ITOX G4V100-P Manuale utente
G4V100-P
G4V100-M
System Board
User’s Manual
935-G4V101-000(G)
A80420546
Copyright
This publication contains information that is protected by copyright.
No part of it may be reproduced in any form or by any means or
used to make any transformation/adaptation without the prior
written permission from the copyright holders.
This publication is provided for informational purposes only. The
manufacturer makes no representations or warranties with respect to
the contents or use of this manual and specifically disclaims any
express or implied warranties of merchantability or fitness for any
particular purpose.The user will assume the entire risk of the use or
the results of the use of this document. Further, the manufacturer
reserves the right to revise this publication and make changes to its
contents at any time, without obligation to notify any person or
entity of such revisions or changes.
© 2005. All Rights Reserved.
Trademarks
Product names or trademarks appearing in this manual are for
identification purpose only and are the properties of the respective
owners.
Caution
To avoid damage to the system:
• Use the correct AC input voltage range.....
To reduce the risk of electric shock:
• Unplug the power cord before removing the system chassis
cover for installation or servicing. After installation or servicing,
cover the system chassis before plugging the power cord.
Battery:
• Danger of explosion if battery incorrectly replaced.
• Replace only with the same or equivalent type recommend
by
the manufacturer.
• Dispose of used batteries according to the battery manufactur-
er’s
instructions.
FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio TV technician for
help.
Notice:
1. The changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
2. Shielded interface cables must be used in order to comply with
the emission limits.
Notice
An electronic file of this manual is included in the CD. To view the
user’s manual in the CD, insert the CD into a CD-ROM drive. The
autorun screen (Main Board Utility CD) will appear. Click “User’s
Manual” on the main menu.
Table of Contents
Chapter 1 - Introduction
1.1 Features.................................................................................................................................
1.2 Special Features of the System Board.....................................................
1.3 Package Checklist.........................................................................................................
Chapter 2 - Hardware Installation
2.1 System Board Layout ...........................................................................................
2.2 System Memory...........................................................................................................
2.3 CPU........................................................................................................................................
2.4 Jumper Settings.............................................................................................................
2.5 Rear Panel I/O Ports..............................................................................................
2.6 I/O Connectors...........................................................................................................
Chapter 3 - BIOS Setup
3.1 Award BIOS Setup Utility....................................................................................
3.5 Updating the BIOS.....................................................................................................
Chapter 4 - Supported Softwares
4.1 Drivers, Utilities and Software Applications.........................................
4.2 Installation Notes..........................................................................................................
7
11
14
15
16
18
23
33
45
61
96
97
105
Introduction
1
6
107
110
110
112
Appendix A - Watchdog Timer
A.1 Watchdog Timer.........................................................................................................
Appendix B - Using the Suspend to RAM
Function
B1 Using the Suspend to RAM Function..................................................
Appendix C - System Error Messages
C.1 POST Beep.....................................................................................................................
C.2 Error Messages............................................................................................................
Appendix D - Troubleshooting
D.1 Troubleshooting Checklist.................................................................................
106
1
Introduction
7
Chapter 1 - Introduction
1.1 Features
Processor
G4V100-P
• Intel®Pentium®4 Processor with Hyper-Threading Technology
