Intel DG965WH Manuale utente

Intel® Desktop Board

DG965WH

Specification Update

March 2008

Order Number: D63340-004US

The Intel®Desktop Board DG965WH may contain design defects or errors known as errata, which may cause the product to deviate

from published specifications. Current characterized errata are documented in this Specification Update.

2 Intel Desktop Board DG965WH Specification Update

Revision History

Revision Revision History Date

-001 This document is the first Specification Update for the Intel®Desktop

Board DG965WH.

August 2006

-002 Added Specification Changes 1. October 2006

-003 Added Specification Changes 2. January 2007

-004 Updated the General Information Section. March 2008

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS

GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR

SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR

IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR

WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT

OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT

INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”

or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for

conflicts or incompatibilities arising from future changes to them.

The Intel®Desktop Board DG965WH may contain design defects or errors known as errata which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your

product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel

literature, may be obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel, the Intel logo, Intel Core, Pentium, and Celeron are trademarks of Intel Corporation in the U.S. and

other countries.

* Other names and brands may be claimed as the property of others.

Intel Desktop Board DG965WH Specification Update 3

Contents

Specification Update for the Intel®Desktop Board DG965WH

Terminology ............................................................................................ 5

General Information ................................................................................. 5

Summary Table of Changes ....................................................................... 6

Codes Used in Summary Table ............................................................ 6

Specification Changes ............................................................................... 6

1.8.1 Intel®82566DC Gigabit Ethernet Controller................................ 6

4 Intel Desktop Board DG965WH Specification Update

Specification Update for the

Intel®Desktop Board DG965WH

This document is an update to the specifications contained in the Intel®Desktop Board

DG965WH Technical Product Specification (Order Number D56008). It is intended for

hardware system manufacturers and software developers of applications, operating

systems, or tools. It will contain Specification Changes, Errata, Specification

Clarifications, and Documentation Changes.

For specification updates concerning the Intel®processor that may apply to this

desktop board, refer to the following:

•Intel®Core™2 Extreme Processor X6800∆and Intel®Core™2 Duo Desktop

Processor E6000∆Sequence Specification Update (Order Number 313279)

•Intel®Pentium®4 Processor 6x1∆Sequence Specification Update (Order

Number 310309)

•Intel®Pentium®4 Processor on 90 nm Process Specification Update (Order

Number 302352)

•Intel®Pentium®4 Processor Specification Update (Order Number 249199)

Unless otherwise noted in this document, it should be assumed that any processor

errata for a given stepping are applicable to the Altered Assembly (AA) revision(s)

associated with that stepping.

Refer to the Intel®P965 Broadwater Chipset Specification Update (Order Number

313054) for specification updates concerning the 82G965 MCH Controller and that may

apply to the desktop board DG965WH. Unless otherwise noted in this document, it

should be assumed that any MCH errata for a given stepping are applicable to the

Altered Assembly (AA) revision(s) associated with that stepping.

Refer to the Intel

®IO Controller Hub8 (ICH8) Family Specification Update (Order

Number 313057) for specification updates concerning the 82801HH I/O Controller Hub

and that may apply to the desktop board DG965WH. Unless otherwise noted in this

document, it should be assumed that any ICH8 errata for a given stepping are

applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Intel Desktop Board DG965WH Specification Update 5

Terminology

Specification Changes are modifications to the current published specifications.

These changes will be incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop

board behavior to deviate from published specifications. Hardware and software

designed to be used with any given Altered Assembly (AA) and BIOS revision level

must assume that all errata documented for that AA and BIOS revision level are

present on all desktop boards.

Specification Clarifications describe a specification in greater detail or further

highlight a specification’s impact to a complex design situation. These clarifications

will be incorporated in the next release of the specifications.

Documentation Changes include typos, errors, or omissions from the current

published specifications. These changes will be incorporated in the next release of the

specifications.

General Information

Basic Desktop Board DG965WH Identification Information

AA Revision BIOS Revision Notes

D41692-304 MQ96510J.86A.0816 1,2

D41692-305 MQ96510J.86A.1612 1,2

D41692-306 MQ96510J.86A.1612 1,2

D41692-307 MQ96510J.86A.1676 1,2

D41692-308 MQ96510J.86A.1687 1,2

D41692-309 MQ96510J.86A.1687 1,2

D41692-310 MQ96510J.86A.1705 1,2

Notes:

1. The AA number is found on a small label on the component side of the board.

2. The 965 Chipset kit used on this AA revision consists of two components as follows:

Device Stepping S-Spec Numbers

82G965 C2 L9R5

82801HH B0 L9ML

6 Intel Desktop Board DG965WH Specification Update

Summary Table of Changes

The following table indicates the Specification Changes, Errata, Specification

Clarifications, or Documentation Changes that apply to the Intel®Desktop Board

DG965WH. Intel intends to fix some of the errata in a future revision of the desktop

board, and to account for the other outstanding issues through documentation or

specification changes as noted. This table uses the following notations:

Codes Used in Summary Table

Doc: Document change or update that will be implemented.

PlanFix: This erratum may be fixed in a future revision of the desktop board, driver, or BIOS.

Fixed: This erratum has been previously fixed.

NoFix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the document.

NO. PLANS SPECIFICATION CHANGES

1 Doc Changes to Section 1.7.2 Audio Connectors

2 Doc Changes to Section 1.8.1 Intel®82566DC Gigabit Ethernet Controller

NO. PLANS ERRATA

There is not characterized erratum for this product

Specification Changes

1. The following note will be added to the Technical Product Specification in

Section 1.7.2 Audio Connectors:

 INTEGRATOR’S NOTES

Electrostatic discharge (ESD) can damage desktop board components. Front-

panel connectors should provide sufficient protection to prevent ESD damage to

components inside the chassis enclosure.

2. Section 1.8.1 of the Technical Specification will be updated in its entirety as follows

to remove reference to Jumbo frame support.

1.8.1 Intel®82566DC Gigabit Ethernet Controller

The Intel®82566DC Gigabit Ethernet Controller supports the following features:

•PCI Express link

•10/100/1000 IEEE 802.3 compliant

•Compliant to IEEE 802.3x flow control support

•TCP, IP, UDP checksum offload

•Transmit TCP segmentation

•Advanced packet filtering

•Full device driver compatibility

•PCI Express Power Management Support
