IOGear MiniView Micro Audio GCS614A Manuale utente

MiniView™ Micro Audio

4 Port KVM Switch with Built-in KVM Cables

Quick Start Guide (GCS614A)

®

Before you begin, please turn off the computers you are going to connect to the MiniView™ Micro Audio.

NOTE:

To prevent damage to your equipment due to static electric discharge, please make sure that all devices on the installation are properly grounded.

Step.1

1. Connect your monitor to the female VGA port

on your MiniView™ Micro Audio.

2. Connect your PS/2 keyboard into the PS/2

keyboard port on your MiniView™ Micro Audio.

3. Connect your PS/2 mouse into the PS/2 keyboard

port on your MiniView™ Micro Audio.

4. Connect your speakers directly into the audio

port on your MiniView™ Micro Audio.

1. Connect the VGA cable that is built into the KVM

cable of your MiniView™ Micro Audio to the VGA

port on your computer.

2. Connect the PS/2 keyboard cable that is built into

the KVM cable of your MiniView™ Micro Audio to

the PS/2 key-board port on your computer.

3. Connect the PS/2 mouse cable that is built into the

KVM cable of your MiniView™ Micro Audio to the

PS/2 mouse port on your computer.

4. Connect the speaker cable that is built into the

KVM cable of your MiniView™ Micro Audio to the

speaker port on your computer.

Step.2

Repeat step 2 for the rest of you computers.

Turn on the power to the computers.

Operation

Accessing all of your computers from a single console could not be easier.The GCS614A uses Hotkey

combinations to give the KVM focus to the computer of your choice.

The GCS614A provides the following Hotkey features:

• Selecting the Active Port

• Auto Scan Mode

Please refer to Page 11 of the GCS614A user manual for details on Hotkey operations.

Step.3

Step.4

Congratulations!

Congratulations! You have completed installing

the IOGEAR®MiniView™ Micro Audio.

MiniView™ Micro Audio

4 Port KVM Switch with Built-in KVM Cables

Quick Start Guide (GCS614A)

IOGEAR

23 Hubble Drive

Irvine, CA 92618

866.946.4327

949.453.8785

Web-site: www.iogear.com

E-mail: info@iogear.com

Entire contents copyright 2003 IOGEAR®

All rights reserved. Reproduction in whole or in

part without permission is prohibited. MiniView™

is a trademark of IOGEAR®. All other trade marks

are the property of their respective owners.

PKG-M0089/QS ®