- 533MHz system data bus
• Intel®Pentium®4 Northwood processor
- 533MHz/400MHz system data bus
• Intel®Celeron®Northwood processor
- 400MHz system data bus
G4V100-M
• Intel®Pentium®4 Processor-M (478-pin)
- 400MHz system data bus
• Supplies IMVP-III voltage current tolerances at VID=1.30V
maximum performance mode
Chipset
• Intel®845GV chipset
- Intel®845GV Graphics Memory Controller Hub (GMCH)
- Intel®82801DB I/O Controller Hub (ICH4)
System Memory
• Two 184-pin DDR SDRAM DIMM sockets
• 2.5V unbuffered PC1600 (DDR200), PC2100 (DDR266) or
PC2700 (DDR333) DDR SDRAM DIMM
• Supports maximum of 2GB system memory using 64Mbit,
128Mbit, 256Mbit or 512Mbit technology
- Double-sided x16 DDR SDRAM DIMM is not supported
BIOS
• Award BIOS, Windows®98SE/2000/ME/XP Plug and Play
compatible
• Supports SCSI sequential boot-up
• Supports DMI 2.0 function
• 4Mbit flash memory
Energy Efficient Design
• Supports ACPI specification and OS Directed Power
Management
Introduction
1
8
• Supports ACPI STR (Suspend to RAM) function
• Wake-On-Events include:
- Wake-On-PS/2 Keyboard/Mouse
- Wake-On-USB Keyboard/Mouse
- Wake-On-LAN
- Wake-On-Ring
- RTC timer to power-on the system
• System power management supported
• CPU stopped clock control
• Hardware supports SMI green mode
• Microsoft®/Intel®APM 1.2 compliant
• Soft Power supported - ACPI v1.0a specification
• AC power failure recovery
Damage Free Intelligence
• Monitors CPU/system temperature and overheat alarm
• Monitors 5VSB(V)/VBAT(V)/1.5V/3.3V/5V/±12V/CPU(V)
voltages and failure alarm
• Monitors CPU/chassis/2nd fan speed and failure alarm
• Read back capability that displays temperature, voltage and fan
speed
• Watchdog timer function
Onboard Graphics Features
• Graphics memory
- Shares 512K/1MB/8MB of the system memory in DOS
mode
- Uses Dynamic Video Memory Technology (DVMT) in
Windows mode
• Graphics controller
- Core frequency of 200MHz
- 350MHz integrated 24-bit RAMDAC
- Analog display up to 2048x1536 @ 60Hz refresh
- 3D setup and render engine - Discrete, Triangles, Strips and
fans
- Per pixel perspective corrected texture mapping
- Software DVD at 30fps, full screen
• 2D graphics features
- Optimized 256-bit BLT engine
- 32-bit alpha blended cursor
- Programmable 3-color transparent cursor
1
Introduction
9
• 3D graphics features
- 200 megapixels/sec fill rate
- Maximum 3D resolution: 1600x1200x32 @ 85Hz
- Flat and Gouraud shading
- 16- and 24-bit Z-buffering and 16- and 24-bit W-buffering
- Vertex and programmable pixel fogging and
atmospheric effects
- Double and triple render buffer
• Software drivers
- Windows®98SE/2000/ME/XP
- Windows NT®4.0
LVDS Transmitter
• Chrontel CH7017
• Supports scale up to 1600x1200 pixels
• 18-bit and 24-bit outputs
• 2D dither engine
• Support for second CRT DAC bypass mode
• Dual LVDS supporting pixel rates up to 330Mpixels/sec when
both 12-bit input ports are ganged together
Onboard Audio Features
• Realtek ALC202A
• 18-bit stereo full-duplex codec with independent variable
sampling rate
• High quality differential CD input
• True stereo line level outputs
• S/PDIF-out interface
• 2-channel audio output
Onboard LAN Features
• Uses Intel 82562EM fast ethernet controller
• IEEE 802.3, 10BASE-T/100BASE-TX compliant physical layer
interface
• IEEE 802.3u Auto-Negotiation
• Digital Adaptive Equalization control
• Link status interrupt capability
• 10BASE-T auto-polarity correction
• Alert on LAN functionality
• LAN Connect I/F
• 1:1 transmit transformer ratio support
• Automatic detection of “unplugged mode”
Introduction
1
10
IDE Interface
• Supports ATA/33, ATA/66 and ATA/100 hard drives
• PIO Mode 4 Enhanced IDE (data transfer rate up to 14MB/sec.)
Processor Socket
• Socket 478
Rear Panel I/O Ports
• 2 USB 2.0/1.1 ports
• 1 RJ45 LAN port
• 2 DB-9 serial ports
• 1 DB-15 VGA port
• 1 DB-25 parallel port
• 1 mini-DIN-6 PS/2 mouse port
• 1 mini-DIN-6 PS/2 keyboard port
• 3 audio jacks: line-out, line-in and mic-in
I/O Connectors
• 2 connectors for 4 additional external USB 2.0/1.1 ports
• 1 connector for COM 3 (RS232 or LVDS)
• 1 connector for COM 4 (RS232 or RS485)
• 1 44-pin connector for LVDS LCD panel
• 1 LCD/Inverter power connector
• 1 LCD brightness control connector
• 1 front audio connector for line-out and mic-in jacks
• 1 CD-in internal audio connector
• 1 S/PDIF-out connector
• 1 IrDA connector
• 1 40-pin IDE 1 connector for 3.5" HDD
• 1 44-pin IDE 2 connector for 2.5" HDD
• 1 floppy connector (FPC connector type)
• 2 ATX power supply connectors
• 1 Wake-On-LAN connector
• 1 chassis open connector
• 3 fan connectors
Expansion Slots
• 1 PCI slot for PCI expansion card or customized riser card for 1,
2 or 3 PCI slots expansion (for low profile PCI card only)
