MS-50BT/MS-50WT

Heavy-Duty Monitor Speaker

MS-50BT/MS-50WT Heavy-Duty Monitor Speaker

Contents

Welcome ..................................................................................................................................... 3

Unpacking ............................................................................................................................... 3

Warnings .................................................................................................................................. 3

Heavy-Duty Monitor Speaker................................................................................................. 5

Features ....................................................................................................................................... 5

Setup and Operation.................................................................................................................. 6

Connecting your Speaker System ............................................................................................ 7

Choosing the Correct Speaker Cable................................................................................... 7

Speaker Connection Procedures .......................................................................................... 7

Maintaining Proper Polarity .................................................................................................... 8

Choosing the Correct Amplification...................................................................................... 8

Using Multiple Loudspeakers.................................................................................................. 8

Specifications.............................................................................................................................. 9

MS-50BT/MS-50WT Heavy-Duty Monitor Speaker

Welcome

A personal welcome to you from the management and employees of Inter-M

Thank you for purchasing this fine Inter-M product. All of us here at Inter-M are dedicated

to providing you with the highest quality products and the best value.

We sincerely trust this product will provide you with years of satisfactory service, but if

anything is not to your complete satisfaction, we will endeavor to make things right.

Welcome to Inter-M, and thank you for becoming a part of our worldwide extended

family!

Unpacking

Although your MS-50BT/MS-50WT Heavy-Duty Monitor Speaker is neither complicated nor

difficult to operate, we recommend you take a few minutes to read this brief manual

and familiarize yourself with the important information regarding product features, setup

and operation.

We strongly recommend you retain the original packaging. In the unlikely event the

product must be returned for servicing, the original packaging (or reasonable

equivalent) is required.

Warnings

Environment

Never place this product in an environment that could alter its performance or reduce its

service life. Such environments are usually characterized by high levels of heat, dust,

moisture, or vibration.

Safety

1. Read these instructions carefully.

2. Follow all instructions.

3. Keep all warnings.

4. Clean only with a damp cloth.

5. Install only in accordance with the instructions in this manual.

6. Do not install near any heat sources such as radiators, heat registers, stoves, or other

devices (including amplifiers) that produce heat.

MS-50BT/MS-50WT Heavy-Duty Monitor Speaker

7. Use only the attachments/accessories specified.

8. Use only with a cart, stand, tripod, bracket, or table specified, or sold with the

apparatus. When a cart is used, use caution when moving the cart/apparatus

combination to avoid overturning.

9. Unplug this apparatus during lightning storms or when unused for long periods of

time.

10. Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate normally, or

has been dropped.

MS-50BT/MS-50WT Heavy-Duty Monitor Speaker

MS-50BT/MS-50WT

Heavy-Duty Monitor Speaker

Features

Stylish

• Sleek, stylish design blends with most environments.

Durable

• Aluminum alloy construction and anti-rust coating for long life and durability.

Versatile

• Full-range speaker system and matching transformer for high efficiency PA system

performance at High or Low Impedance.

Easy Installation

• Free standing, or use with optional FSB-1 mounting bracket.

MS-50BT/MS-50WT Heavy-Duty Monitor Speaker

Setup and Operation

Your MS-50BT/MS-50WT Heavy Duty Monitor Speakers can be placed on a table top or

other surface, or attach the speakers to a wall or other secure surface with the optional

FSB-1 mounting bracket.

WARNING: under no circumstances should any loudspeaker be mounted or suspended

in a public place unless the mounting method has been approved and certified by a

qualified engineer. Failure to properly secure the system can result in damage to the unit

or personal injury.

The MS-50BT/MS-50WT can operate at a rated input of 20W/4Ω, or in a 100V distributed

system.

MS-50BT/MS-50WT Heavy-Duty Monitor Speaker

Connecting your Speaker System

Always switch off the power to the amplifier before connecting speakers.

Choosing the Correct Speaker Cable

It is important to choose cabling designated for audio use and good quality connectors.

