Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 R2

Juniper Networks, Inc.

1194 North Mathilda Avenue

Sunnyvale, CA 94089

USA

408-745-2000

www.juniper.net

Part Number: 530-027290-01, Revision 1

Security Threat Response Manager

STRM Installation Guide

Release 2008.2 R2

2

Networks Inc. in the United States and other countries. All other trademarks, service marks, registered trademarks, or registered service marks in this

document are the property of Juniper Networks or their respective owners. All specifications are subject to change without notice. Juniper Networks

assumes no responsibility for any inaccuracies in this document or for any obligation to update information in this document. Juniper Networks reserves

the right to change, modify, transfer, or otherwise revise this publication without notice.

FCC Statement

The following information is for FCC compliance of Class A devices: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. The equipment generates, uses, and can radiate radio-frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference, in which case users will be required to correct the interference at their own expense. The following

information is for FCC compliance of Class B devices: The equipment described in this manual generates and may radiate radio-frequency energy. If it

is not installed in accordance with NetScreen’s installation instructions, it may cause interference with radio and television reception. This equipment has

been tested and found to comply with the limits for a Class B digital device in accordance with the specifications in part 15 of the FCC rules. These

specifications are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Consult the dealer or an experienced radio/TV

technician for help. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

Caution: Changes or modifications to this product could void the user's warranty and authority to operate this device.

Disclaimer

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET

THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE

SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR JUNIPER NETWORKS REPRESENTATIVE FOR A COPY.

STRM Installation Guide

Release 2008.2 R2

Revision History

September 2008—Revision 1

The information in this document is current as of the date listed in the revision history.

CONTENTS

ABOUT THIS GUIDE

Conventions 1

Technical Documentation 1

Contacting Customer Support 2

1PREPARING FOR YOUR INSTALLATION

Deploying STRM 4

Additional Hardware Requirements 6

Additional Software Requirements 6

Browser Support 6

Preparing Your Network Hierarchy 6

Identifying Network Settings 7

Identifying Security Monitoring Devices and Flow Data Sources 8

Identifying Network Assets 9

2INSTALLING STRM

Setting Up Appliances 11

Installing STRM Using Red Hat Enterprise 4.6 16

Installing Japanese Support 21

Accessing STRM 22

ASETTING UPRED HAT ENTERPRISE

Before You Begin 23

Configuring Network Parameters 24

Configuring Firewall Configuration 24

Configuring Disk Partitions 24

Installing Red Hat Enterprise 4

Update 6 25

Customizing Red Hat Upgrades 26

BCHANGING NETWORK SETTINGS

Changing Network Settings in an All-in-One Console 27

Changing the Network Settings of a Console in a Multi-System Deployment 28

Changing the Network Settings of a Non-Console in a Multi-System Deployment 31

INDEX

STRM Installation Guide

ABOUT THIS GUIDE

The STRM Installation Guide provides you with information on setting up STRM.

This guide assumes a working knowledge of networking and Linux systems.

Conventions Table 1 lists conventions that are used throughout this guide.

Technical

Documentation

You can access technical documentation, technical notes, and release notes

directly from the Qmmunity web site at https://support@juniper.net/. Once you

access the Qmmunity web site, locate the product and software release for which

you require documentation.

Your comments are important to us. Please send your e-mail comments about this

guide or any of the Juniper Networks documentation to:

documentation@Juniper.net.

Include the following information with your comments:

•Document title

•Page number

Contacting

Customer Support

To help you resolve any issues that you may encounter when installing or

maintaining STRM, you can contact Customer Support as follows:

•Log a support request 24/7: https://support@juniper.net

For access to the Qmmunity web site, please contact Customer Support.

Table 1 Icons

Icon Type Description

Information note Information that describes important features or

instructions.

Caution Information that alerts you to potential loss of

data or potential damage to an application,

system, device, or network.

Warning Information that alerts you to potential personal

injury.

STRM Installation Guide

2ABOUT THIS GUIDE

•Access Qmmunity and Self-Service support using e-mail: support@juniper.net

•Telephone assistance: 1.866.377.7000.

STRM Installation Guide

1PREPARING FOR YOUR

INSTALLATION

This chapter provides information for when planning your STRM deployment

including:

•Deploying STRM

•Additional Hardware Requirements

•Additional Software Requirements

•Browser Support

•Preparing Your Network Hierarchy

•Identifying Network Settings

•Identifying Security Monitoring Devices and Flow Data Sources

•Identifying Network Assets

Your STRM deployment may consist of STRM installed on one or multiple

systems. You can use the STRM three-tier architecture to install any or all

components on a single server for small enterprises or distributed across multiple

servers for maximum performance and scalability in large enterprise

environments.

