defects or errors known as errata which may cause the product to deviate from published

specifications. Current characterized errata are available on request.

Copies of documents which have an order number and are referenced in this document may be obtained by calling 1-800-548-4725 or by

visiting: http://www.intel.com/design/literature.htm.

Intel technologies' features and benefits depend on system configuration and may require enabled hardware, software or service activation.

Performance varies depending on system configuration. No computer system can be absolutely secure.

Intel and the Intel logo are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries.

*Other names and brands may be claimed as the property of others.





Contents
0 Introduction ....................................................................................................................... 5
1 Before You Begin ...........................................................................................................................................5
2 Installation Precautions.............................................................................................................................6
3 Observe Safety and Regulatory Requirements.........................................................................6
0 Open the Chassis ............................................................................................................. 7
0 System Memory ................................................................................................................ 8
0 Change the M.2 SSD ..................................................................................................... 11
0 Close the Chassis ........................................................................................................... 13
0 Attaching and using the VESA Bracket (Optional)........................................ 14
0 Connect Power ................................................................................................................ 16
0 Install an Operating System .................................................................................... 18
0 Install the Latest Device Drivers and Software.............................................. 19




Revision History

Date

Revision

Description

1.0

Initial release.

1.0 Introduction

This User Guide provides step-by-step installation instructions for these products:

•Intel® NUC 11 Enthusiast Kit - NUC11PHKi7C

•Intel® NUC 11 Enthusiast Mini PC - NUC11PHKi7CAA

1.1 Before You Begin

CAUTIONS

The steps in this guide assume you’re familiar with computer terminology and

with the safety practices and regulatory compliance required for using and

modifying computer equipment.

Disconnect the computer from its power source and from any network before

performing any of the steps described in this guide.

Failure to disconnect power, telecommunications links, or networks before you open

the computer or perform any procedures can result in personal injury or equipment

damage. Some circuitry on the board can continue to operate even though the front

panel power button is off.

Follow these guidelines before you begin:

•Always follow the steps in each procedure in the correct order.

•Create a log to record information about your computer, such as model,

serial numbers, installed options, and configuration information.

•Electrostatic discharge (ESD) can damage components. Perform the

procedures described in this chapter only at an ESD workstation using an

antistatic wrist strap and a conductive foam pad. If such a station isn’t

available, you can provide some ESD protection by wearing an antistatic wrist

strap and attaching it to a metal part of the computer chassis.

1.2 Installation Precautions

When you install and test the Intel NUC, observe all warnings and cautions in the

installation instructions.

To avoid injury, be careful of:

•Sharp pins on connectors

•Sharp pins on circuit boards

•Rough edges and sharp corners on the chassis

•Hot components (such as SSDs, processors, voltage regulators, and heat sinks)

•Damage to wires that could cause a short circuit

Observe all warnings and cautions that instruct you to refer computer servicing

to qualified technical personnel.

1.3 Observe Safety and Regulatory Requirements

If you don’t follow these instructions, you increase your safety risk and the possibility

of noncompliance with regional laws and regulations.

2.0 Open the Chassis

1. Unscrew the 8 screws on the top side of the chassis (A) and lift the cover (B):

2. Unscrew the 5 screws on the metal plate (C) and lift it (D):

3.0 System Memory

Intel® NUC 11 Enthusiast Kit - NUC11PHKi7C and Intel® NUC 11 Enthusiast Mini PC -

NUC11PHKi7CAA have two DDR4 SO-DIMM sockets. Be sure to select memory

modules that meet these requirements:

•1.2V low voltage memory

•3200/2666MHz SO-DIMMs

•Max capacity - 64GB

•Non-ECC

Find compatible memory modules in the Intel Product Compatibility Tool

•NUC11PHKi7C

•NUC11PHKi7CAA

NOTE

If you plan to install only one memory module, install it in the upper

memory socket.

To install memory, follow these steps:

1. Observe the precautions in "Before You Begin" on page 5.

2. Turn off all peripheral devices connected to the computer. Turn off the

computer and disconnect the power cord.

3. Remove the computer’s top chassis cover and metal plate as described on

page 7 (section 2.0)

4. Align the small space at the bottom edge of the memory module with the key

in the socket.

5. Insert the bottom edge of the module at a 45-degree angle into the socket

(A).

6. When the module is inserted, push down on the outer edge of module until

the retaining clips snap into place (B). Make sure the clips are firmly in place

(C).

To remove a SO-DIMM, follow these steps:

1. Observe the precautions in "Before You Begin" on page 5.

2. Turn off all peripheral devices connected to the computer. Turn off the

computer and disconnect the power cord.

3. Remove the computer’s top chassis cover and metal plate.

4. Gently spread the retaining clips at each end of the memory socket, which

causes the module to pop out of the socket (C).

5. Holding the module by the edges, lift it away from the socket, and store it in an

anti-static package.

6. Reinstall and reconnect any parts you removed or disconnected to reach the

memory sockets.

7. Replace the computer’s cover and reconnect the power cord.
