Intimus F-300 Manuale utente

Folder

Operating instructions

F-300

95516 1 12/18

intimus International GmbH, Bergheimer Straße 6-12, 88677 Markdorf / Germany

Tel.: ++49 (0)7544 / 60-0 --- E-mail: [email protected] --- www.intimus.com

Thankyouforusingourmachine.Pleasereadtheseoperatinginstructions

beforeputtingthemachineintooperationandobservethesafetyprecautions.

1.SafetyPrecautions…………………………………………2

2.Installation…………………………………………5

3.NamesandFunctions…………………………………………6

4.DescribingControlPanel…………………………………………9

5.HandlingPaper…………………………………………10

6.BasicOperation…………………………………………

7.FoldingOperation…………………………………………16

8.CorrectingFolding…………………………………………21

9.Troubleshooting…………………………………………27

10.MaintenanceandCleaning…………………………………………37

11.Specification…………………………………………40

SafetyPrecautions

Pleasereadtheseoperatinginstructions

beforeputtingthemachineintooperation

andobservethesafetyprecautions.

Childrenmustnotoperatethemachine!

Donotreachintothemachine!

SafetyPrecautions

Longhaircanbecomeentangledincutting

head!

Takecareoftiesandotherloosepiecesof

clothing!

Removeanypaperclips!

SafetyPrecautions

Componentswhichmayendanger

theoperatorarecovered!

Connectthepowercordtoasingle

phasesocket230V/10A.

Disconnectfromthemainsifnot

usedforalongperiod.

Installation

Attach Attach Attach Attachthe the the thefirst first first firstfolding folding folding foldingplate plate plate plate: :::

Thesamewaywiththesecond

foldingplate.

Attach Attach Attach Attachthe the the thesecond second second secondfolding folding folding foldingplate plate plate plate：：：：

Movethelockleverofthesecond

foldingplatetothepositionof

"UNLOCK".

Insertthefoldingplatetothe

machinealongtheslider.

Movethelocklevertotheposition

of"LOCK".

Slider

Locklever Secondfoldingplate

Firstfoldingplate

Locklever

NamesandFunctions

NO.NameFunction

FirstfoldingplateGuideplatefordecidingapaperfoldingposition.

Firstfoldingismadeusingthisplate.

FineadjustmentknobUsedwhenadjustingapaperfoldingposition.

RoughadjustmentknobUsedwhendecidingapaperfoldingposition.

ControlpanelUsedwhenoperatingthemachine.Error

messagesarealsodisplayedontheLCDdisplay.

5SecondfoldingplateGuideplatefordecidingapaperfoldingposition.

Secondfoldingismadeusingthisplate.Thisplate

isnotusedwhenfoldingpaperintotwo.

PaperreceivingtrayReceivesfoldedpaperejectedout.

PaperreceivingstopperStopspaperejectedoutfromthemachine.

StackerrollersEjectsfoldedpaperfromthemachine.

SupportpaperfeedplateSupportspaperstackedonthepaperfeedtable.

SideguideHoldspaperstackedonthepaperfeedtable.

11PaperfeedtableUsedtostackpapertobefolded.

NamesandFunctions

NO.NameFunction

TopcoverPreventstheuserfromtouchingthemovingparts.

PaperfeedringFeedspaperintothemachine.

Separatingpressure

adjustmentdial

Adjuststhepaperseparatingpressure.

RubberrollSendspapertothefirstfoldingplate.

16Paperfeedpressure

adjustmentknob

Adjustspaperfeedpressure.

Slantcorrectionpaper

feedknob

Correctsmisalignmentalongsidesofpaper.

PowerswitchTurnsonandoffthepower.

NamesandFunctions

NO.NameFunction

Counter/LCDdisplayCountsupthenumberoffoldedpaperordisplays

thestatusofthemachine.

CountbuttonEntertherequirednumber.

C(clear)buttonWhenthemachineisstoppedwithpaperonthe

paperfeedtable,pressingthebuttonformore

thantwosecondsmakesthecountednumber

returnto"0."

Whenamis-feedhasoccurred,pressingthis

buttonclearsthemessage.

StopbuttonWhenpressed,themachinestops.

StartbuttonWhenpressed,themachinestartsfolding

operations.

Tableofstackerrollers

position

Usedasareferencetocheckanappropriate

positionofthestackerrollersdependingona

papersizeandfoldingpattern.

DescribingControlPanel

123

4 5