To ensure a successful STRM deployment, adhere to the recommendations in this

document.

STRM Installation Guide

4PREPARING FOR YOUR INSTALLATION

Deploying STRM You can deploy STRM using STRM appliances or STRM software installed on

your own hardware. This section provides information on deploying STRM

including:

•STRM Components

A STRM appliance includes STRM software and a CentOS-4 operating system.

For further information on STRM appliances, see the Hardware Installation Guide.

STRM Components STRM components that may exist in your deployment include:

Note: For more information on each STRM component, see the STRM

Administration Guide.

•QFlow Collector - Passively collects traffic flows from your network through

span ports or network taps. The QFlow Collector also supports the collection of

external flow-based data sources, such as NetFlow. You can install a QFlow

Collector on your own hardware or use one of the QFlow appliances.

•Flow Processor - Normalizes flows sent from one or more QFlow Collector(s)

by consolidating, aggregating, and removing duplicate flows. The QFlow

Collector can also create superflows (aggregate flows) before the flows reach

the Classification Engine.

•Classification Engine - Analyzes flows to classify and identify all traffic in the

enterprise network into multiple objects.

•Console - Provides the interface for STRM. The Console provides real time

views, reports, alerts, and in-depth flow views of network traffic and security

threats. This Console is also used to manage distributed STRM deployments.

The Console is accessed from a standard web browser. When you access the

system, a prompt appears for a user name and password, which must be

configured during the installation process. You must also have Java installed.

For information on software requirements, see Additional Software

Requirements.

•Update Daemon - Stores the database and TopN data. Typically, the Update

Daemon is installed on the Console.

•Flow Writer - Stores the flow and asset profile data.

•Offense Resolution - Offense Resolution is a module that provides

enterprise-wide intrusion prevention for your network and includes Resolvers,

Resolutions and Resolver Agents.

•Event Collector - The Event Collector gathers events from local and remote

device sources. The Event Collector normalizes events and sends the

information to the Event Processor. Before being sent to the Event Processor,

the Event Collector bundles identical events to conserve system usage. During

this process, Magistrate risk factors map the events to the STRM Identification

System, and creates the bundles.

STRM Installation Guide

Additional Hardware Requirements 5

•Event Processor - Processes events collected from one or more Event

Collector(s). Once received, the Event Processor correlates the information

from STRM and distributes to the appropriate area, depending on the type of

event. The Event Processor also includes information gathered by STRM to

indicate any behavioral changes or policy violations for the event. Rules are

applied to the events that allow the Event Processor to process according to the

configured rules. Once complete, the Event Processor sends the events to the

Magistrate.

•Magistrate - Provides the core processing components. You can add one

Magistrate component for each deployment. The Magistrate provides views,

reports, alerts, and analysis of network traffic and security events. The

Magistrate processes the event against the defined custom rules to create an

offense. If no custom rules exist, the Magistrate uses the default rules to

process the event. An offense is an event that has been processed through

STRM using multiple inputs, individual events, and events combined with

analyzed behavior and vulnerabilities. Magistrate prioritizes the offenses and

assigns a magnitude value based on several factors, including number of

events, severity, relevance, and credibility.

Additional

Hardware

Requirements

Before installing your STRM systems, make sure you have access to the additional

hardware components:

•Monitor and keyboard or a serial console

•To make sure that your STRM data is preserved during a power failure, we

highly recommend that all STRM appliances or systems running STRM

software storing data (such as, Consoles, Event Processors, or Flow

Processors) be equipped with a Uninterrupted Power Supply (UPS).

Additional Software

Requirements

Before installing STRM, make sure you have Java Runtime Environment installed

on your system. You can download Java version 1.5.0_15 at the following web

site: http://java.com/.

Browser Support You must have a browser installed on your client system to access the STRM

interface. STRM supports the following web browsers:

- Microsoft Internet Explorer 6.0/7.0

- Firefox 2.0

Preparing Your

Network Hierarchy

STRM uses the network hierarchy to understand your network traffic and provide

you with the ability to view network activity for your entire deployment. STRM

supports any network hierarchy that can be defined by a range of IP addresses.

STRM Installation Guide

6PREPARING FOR YOUR INSTALLATION

You can create your network based on many different variables, including

geographical or business units. For example, your network hierarchy may include

corporate IP address ranges (internal or external), physical departments or areas,

mails servers, and web servers.

