Jacuzzi CETRA 536 PLUS Manuale utente

Like its namesake, the Cetra

whirlpool

bath is an undeniable classic.

features:

• 4 fully adjustable TheraPro™ jets

• 5 directionally adjustable AccuPro™ jets

• RapidHeat™ in-line heater

• Electronic on/off control with temperature readout

• Air ﬂow adjustability

• Chromatherapy™ lighting system capable of 256

colors

• Sculpted armrest and contoured backrest

• Integral skirt with access panels and

built-in tile ﬂange

• PrO

™

Cleansing System

cetra®536 plus

(with integral skirt)

model number: BP99 – RH, BP93 – LH

exterior dimensions:

60" long x 36" wide x 21¼" high

interior dimensions:

41½" long x 22" wide

# of Jets/type of Jets:

4 TheraPro™ Jets,

5 AccuPro™ Jets

operating gallons:

48 gallons

cetra®536 whirlpool plus with integral skirt

from the ancient hymns of the greek gods comes cetra®—italian for “lyre”.

Cetra® 536 Plus Whirlpool Bath w/Integral Skirt

Model: BP99, BP93

Installation Notes

Refer to installation instructions included with ﬁxture before beginning installation.

Please conﬁrm product availability and speciﬁcations before commencing with any

installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE

WITHOUT NOTICE.

Ordering Information

Product Code:

BP99 Cetra® 536 Plus Whirlpool Bath

with Integral Skirt Right Hand

BP93 Cetra® Plus Whirlpool Bath with

Integral Skirt Left Hand

• Right and Left Hand Drain Location

• Accessories / Hardware:

Trip-Lever Drain Kit: #X559

Rotary Drain Kit, 26” Cable: #8730

TheraPro™ Jet Rings Kit: #D095

AccuPro™ Jet Rings Kit (3 Req’d): #P556

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(845) – Oil Rubbed Bronze

Technical Speciﬁcations

Dimensions

60” L x 36” W x 21-1/4” H

(1524 mm) L x (914 mm) W x (540 mm) H

Drain/Overﬂow

A: 18-1/2” ( 470 mm) B: 9” ( 229 mm)

Cutout

Not Applicable

Total Weight

742 lb (337 kg) / 50 lb/sq. ft. (242 kg/m2)

Operating Gallonage

48 U.S. Gal. (181 Liters)

Max. 55 U.S. Gal. (208 Liters)

Product Weight

92 lb (42 kg)

Skirt Mounting

Integral

Electrical Speciﬁcations

Requires a dedicated GFCI protected separate circuit.

Motor/Pump: 120 VAC, 15 AMP, 60 Hz.

RapidHeat™: 120 VAC, 15 AMP, 60 Hz.

Heater(Standard)

Requires a dedicated GFCI protected separate circuit.

RapidHeat™: P/N S750000

*60"

36"

17-3/8"

12" x 4"*

(Left hand shown. Right hand is mirror image.)

SIDE VIEW END VIEW

(Suction

Heater)

#FR29 07/07

DRAIN/OVERFLOW

Product Shown: Cetra® 536 Plus Whirlpool Bath with Integral Skirt Left Hand Model: BP93

* Measurements inside unit represent cutout in ﬂoor to allow for drain/overﬂow.
