Keysight Technologies E8257DS Series Manuale utente

Notice: This document contains references to Agilent.

Please note that Agilent’s Test and Measurement business

has become Keysight Technologies. For more information,

go to www.keysight.com.

Millimeter

Source Modules

Keysight Technologies

E8257DS02-S15



User’s Guide

Notices

2019

No part of this manual may be

reproduced in any form or by any

means (including electronic storage

and retrieval or translation into a

foreign language) without prior

agreement and written consent

from Keysight Technologies, Inc. as

governed by United States and

international copyright laws.

Manual Part Number

E8251-90283

Print Date

January 2019

Supersedes: August 2014

Printed in USA

Keysight Technologies Inc.

1400 Fountaingrove Parkway

Santa Rosa, CA 95403

Where to Find the Latest

Information

Documentation isupdated

periodically.Forthelatestinformation

about these products, including

instrument software upgrades,

application information, and product

information, browse to the following

URL, search for the name of your

product:

http://www.keysight.com/find



Technology Licenses

The hardware and/or software

described in this document are

furnished under a license and may be

used or copied only in accordance

with the terms of such license.



Restricted Rights Legend

If software is for use in the

performance of a U.S. Government

prime contract or subcontract,

Software is delivered and licensed as

“Commercial computersoftware” as

defined in DFAR 252.227-7014 (June

1995), or as a “commercial item” as

defined in FAR 2.101(a) or as

“Restricted computer software” as

definedinFAR52.227-19(June1987)

oranyequivalentagencyregulationor

contract clause. Use, duplication or

disclosure of Software is subject to

Keysight Technologies’ standard

commercial license terms, and

non-DOD Departments and Agencies

oftheU.S.Governmentwillreceiveno

greater than Restricted Rights as

defined in FAR 52.227-19(c)(1-2)

(June 1987). U.S. Government users

will receive no greater than Limited

Rights as defined in FAR 52.227-14

(June 1987) or DFAR 252.227-7015

(b)(2)(November1995), asapplicable

in any technical data.



Warranty

THE MATERIAL CONTAINED IN THIS

DOCUMENT IS PROVIDED “AS IS,” AND IS

SUBJECT TO BEING CHANGED, WITHOUT

NOTICE, IN FUTURE EDITIONS. FURTHER,

TO THE MAXIMUM EXTENT PERMITTED

BY APPLICABLE LAW, KEYSIGHT

DISCLAIMS ALL WARRANTIES, EITHER

EXPRESS OR IMPLIED WITH REGARD TO

THIS MANUAL AND ANY INFORMATION

CONTAINED HEREIN, INCLUDING BUT

NOT LIMITED TO THE IMPLIED

WARRANTIESOFMERCHANTABILITYAND

FITNESS FOR A PARTICULAR PURPOSE.

KEYSIGHT SHALL NOT BE LIABLE FOR

ERRORS OR FOR INCIDENTAL OR

CONSEQUENTIAL DAMAGES IN

CONNECTION WITH THE FURNISHING,

USE, OR PERFORMANCE OF THIS

DOCUMENT OR ANY INFORMATION

CONTAINED HEREIN. SHOULD KEYSIGHT

AND THE USER HAVE ASEPARATE

WRITTEN AGREEMENT WITH WARRANTY

TERMSCOVERINGTHEMATERIALINTHIS

DOCUMENTTHATCONFLICTWITHTHESE

TERMS, THE WARRANTY TERMS IN THE

SEPARATE AGREEMENT WILL CONTROL.



Safety Notices

CAUTION

ACAUTIONnoticedenotesahazard.It

calls attention to an operating

procedure,practice,or the like that, if

notcorrectlyperformedoradheredto,

couldresult indamagetotheproduct

or loss of important data. Do not

proceed beyond a CAUTION notice

untiltheindicatedconditionsarefully

understood and met.

WARNING

A WARNING notice denotes ahazard.

It calls attention to an operating

procedure,practice,or the like that, if

notcorrectlyperformedoradheredto,

could result in personal injury or

death. Do not proceed beyond a

WARNING notice until the indicated

conditions are fully understood and

met.

Table of Contents

Keysight E8257DS02-S15

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Content List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

System Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Performance Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Attenuator Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

A25 - Manually Adjustable Attenuator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

EA2 - Electronically Controlled Attenuator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Safety and Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Safety Earth Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Statement of Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Before Applying Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connector Care and Cleaning Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Electrostatic Discharge Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Instrument Markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Electrical Safety Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

EMC Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Keysight Support, Services, and Assistance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Service and Support Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Contacting Keysight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Shipping Your Product to Keysight for Service or Repair . . . . . . . . . . . . . . . . . . . . . . . 13

User’s Guide E8251-90283 1

E8257DS02-S15

2 User’s Guide E8251-90283

E8257DS02-S15

Introduction

The E8257DS02, S03, S05, S06, S08, S10, S12, and S15 are Millimeter-wave Source Modules

that are manufactured by Oleson Microwave Labs (OML) and is provided as an ordering

convenience by Keysight Technologies. This product can be ordered directly from OML. For

additional Millimeter-wave Source Modules information go to the Keysight website at

http://www.keysight.com/find

This product is warranted by OML against defective materials and workmanship. Refer to

documentation supplied with this product or go to http://www.omlinc.com for more

information.

