Intel DG33TL Manuale utente

Intel® Desktop Board

DG33TL

Specification Update

May 2008

Order Number E11661-003US

The Intel®Desktop Board DG33TL may contain design defects or errors known as errata, which may cause the product to deviate

from published specifications. Current characterized errata are documented in this Specification Update.

2 Intel Desktop Board DG33TL Specification Update

Revision History

Revision Revision History Date

-001 This document is the first Specification Update for the Intel®Desktop

Board DG33TL. June 4, 2007

-002 Added Specification Changes 1 & 2 and updated General Information

Table. September 2007

-003 Updated General Information and Specification Changes Sections. May 2008

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS

GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR

SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR

IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR

WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT

OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT

INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”

or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for

conflicts or incompatibilities arising from future changes to them.

The Intel®Desktop Board DG33TL may contain design defects or errors known as errata which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your

product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel

literature, may be obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel, the Intel logo, Intel Core, Pentium, and Celeron are trademarks of Intel Corporation in the United

States and other countries.

* Other names and brands may be claimed as the property of others.

Intel Desktop Board DG33TL Specification Update 3

Contents

Specification Update for the Intel®Desktop Board DG33TL

Terminology ............................................................................................ 5

General Information .................................................................................5

Summary of Changes ............................................................................... 6

Specification Changes...............................................................................6

4 Intel Desktop Board DG33TL Specification Update

Specification Update for the

Intel®Desktop Board DG33TL

This document is an update to the specifications contained in the Intel ®Desktop Board

DG33TL Technical Product Specification (Order Number: D95738). It is intended for

hardware system manufacturers and software developers of applications, operating

systems, or tools. It will contain Specification Changes, Errata, Specification

Clarifications, and Documentation Changes.

For specification updates concerning the Intel processor that may apply to this desktop

board, refer to the following:

•Intel®Core™2 Extreme Quad-Core Processor QX6000ΔSequence and Intel®

Core™2 Quad Processor Q6000ΔSequence Specification Update

(Order Number: 315593)

•Intel®Core™2 Extreme Processor X6800∆and Intel®Core™2 Duo Desktop

Processor E6000∆and E4000∆Sequence Specification Update (Order Number:

313279)

•Intel®Pentium®Dual-Core Desktop Processor E2000ΔSequence Specification

Update (Order Number: 316982)

•Intel®Celeron®Processor 400ΔSequence Specification Update

(Order Number: 316964)

Unless otherwise noted in this document, it should be assumed that any processor

errata for a given stepping are applicable to the Altered Assembly (AA) revision(s)

associated with that stepping.

Refer to the Intel®G33 Chipset Specification Update (Order Number: 316967) for

specification updates concerning the 82G33 GMCH Controller and that may apply to

the desktop board DG33TL. Unless otherwise noted in this document, it should be

assumed that any MCH errata for a given stepping are applicable to the Altered

Assembly (AA) revision(s) associated with that stepping.

Refer to the Intel®IO Controller Hub9 (ICH9) Family Specification Update (Order

Number: 316973) for specification updates concerning the 82801IR I/O Controller Hub

and that may apply to the desktop board DG33TL. Unless otherwise noted in this

document, it should be assumed that any ICH9 errata for a given stepping are

applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Intel Desktop Board DG33TL Specification Update 5

Terminology

Specification Changes are modifications to the current published specifications.

These changes will be incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop

board behavior to deviate from published specifications. Hardware and software

designed to be used with any given Altered Assembly (AA) and BIOS revision level

must assume that all errata documented for that AA and BIOS revision level are

present on all desktop boards.

Specification Clarifications describe a specification in greater detail or further

highlight a specification’s impact to a complex design situation. These clarifications

will be incorporated in the next release of the specifications.

Documentation Changes include typos, errors, or omissions from the current

published specifications. These changes will be incorporated in the next release of the

specifications.

General Information

Basic Desktop Board DG33TL Identification Information

AA Revision BIOS Revision Notes

D89517-600 DPP3510J.86A.0216 1,2

D89517-700 DPP3510J.86A.0216 1,2

D89517-801 DPP3510J.86A.0216 1,2

D89517-802 DPP3510J.86A.0216 1,2

D89517-803 DPP3510J.86A.0293 1,2

D89517-804 DPP3510J.86A.0413 1,2

Notes:

1. The AA number is found on a small label on the component side of the board.

2. The G33 Chipset kit used on this AA revision consists of two components as follows:

Device Stepping S-Spec Numbers

82G33 A2 SLA9Q

82801IR A2 SLA9N

6 Intel Desktop Board DG33TL Specification Update

Summary of Changes

The following table indicates the Specification Changes, Errata, Specification

Clarifications, or Documentation Changes that apply to the Intel®Desktop Board

DG33TL. Intel intends to fix some of the errata in a future revision of the desktop

board, and to account for the other outstanding issues through documentation or

specification changes as noted.

The following notations are used in the table:

Doc: Document change or update that will be implemented.

PlanFix: This erratum may be fixed in a future revision of the desktop board, driver, or BIOS.

Fixed: This erratum has been previously fixed.

NoFix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the document.

No. Plans Specification Changes

1 Doc Table 1 of the technical specification will be updated to add the word “Micro” before

ATX in Form Factor.

2 Doc Section 2.4.1 of the technical specification will be updated to add the word “Micro”

before ATX.

3 Doc Section 1.6.3.3 has been added to the technical specification.

No. Plans Errata

There are no characterized erratum for this product

Specification Changes

The Specification Changes listed in this section apply to the Intel®Desktop Board

DG33TL Technical Product Specification (Order Number: D95738). All Specification

Changes will be incorporated into a future version of that specification.

1. Table 1 of the technical specification will be updated to add the word “Micro” before

ATX in Form Factor.

Form Factor Micro ATX (9.60 inches by 9.60 inches [243.84 millimeters by 243.84

millimeters]

2. Section 2.4.1 of the technical specification will be updated to add word “Micro”

before ATX.

2.4.1 Form Factor

The board is designed to fit into a Micro ATX-form-factor chassis.

Intel Desktop Board DG33TL Specification Update 7

3. Section 1.6.3.3 has been added to the Technical Specification.

1.6.3.3 Intel®Rapid Recover Technology

The Intel®Desktop Board DG33TL incorporates the Intel®Rapid Recover Technology.

Intel Rapid Recover Technology is a feature of Intel®Matrix Storage Manager. It

uses RAID 1 (mirroring) functionality to copy data from a designated master drive to

a designated recovery drive. The master drive data can be copied to the recovery

drive either continuously or on request.

When using the continuous update policy, changes made to the data on the master

drive while the recovery drive is disconnected or offline are automatically copied to

the recovery drive when it is reconnected. When using the on request update policy,

the master drive data can be restored to a previous state by copying the data on the

recovery drive back to the master drive. The table below provides an overview of the

advantages, disadvantages, and the typical usage of Intel Rapid Recover Technology.

Hard Drives Required 2

Advantage More control over how data is copied between master and recovery drives;

fast volume updates (only changes to the master drive since the last update

are copied to the recovery drive); member hard drive data can be viewed in

Microsoft Windows* Explorer.

Disadvantage No increase in volume capacity.

Application Critical data protection; fast restoration of the master drive to a previous or

default state.
