Jabra rox wireless Manuale utente
jabra.com/roxwireless
User Manual
JABRA ROX WIRELESS
© 2013 GN Netcom A/S. All rights reserved. Jabra®is a registered
trademark of GN Netcom A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth®word
mark and logos are owned by the Bluetooth SIG, Inc. and any use
of such marks by GN Netcom A/S is under license. (Design and
specifications subject to change without notice).
Declaration of Conformity can be found on www.jabra.com/CP/US/declarations-of-
conformity
MADE IN CHINA
MODEL: OTE16
3
english
jabra rox WIrELESS
CONTENTS
1. WELCOME.......................................... 4
2. HEADSET OVERVIEW......................... 5
2.1 INCLUDED ACCESSORIES
3. HOW TO WEAR.................................. 6
3.1 CHANGING EARGELS
3.2 WEARING THE EARWINGS
3.3 WEARING THE FITCLIP
3.4 HOWTOWEAR VIDEOS
3.5 MAGNETIC EARBUDS
4. HOW TO CHARGE THE BATTERY..... 10
5. HOW TO CONNECT...........................11
5.1 CONNECT WITH A BLUETOOTH DEVICE
5.2 CONNECT WITH AN NFC DEVICE
5.3 CONNECT MULTIPLE DEVICES
6. HOW TO USE ...................................13
6.1 MULTIPLE CALL HANDLING
6.2 LIST OF VOICE GUIDANCE
7. SUPPORT..........................................18
7.1 FAQ
7.2 HOW TO CARE FOR YOUR HEADSET
8. TECHNICAL SPECIFICATIONS ...........19
4
english
jabra rox WIrELESS
1. WELCOME
Thank you for using the Jabra Rox Wireless. We
hope you will enjoy it!
JABRA ROX WIRELESS FEATURES
High definition Dolby® Digital Plus enhanced
sound with the exclusive Jabra Sound App
Cable controls for easy music and call
management
Life proof: weather and dust resistant
Premium materials: Kevlar reinforced cable
design, solid steel earbuds
Magnetic earbuds: Save battery when the
headset is not in use
NFC for easy pairing
5
english
jabra rox WIrELESS
2. HEADSET OVERVIEW
2.1 INCLUDED ACCESSORIES
4 ColorCore EarGelsTM 3 EarWings
(Small, medium, large)
USB cable
ColorCore
EarGelTM
Volume up
button
Multi-function
button
Volume down
button
NFC zone
(button side)
LED
indicator
Charging
cover Magnetic
earbuds
Fitclip
(optional
wearing
style)
Charging cover
Charging
port
Microphone
6
english
jabra rox WIrELESS
3. HOW TO WEAR
jabra
jabra
3.1 CHANGING EARGELS
Choose between 4 Colorcore Eargels for optimal
fit and comfort.
7
english
jabra rox WIrELESS
3.2 WEARING THE EARWINGS
Choose between 3 EarWing sizes for optimal fit
and stability.
1. Align the L or R on the EarWing with the L or R
on the earbud and gently pull the EarWing onto
the earbud. Adjust by rotating, if needed.
2. When wearing the headset, the EarWing fits into
the ridge of the ear. Ensure the EarWing does
not cover the microphone.
8
english
jabra rox WIrELESS
3.3 WEARING THE FITCLIP
Attach the fitclip to the cable, and adjust for
optimal fit.
jabra
jabra
3.4 HOWTOWEAR VIDEOS
You can watch how-to-wear instructional videos
for the ColorCore EarGelsTM, EarWings and fitclip at
jabra.com/roxwireless.
9
english
jabra rox WIrELESS
3.5 MAGNETIC EARBUDS
The earbuds are magnetic. Join or separate them
to turn Standby mode on/off, or end/answer a
call.
Standby mode ON Standby mode OFF
jabra
jabra
NOTE:The headset will power off after 5 minutes when the
magnetic earbuds are separated and the headset is not
connected to a mobile device.
10
english
jabra rox WIrELESS
4. HOW TO CHARGE THE
BATTERY
Remove the charging cover on the right earbud to
expose the micro-USB port. Plug the USB cable into
the headset and the PC to begin charging.
jabra
It takes approx. 2.5 hours to fully charge the
headset.
NOTE:For safety reasons, it is recommended not to use the
headset while it is charging.