A periodic calibration is not required for millimeter-wave modules.

Content list

Each source module ordered includes one each of the standard accessories listed below:

• Source Module Interface cable (2 meter)

• RF cable SMA (m) to SMA (m) (1 meter)

Description

The millimeter-wave source modules are designed to work with the E8247C, E8257C, E8257D,

E8267C or E8267D PSG Series Synthesized Sources.

The following list of adapters are required to connect the PSG RF Output to the millimeter-

wave source module RF Input. The adapter is included with the PSG product, but is not

included with the millimeter-wave source module. Refer to the following table for required

adapters.

Table1 Adapters

Instrument Options Adapter Description Keysight

Part Number

520 3.5 mm (f) to (f) 5061-5311

532, 540, 550 and 567 2.4 mm (f) to 3.5 mm (f) 1250-2187

1ED 3.5 mm (f) to Type-N (m) 1250-1744

The E8257DSxx millimeter-wave source modules can be driven directly from

the E8257D or E8267D-1EU Performance Signal Generators (PSGs) or from

other MXG/ESG Signal Generators with the OML VDCPW09-4, 9 VDC Power

Supply (7-pin output circular jack).

Only Keysight-approved accessories shall be used.

User’s Guide E8251-90283 3

E8257DS02-S15

System Setup

1. Connect the interface cable (included with this option) from the millimeter-wave source

module and to the rear panel on the PSG. Refer to Figure 1.

2. Connect the RF cable (included with this option) from the SMA RF Input connector on the

millimeter-wave source module to the RF Output connector on the PSG, using the adapter

listed in Table 1. Refer to Figure 2.

Figure 1 Interface Cable Installation

Figure 2 RF Cable Installation

Interface Cable

Source Module Interface Connecto

RF Cable

Millimeter

Source RF Output

RF Cable

4 User’s Guide E8251-90283

E8257DS02-S15

Performance Specifications

The following table provides specifications or each of the millimeter source models. Refer to the

millimeter source module used for your application. All specification apply over a temperature

range of +20 to +30 °C.

Table 2 Millimeter Source Model Performance Specifications

Item1

1. Specifications subject to change without notice.

S15 S12 S10 S08 S06 S05 S03 S02

Multipliers x4x6x6x8x12x12x18x30

FREQ IN (GHz) 12.5 to

18.7

10.0 to

15.0

12.5 to

18.4

11.2 to

17.5

9.1 to

14.1

11.6 to

18.4

12.2 to

18.1

10.83 to

16.67

FREQ OUT (GHz) 50.0 to

75.0

60.0 to

90.0

75.0 to

110.0

90.0 to

140.0

110.0 to

170.0

140.0 to

220.0

220.0 to

325.0

325 to 

500

RF IN +10 dBm

RF IN Damage Level +36 dBm

RF OUT2 (typical)

2. Not traceable to NIST above 110 GHz.

+8 dBm +6 dBm +5 dBm -5 dBm -13 dBm -15 dBm3

3. Up to 200 GHz, rolling off at -25 dBm typical at 220 GHz as measured by OML’s calorimeter.

-25 dBm4

4. Output power estimated due to sensitivity limitation of OML’s calorimeter, measured power data not traceable or

provided.

-27 dBm4

Harmonics &

Sub-Harmonics5

(typical)

5. As related to the desired output frequencies.

 -20 dBc

In-Band Spurious6

(typical)

6. In-band mixing products. Typically -15 dBc in the lower 10% of WR-15, WR12, or WR10 waveguide band.

 -20 dBc

-15 dBc (in the lower 10% band) -20 dBc

RF IN VSWR 

(typical) 2

RF OUT VSWR

(typical)  1.7 1.7  1.7  1.7 1.7  1.7 3.0  3.0

RF IN Port SMA Female

Manually Adjustable

Attenuator7

7. Available as Option A25. Not available in the E8257DS02 module.

25 dB minimum n/a

RF OUT Port8

8. RF Output port flange configuration per MIL-F-3922-67B-xx.

WR-15 WR-12 WR-10 WR-08 WR-06 WR-05 WR-03 WR-02

Power (typical) Supplied by E82xx Series PSG (+8 Vdc at 1.2 A max, +15 Vdc at 150 mA max)

User’s Guide E8251-90283 5

E8257DS02-S15

Performance Specifications

The following OML millimeter-wave source module model part numbers corresponding with the

Keysight model part numbers.