Using guitar cable or zip cord (designed for lamps and other electrical use) or poor

quality connectors will degrade your loudspeakers’ audio performance. For distributed

loudspeaker systems, we recommend stranded twisted pair speaker cable with an

overall vinyl jacket (plenum rated when installed in required installations).

Always use the appropriate gauge of speaker cable. For cable runs of less than 25 feet

(7.5 meters), 18- gauge cable is adequate. For longer cables, we suggest 16-gauge

stranded cable.

For installations where the speaker cable will be exposed to high traffic or weather

conditions such as moisture or extreme temperatures, we recommend you use weather-

resistant rubber jacketed cable, such as type S, SO or SJ cable.

Speaker Connection Procedures

After removing approximately 10mm (1/4-inch) of insulation from the ends of the speaker

cables, twist the strands tightly and then twist together with the distribution cable(s), using

an appropriate cable connector.

Make certain the wires do not protrude from the cable connector and touch any metal

on the speaker chassis, or any other adjacent metal.

Connect speaker wires to the appropriate terminals for your mode of operation, as

shown in the illustration below.

MS-50BT/MS-50WT Heavy-Duty Monitor Speaker

Maintaining Proper Polarity

It is very important to wire your speakers consistently in order to maintain proper

polarity. All quality cables are manufactured with clear markings to identify the

different conductors – normally by color-coding, printed markings, or textured ribbing

on the cable’s jacket material. Failing to do so will cause your speakers to operate

out of phase, resulting in significantly reduced low-frequency output from your

system.

Choosing the Correct Amplification

When selecting an amplifier for use with your speaker system, it is important to choose an

amplifier that has sufficient power output.

Choosing an amplifier that does not have adequate rated power may result in pushing

the amp beyond its limits, producing distortion or “clipping” of the signal. This can irritate

the listener and may cause damage to the speaker.

Choosing an amplifier that is over-powered can result in over-driving the speaker system.

Using Multiple Loudspeakers

It is important to consider the overall speaker load (impedance) when connecting

distributed speaker systems to an amplifier. Some distributed loudspeakers are marked in

load impedance; others show the wattage taps. Whatever the case, it is easy to

compute the total impedance (or wattage load) that is possible for a given amplifier.

Alternatively, the MS-50BT/MS-50WT can operate in a distributed system at 100V.

MS-50BT/MS-50WT Heavy-Duty Monitor Speaker

Specifications

ELECTRICAL

Rated Input 20W/4Ωor 20W/100V distributed

Frequency Response 120Hz – 20kHz

SPL (1W/1m) 90dB

Color

MS-50BT Black

MS-50WT White

Dimensions 150(W) x 240(H) x 150(D)mm/

5.9(W) x 9.4(H) x 5.9(D) in.

Weight 3.2kg / 7.1lbs.

Specifications and design subject to change without notice for improvements.

MS-50BT/MS-50WT Heavy-Duty Monitor Speaker

Inter-M, Ltd. (Korea) began operations in 1983.

Since then, Inter-M has grown to become one of the largest manufacturers

of professional audio and commercial sound electronics equipment in the world.

Inter-M has gained worldwide recognition for its own branded products,

as well as private label manufacturing of electronics sold under other names (OEM).

The company is no longer just a Korean company, but rather a global company

that is truly international in scope, with factories and offices in Korea and China,

and sales and marketing operations located in Japan, Europe, and the U.S.A.

With more than 850 employees around the globe, Inter-M is well-poised for further growth and

expansion.

INTER-M AMERICAS, INC.

1 EAST BEACON LIGHT LANE, CHESTER, PA, USA 19013-4409

TEL: (610) 874-8870, FAX: (610) 874-8890

Home Page:http://www.inter-m.net, E-mail: [email protected]

INTER-M Corporation

SEOUL OFFICE: 653-5 BANGHAK-DONG, DOBONG-KU, SEOUL, KOREA

TEL: 82-2-2289-8140~8, FAX: 82-2-2289-8149

Home Page:http://www.inter-m.com, E-mail: [email protected]

0804MS50BTWT PRINTED IN KOREA