Once you define the components you wish to add to your network hierarchy and

install STRM, you can then configure the network hierarchy using the STRM

interface. For each component you wish to add to your network hierarchy, use the

following table to indicate each component in your network map.

At a minimum, we recommend that you define objects in the network hierarchy for:

•Internal/external Demilitarized zone (DMZ)

•VPN

•All internal IP address space (for example, 0.0.0.0/8)

•Proxy servers

•Network Address Translation (NAT) IP address range

•Server Network subnets

•Voice over IP (VoIP) subnets

For more information, see the STRM Administration Guide - Setting Up STRM,

Creating Your Network Hierarchy.

Identifying Network

Settings

Before you install STRM, you must have the following information for each system

you wish to install:

•Hostname

•IP address

•Network Mask address

•Subnet Mask

•Default Gateway

•Primary DNS Server

•Secondary DNS Server (Optional)

•Public IP address for networks using Network Address Translation (NAT)

Table 1-1 Network Hierarchy

Description Name IP/CIDR Value Weight

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Juniper Software

Juniper

Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 - EVENT CATEGORY CORRELATION REV... Manuale utente

Juniper

Juniper JUNOS SPACE SERVICE INSIGHT Guida all'installazione

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - SERVICE AVAILABILITY CONFIGURATION GUIDE... Manuale utente

Juniper

Juniper JUNOS OS 10.3 - XML MANAGEMENT PROTOCOL GUIDE... Manuale di installazione

Juniper

Juniper JUNOSE SOFTWARE 11.2.X - LINK LAYER CONFIGURATION GUIDE... Manuale utente

Juniper

Juniper NETWORK AND SECURITY MANAGER 2010.3 - CONFIGURING INTRUSION DETECTION AND PREVENTION GUIDE... Manuale utente

Juniper

Juniper JUNOSE 11.2.X BGP AND MPLS Manuale utente

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - POLICY MANAGEMENT CONFIGURATION GUIDE... Manuale utente

Juniper

Juniper JUNOSE 11.0.X MULTICAST ROUTING Manuale utente

Juniper

Juniper STRM 2008-2 - TECHNICAL NOTE CHANGING NETWORK SETTING... Guida

Juniper

Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 R2 -... Manuale utente

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - IP-IPV6-IGP CONFIGURATION GUIDE... Manuale utente

Juniper

Juniper JUNOSE 11.0.2 RELEASE NOTES Manuale di istruzioni

Juniper

Juniper JUNOS OS 10.4 - PROTECTED SYSTEM DOMAIN Manuale utente

Juniper

Juniper JUNOS PULSE 2.0 RELEASE NOTES Manuale di istruzioni

Juniper

Juniper POLICY MANAGEMENT - CONFIGURATION GUIDE... Manuale utente

Juniper

Juniper JUNOS OS 10.4 - FOR EX REV 1 Manuale utente

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - S... Manuale di istruzioni

Juniper

Juniper NETWORK AND SECURITY MANAGER 2010.4 - API GUIDE REV... Manuale utente

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - LINK LAYER CONFIGURATION GUIDE... Manuale utente

Juniper

Juniper NETWORK AND SECURITY MANAGER 2010.4 - REV1 Manuale utente

Juniper

Juniper STRM 2008.2 RELEASE NOTES Manuale di istruzioni

Juniper

Juniper JUNOS SPACE 2.0 - RELEASE NOTES Manuale utente

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - COMMAND REFERENCE A TO M... Manuale di installazione

Manuali Software popolari di altre marche

COMPRO

COMPRO COMPROFM Manuale utente

Muratec

Muratec OFFICEBRIDGE ONLINE Manuale utente

Oracle

Oracle Contact Center Anywhere 8.1 Manuale utente

Adobe

Adobe 65007312 - Photoshop Lightroom Manuale

Avaya

Avaya NULL One-X for RIM Blackberry Manuale utente

HP ProLiant BL420c Manuale utente

PS Audio

PS Audio PowerPlay Manuale del proprietario

Brady

Brady LOCKOUT PRO 3.0 Manuale di servizio

Avaya

Avaya Interaction Center Manuale utente

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuale

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuale utente

Oracle

Oracle Application 9i Manuale utente

Acer

Acer RDM Manuale utente

Canon

Canon Vixia HF21 Manuale utente

Canon

Canon ZR950 Manuale utente

Samsung

Samsung Auto Backup Manuale utente

Polycom

Polycom Vortex EF2201 Istruzioni per l'installazione e il funzionamento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuale utente

Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 R2 - INSTALLATION... Manuale utente

Manuali Software popolari di altre marche
