Jacuzzi Fuzion 7260 Manuale utente

Bathing has never been like this before. Incorporating exotic woods, acrylic and

state-of-the art bathing technologies, the Fuzion™combines everything you need

to create your ideal spa experience.

FEATURES:

• Multi-speed motor

• 4 fully adjustable TheraPro®jets

• 11 directionally adjustable AccuPro™ jets

• 900 watt variable speed heated air blower

• Bottom air channels for maximum massage

• Chromatherapy™ lighting system capable of 256 colors

• Water level sensor

• Drain-assist purge system

• Sculpted armrest and contoured backrest with pillows

• All-in-one electronic control panel

• Inﬁnity-edge drain system

• RapidHeat™ inline heater

• Undermount or choose Wenge or Teak wooden deck

• PrO3

™Cleansing System

Fuzion™7260 |SALON™ SPA with CHROMATHERAPY, SINGLE MOTOR

Fuzion™6666

SALON™ SPA with

CHROMATHERAPY,

SINGLE MOTOR

MODEL NUMBER:

FL85 (Teak RH)

FL05 (Wenge RH)

EXTERIOR DIMENSIONS:

72" long x 60" wide x

24" high

# OF JETS/TYPE OF JETS:

4 TheraPro™

7 AccuPro™ Back Jets

4 AccuPro™ Foot Jets

OPERATING GALLONS:

145 gallons

Technical Speciﬁcations

DIMENSIONS

72” L x 60” W x 24” H

(1829 mm) L x (1524 mm) W x (667 mm) H

DRAIN/OVERFLOW

A: 16-3/4” (425 mm) B: 12-1/16” (306 mm)

CUTOUT

71” (1803 mm) x 59” (1499 mm)

TOTAL WEIGHT

1805 lb. (819 kg) / 60 lb/ft2(293 kg/m2)

OPERATING GALLONAGE

145 U.S. Gal. (549 Liters)

PRODUCT WEIGHT

274 lb. (124 kg)

SKIRT MOUNTING

Not Available

ELECTRICAL SPECIFICATIONS

Requires a dedicated GFCI protected separate circuit.

Blower: 120VAC, 20AMP, 60 Hz.

Motor/Pump and RapidHeat™: 240VAC, 20AMP, 60 Hz.

HEATER (STANDARD)

Requires a dedicated GFCI protected separate circuit.

RapidHeat™: P/N BN60000

INSTALLATION NOTES

Refer to installation instructions included with ﬁxture before

beginning installation. Please conﬁrm product availability and

speciﬁcations before commencing with any installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT

TO CHANGE WITHOUT NOTICE.

#FR77000 10/07

Fuzion™7260

SALON™SPA with CHROMATHERAPY

FL85 Fuzion™ 7260 Salon™ Spa with Chromatherapy

Right Hand motor, Teak

FL05 Fuzion™ 6666 Salon™ Spa with Chromatherapy

Right Hand motor, Wenge

• Center Drain Location

• Overﬂow ﬁtting comes with tub

• Accessories / Hardware:

TheraPro™ Jet Rings Kit: #D095

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(845) – Oil Rubbed Bronze

Motor

Heater

72"

60"

36"

24.19"

12"

8.47"

18-1/2" x 4"

12" H x 24" L

Service Access

Optional

Service Access

Blower

Product Shown: Fuzion™ 7260 Salon™ Spa

Teak with Chromatherapy

Single Right Hand Motor Model:FL85

* Measurements inside unit represent cutout in

ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.

DRAIN/OVERFLOW

6-1/4" (159 mm)

SIDE VIEWEND VIEW

(Motor)

(Inlet Heater)

72"

25-1/4"

60"

(Blower)
