Juniper SECURITY THREAT RESPONSE MANAGER - LOG MANAGEMENT INSTALLATION REV... Manuale utente

Juniper Networks, Inc.

1194 North Mathilda Avenue

Sunnyvale, CA 94089

USA

408-745-2000

www.juniper.net

Part Number:530-027302-01, Revision 1

Security Threat Response Manager

STRM Log Management Installation

Guide

Release 2008.2 R2

2

Networks Inc. in the United States and other countries. All other trademarks, service marks, registered trademarks, or registered service marks in this

document are the property of Juniper Networks or their respective owners. All specifications are subject to change without notice. Juniper Networks

assumes no responsibility for any inaccuracies in this document or for any obligation to update information in this document. Juniper Networks reserves

the right to change, modify, transfer, or otherwise revise this publication without notice.

FCC Statement

The following information is for FCC compliance of Class A devices: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. The equipment generates, uses, and can radiate radio-frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference, in which case users will be required to correct the interference at their own expense. The following

information is for FCC compliance of Class B devices: The equipment described in this manual generates and may radiate radio-frequency energy. If it

is not installed in accordance with NetScreen’s installation instructions, it may cause interference with radio and television reception. This equipment has

been tested and found to comply with the limits for a Class B digital device in accordance with the specifications in part 15 of the FCC rules. These

specifications are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Consult the dealer or an experienced radio/TV

technician for help. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

Caution: Changes or modifications to this product could void the user's warranty and authority to operate this device.

Disclaimer

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET

THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE

SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR JUNIPER NETWORKS REPRESENTATIVE FOR A COPY.

STRM Log Management Installation Guide

Release 2008.2 R2

Revision History

September 2008—Revision 1

The information in this document is current as of the date listed in the revision history.

CONTENTS

ABOUT THIS GUIDE

Conventions 1

Technical Documentation 1

Contacting Customer Support 2

1PREPARING FOR YOUR INSTALLATION

Deploying STRM-LM 3

Additional Hardware Requirements 4

Additional Software Requirements 4

Browser Support 4

Preparing Your Network Hierarchy 5

Identifying Network Settings 5

Identifying Security Monitoring Devices 6

2INSTALLING STRM-LM

Setting Up Appliances 9

Installing Japanese Support 14

Accessing STRM-LM 15

ACHANGING NETWORK SETTINGS

Changing Network Settings in an All-in-One Console 17

Changing the Network Settings of a Console in a Multi-System Deployment 18

Changing the Network Settings of a Non-Console in a Multi-System Deployment 21

INDEX

STRM-LM Installation Guide

Juniper

Networks ABOUT THIS GUIDE

The STRM-LM Installation Guide provides you with information on setting up

STRM-LM. This guide assumes a working knowledge of networking and Linux

systems.

Conventions Table 1 lists conventions that are used throughout this guide.

Technical

Documentation

You can access technical documentation, technical notes, and release notes

directly from the Qmmunity web site at https://support@juniper.net. Once you

access the Qmmunity web site, locate the product and software release for which

you require documentation.

Your comments are important to us. Please send your e-mail comments about this

guide or any of the Juniper Networks documentation to:

documentation@juniper.net.

Include the following information with your comments:

•Document title

•Page number

Table 1 Icons

Icon Type Description

Information note Information that describes important features or

instructions.

Caution Information that alerts you to potential loss of

data or potential damage to an application,

system, device, or network.

Warning Information that alerts you to potential personal

injury.

STRM-LM Installation Guide

2ABOUT THIS GUIDE

Contacting

Customer Support

To help you resolve any issues that you may encounter when installing or

maintaining STRM-LM, you can contact Customer Support as follows:

•Log a support request 24/7: https://support@juniper.net

For access to the Qmmunity web site, please contact Customer Support.

•Access Qmmunity and Self-Service support using e-mail: support@juniper.net

•Telephone assistance: 1.866.377.7000

STRM-LM Installation Guide

1PREPARING FOR YOUR

INSTALLATION

This chapter provides information for when planning your STRM-LM deployment

including:

•Deploying STRM-LM

•Additional Hardware Requirements

•Additional Software Requirements

•Browser Support

•Preparing Your Network Hierarchy

•Identifying Network Settings

•Identifying Security Monitoring Devices

Your STRM-LM deployment may consist of STRM-LM installed on one or multiple

systems. You can also connect one or multiple STRM 1601system to your

STRM-LM system. For more information on appliances, see the Hardware

Installation Guide.

To ensure a successful STRM-LM deployment, adhere to the recommendations in

this document.