Table 3 Instrument Dimensions

Net Weight Height1Width Depth2

< 2.0 lb (907 g) nominal



< 4.0 lb (1.8 kg)3 2.8 in (7.11 cm) 4.3 in (10.92 cm) 5.7 in (14.47 cm)

9.5 in (24.13 cm)3

1. Height excludes the adjustable rubber feet length and attenuator adjustment knob.

2. Depth dimension excludes the output waveguide length.

3. Option EA2.

Table 5OML and Keysight Model Numbers

OML

Model Number Keysight

Model Number

S15MS-AG E8257DS15

S12MS-AG E8257DS12

S10MS-AG E8257DS10

S08MS-AG E8257DS08

S06MS-AG E8257DS06

S05MS-AG E8257DS05

S03MS-AG E8257DS03

S02MS-AG E8257DS02

Table 4 Power Supply Voltage, Frequency, and Power Ratings

Nominal Voltage and/or Range: Input: 100-240 VAC (AC/DC Adapter)

Output: 9 VDC (AC/DC Adapter)

Nominal Frequency and/or Range: Input: 5/60 Hz (AC/DC Adapter)

Power in Watts, VA, or Current: Input: 1.0 A (AC/DC Adapter)

Output: 4.45 A, 40 W Max (AC/DC Adapter)

Environmental Conditions

For indoor use only.

6 User’s Guide E8251-90283

E8257DS02-S15

Performance Specifications

Attenuator Options

Attenuator options will slightly degrade the maximum power output from the module.

A25- Manually Adjustable Attenuator

• micrometer controlled

• 25 dB range minimum (not available on the E8257DS02)

EA2- Electronically Controlled Attenuator

Available on the E8257DS12 (only).

• inside modules chassis (controlled by DC voltage)

•increases module size

• 50 dB attenuator range

• use PSG LF Out = DC (0-3.5 V, 110 mA max) to control

— requires PSG Option UNT

• includes 20 dB fixed waveguide attenuator

• includes correction files on USB drive (output power vs frequency & LF voltage)

Figure 3 EA2 Rear Panel

Interface Cable (PSG) RF Cable (PSG)

V-tune (PSG LF OUT)

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Keysight Technologies Unità di controllo

Keysight Technologies

Keysight Technologies M937A Series Manuale utente

Keysight Technologies

Keysight Technologies M9195A PXIe Guida utente

Keysight Technologies

Keysight Technologies M8000 Series Manuale utente

Keysight Technologies

Keysight Technologies E4461B Manuale utente

Keysight Technologies

Keysight Technologies 8495D Manuale di servizio

Keysight Technologies

Keysight Technologies M8197A Manuale utente

Keysight Technologies

Keysight Technologies 34946A Manuale utente

Keysight Technologies

Keysight Technologies J7201A Manuale di servizio

Keysight Technologies

Keysight Technologies 75000 C Series Manuale utente

Keysight Technologies

Keysight Technologies M8192A Manuale utente

Keysight Technologies

Keysight Technologies 11713D Manuale di servizio

Keysight Technologies

Keysight Technologies 11713B Manuale di servizio

Keysight Technologies

Keysight Technologies 81618A Manuale utente

Keysight Technologies

Keysight Technologies J7211A Manuale di servizio

Keysight Technologies

Keysight Technologies N3301A Istruzioni operative

Keysight Technologies

Keysight Technologies 8494 Manuale di servizio

Keysight Technologies

Keysight Technologies M9101A Manuale operativo

Keysight Technologies

Keysight Technologies J7204A Manuale di servizio

Keysight Technologies

Keysight Technologies 34931A Manuale utente

Keysight Technologies

Keysight Technologies 34941A Manuale utente

Keysight Technologies

Keysight Technologies VXI bus 75000 C Series Manuale utente

Keysight Technologies

Keysight Technologies 81650A Manuale utente

Keysight Technologies

Keysight Technologies N9029BV Manuale di servizio

Keysight Technologies

Keysight Technologies M9170A Manuale utente

Manuali Unità di controllo popolari di altre marche

Festo

Festo Compact Performance CP-FB6-E Manuale elenco delle parti

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuale utente

JS Automation

JS Automation MPC3034A Manuale utente

JAUDT

JAUDT SW GII 6406 Series Guida rapida

Spektrum

Spektrum Air Module System Manuale utente

BOC Edwards

BOC Edwards Q Series Manuale utente

KHADAS

KHADAS BT Magic Manuale utente

Etherma

Etherma eNEXHO-IL Manuale utente

PMFoundations

PMFoundations Attenuverter Manuale utente

GEA

GEA VARIVENT Manuale utente

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuale utente

Altronix

Altronix LINQ8PD Istruzioni per il montaggio

Eaton

Eaton Powerware Series Manuale utente

WAGO

WAGO 750-407/040-000 Manuale utente

Sony

Sony CCU-590 Manuale utente

Graco

Graco 25D614 Manuale utente

Task Force Tips

Task Force Tips YE-RF-900 Manuale di programmazione

Shini

Shini SPV-U Series Manuale utente