Deploying

STRM-LM

You can deploy STRM-LM using appliances or STRM-LM software installed on

your own hardware. A STRM-LM appliance includes STRM-LM software and a

CentOS-4 operating system. For further information on STRM appliances, see the

Hardware Installation Guide.

STRM-LM components that may exist in your deployment include:

Note: For more information on each STRM-LM component, see the STRM-LM

Administration Guide.

•Console - Provides the interface for STRM-LM. The Console is accessed from

a standard web browser. When you access the system, a prompt appears for a

user name and password, which is configured during the installation process.

You must also have Java installed. For information on software requirements,

see Additional Software Requirements.

STRM-LM Installation Guide

4PREPARING FOR YOUR INSTALLATION

•Event Collector - The Event Collector gathers events from local and remote

device sources. The Event Collector normalizes events and sends the

information to the Event Processor. Before being sent to the Event Processor,

the Event Collector bundles identical events to conserve system usage.

•Event Processor - Processes events collected from one or more Event

Collector(s). Once received, the Event Processor correlates the information

from STRM-LM and distributes to the appropriate area, depending on the type

of event. Rules are applied to the events that allow the Event Processor to

process according to the configured rules.

Additional

Hardware

Requirements

Before installing your STRM-LM systems, make sure you have access to the

additional hardware components:

•Monitor and keyboard or a serial console

•To make sure that your STRM-LM data is preserved during a power failure, we

highly recommend that all STRM-LM appliances or systems running STRM-LM

software storing data (such as, Consoles or Event Processors) be equipped

with a Uninterrupted Power Supply (UPS).

Additional Software

Requirements

Before installing STRM-LM, make sure you have Java Runtime Environment

installed on your system. You can download Java version 1.5.0_15 at the following

web site: http://java.com/

Browser Support You must have a browser installed on your client system to access the STRM-LM

interface. STRM-LM supports the following web browsers:

- Microsoft Internet Explorer 6.0/7.0

- Firefox 2.0

Preparing Your

Network Hierarchy

STRM-LM uses the network hierarchy to understand your network traffic and

provide you with the ability to view network activity for your entire deployment.

STRM-LM supports any network hierarchy that can be defined by a range of IP

addresses. You can create your network based on many different variables,

including geographical or business units. For example, your network hierarchy

may include corporate IP address ranges (internal or external), physical

departments or areas, mails servers, and web servers.

Once you define the components you wish to add to your network hierarchy and

install STRM-LM, you can then configure the network hierarchy using the

STRM-LM interface. For each component you wish to add to your network

hierarchy, use the following table to indicate each component in your network map.

STRM-LM Installation Guide

Identifying Network Settings 5

At a minimum, we recommend that you define objects in the network hierarchy for:

•Internal/external Demilitarized zone (DMZ)

•VPN

•All internal IP address space (for example, 0.0.0.0/8)

•Proxy servers

•Network Address Translation (NAT) IP address range

•Server Network subnets

•Voice over IP (VoIP) subnets

For more information, see the STRM-LM Administration Guide - Setting Up

STRM-LM, Creating Your Network Hierarchy.

Identifying Network

Settings

Before you install STRM-LM, you must have the following information for each

system you wish to install:

•Hostname

•IP address

•Network Mask address

•Subnet Mask

•Default Gateway

•Primary DNS Server

•Secondary DNS Server (Optional)

•Public IP address for networks using Network Address Translation (NAT)

•E-mail Server

•NTP Server (Console only) or Time server

Identifying Security

Monitoring Devices

STRM-LM can collect and correlate events received from external sources such as

security equipment (for example, firewalls, VPNs, or IDSs) and host or application

security logs, such as, window logs. Device Support Modules (DSMs) allows you

to integrate STRM-LM with this external data.

Table 1-1 Network Hierarchy

Description Name IP/CIDR Value Weight

STRM-LM Installation Guide

6PREPARING FOR YOUR INSTALLATION

STRM-LM automatically discovers sensor devices that are sending syslog

messages to an Event Collector. Any sensor devices that are automatically

discovered by STRM-LM appear in the Sensor Devices window within the

STRM-LM Administration Console. For more information, see Chapter 4 Using the

Deployment Editor of the STRM-LM Administration Guide.

Non-syslog based information sources must be added to your deployment

manually. For more information, see the Managing Sensor Devices Guide. For

each device you wish to add to your deployment, record the device in Ta b l e 1 - 2 .

Where:

•Link Speed & Type indicates the maximum network link (in Kbps) for firewall,

router, and VPN devices. Record the primary application of the host system, for

example, e-mail, anit-virus, domain controller, or a workstation.

•Msg Level indicates the message level you wish to log. For example, critical,

informational, debug.

•No. of Users indicates the maximum number of hosts/users using or being

served by tis device.

•Network Location indicates whether this device is located on the Internet

DMZ, Intranet, or Extranet DMZ.

•Geographic Location indicates if the device is located on the same LAN as

STRM-LM or sending logs over the WAN identified in the Link Speed & Type

column.

•Credibility indicates the integrity of an event as determined by the credibility

rating from source devices. Credibility increases as multiple sources report the

same event.

Table 1-2 Devices

Device

Type QTY

Product

Name/

Version

Link

Speed

& Type

Msg

Level

Avg Log

Rate

(Event/Sec)

No. of

Users

Network

Location

Geographic

Location

Credibility

(0 to 10)

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Juniper Software

Juniper

Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 R2 - INSTALLATION... Manuale utente

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - BGP AND MPLS CONFIGURATION GUIDE... Manuale utente

Juniper

Juniper STRM 2008-2 - TECHNICAL NOTE CHANGING NETWORK SETTING... Manuale di installazione e funzionamento

Juniper

Juniper JUNOS SOFTWARE 10.2 - SOFTWARE INSTALLATION AND UPGRADE GUIDE... Manuale di installazione e funzionamento

Juniper

Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 - CATEGORY OFFENSE INVESTIGATION GUIDE REV... Manuale utente

Juniper

Juniper JUNOSE FOR E SERIES BROADBAND SERVICES ROUTERS - S... Manuale di istruzioni

Juniper

Juniper POLICY MANAGEMENT - CONFIGURATION GUIDE... Manuale utente

Juniper

Juniper TEPM AGENT - RELEASE NOTES 17-12-10 Manuale di istruzioni

Juniper

Juniper NETWORK AND SECURITY MANAGER 2010.4 - ADMININISTRATION GUIDE... Manuale di istruzioni

Juniper

Juniper JUNOSE SOFTWARE 11.0.X - COMMAND REFERENCE A TO M... Manuale di installazione

Juniper

Juniper STRM Manuale utente

Juniper

Juniper JUNOSE 11.0.X PHYSICAL LAYER Manuale utente

Juniper

Juniper IP SERVICES - CONFIGURATION GUIDE V 11.1.X Manuale utente

Juniper

Juniper MEDIA FLOW PUBLISHER Manuale utente

Juniper

Juniper IDP OS 5.1R1 - S REV 1 Manuale di istruzioni

Juniper

Juniper JUNOSE 11.2.X PHYSICAL LAYER Manuale utente

Juniper

Juniper IGP - CONFIGURATION GUIDE V11.1.X Manuale utente

Juniper

Juniper CARE PLUS Manuale utente

Juniper

Juniper JUNOS 10.1 - CONFIGURATION GUIDE 1-2010 Manuale utente

Juniper

Juniper STRM 2008-2 - TECHNICAL NOTE CHANGING NETWORK SETTING... Guida

Juniper

Juniper ADVANCED INSIGHT SCRIPTS 2.5 - S REV 1 Manuale di istruzioni

Juniper

Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 - EVENT CATEGORY CORRELATION REV... Manuale utente

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.0.X - BGP AND MPLS CONFIGURATION GUIDE... Manuale utente

Juniper

Juniper TEPM AGENT - RELEASE NOTES 17-12-10 Manuale di istruzioni

Manuali Software popolari di altre marche

COMPRO

COMPRO COMPROFM Manuale utente

Muratec

Muratec OFFICEBRIDGE ONLINE Manuale utente

Oracle

Oracle Contact Center Anywhere 8.1 Manuale utente

Adobe

Adobe 65007312 - Photoshop Lightroom Manuale

Avaya

Avaya NULL One-X for RIM Blackberry Manuale utente

HP ProLiant BL420c Manuale utente

PS Audio

PS Audio PowerPlay Manuale del proprietario

Brady

Brady LOCKOUT PRO 3.0 Manuale di servizio

Avaya

Avaya Interaction Center Manuale utente

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuale

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuale utente

Oracle

Oracle Application 9i Manuale utente

Acer

Acer RDM Manuale utente

Canon

Canon Vixia HF21 Manuale utente

Canon

Canon ZR950 Manuale utente

Samsung

Samsung Auto Backup Manuale utente

Polycom

Polycom Vortex EF2201 Istruzioni per l'installazione e il funzionamento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuale utente
