KitchenAid 5KFPM770 Guida rapida

English

Model 5KFPM770

Food Processor

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUKTIONER OG OPSKRIFTER

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

FOOD PROCESSOR

INSTRUCTIONS AND RECIPES

English

Table of Contents

Food Processor Safety....................................................................................3

Electrical Requirements..................................................................................3

Important Safeguards....................................................................................4

Food Processor Features ...............................................................................5

Preparing the Food Processor for Use

Before First Use.......................................................................................7

Work Bowl Assembly .............................................................................7

Multipurpose Blade & Dough Blade Assembly ........................................8

Slicing & Shredding Disc Assembly .........................................................8

Mini Bowl Assembly................................................................................9

Chef’s Bowl Assembly ............................................................................9

Egg Whip Assembly & Use....................................................................10

Citrus Press Assembly & Use..................................................................10

Using the Food Processor

Before Use ............................................................................................12

Food Pusher Interlock ..........................................................................12

Maximum Liquid Level .........................................................................12

Turning the Food Processor On and Off ...............................................12

Using the Pulse Control .......................................................................13

2-Piece Food Pusher .............................................................................13

Disassembling the Food Processor ..............................................................13

Care and Cleaning.......................................................................................15

Troubleshooting .........................................................................................16

Food Processing Tips ...................................................................................17

Using the Multipurpose Blade...............................................................17

Using a Slicing or Shredding Disc..........................................................18

Using the Dough Blade.........................................................................19

Using the Egg Whip..............................................................................19

Helpful Hints.........................................................................................20

Recipes........................................................................................................22

Warranty and Service Information

Household KitchenAid®Food Processor Warranty for Europe ................27

Service Centers......................................................................................27

Customer Service ..................................................................................28

Model 5KFPM770:

220-240 Volts A.C.

Hertz: 50/60 Hz

NOTE: Model 5KFPM770 has a

grounded plug. To reduce the risk of

electrical shock, this plug will fit in

an outlet only one way. If the plug

does not fit in the outlet, contact a

qualified electrician. Do not modify

the plug in any way.

Do not use an extension cord. If the

power supply cord is too short, have

a qualified electrician or serviceman

install an outlet near the appliance.

English

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on

your appliance. Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt

you and others.

All safety messages will follow the safety alert symbol and either

the word “DANGER” or “WARNING.” These words mean:

You can be killed or seriously

injured if you don’t immediately

follow instructions.

You can be killed or seriously

injured if you don’t follow

instructions.

All safety messages will tell you what the potential hazard is, tell you how to

reduce the chance of injury, and tell you what can happen if the instructions

are not followed.

DANGER

WARNING

Food Processor Safety

Electrical Requirements

English

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed, including the following:

1. Read all instructions.

2. To protect against risk of electrical shock do not put Food Processor in

water or other liquid.

3. Close supervision is necessary when any appliance is used by or near

children.

4. Unplug from the outlet when not in use, before putting on or taking off

parts, and before cleaning.

5. Avoid contacting moving parts.

6. Do not operate any appliance with a damaged cord or plug, or after the

appliance malfunctions, or is dropped or damaged in any manner. Return

appliance to the nearest Authorized Service Facility for examination,

repair, or electrical or mechanical adjustment.

7. The use of attachments not recommended or sold by the manufacturer

may cause fire, electric shock or injury.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter.

10. Keep hands and utensils away from moving blades or discs while

processing food to reduce the risk of severe injury to persons or damage

to the Food Processor. A scraper may be used but must be used only

when the Food Processor is not running.

11. Blades are sharp. Handle carefully.

12. To reduce the risk of injury, never place cutting blade or discs on base

without first putting bowl properly in place.

13. Be certain cover is securely locked in place before operating appliance.

14. Never feed food by hand. Always use the food pusher.

15. Do not attempt to defeat the cover interlock mechanism.

16. This product is designed for household use only.

SAVE THESE INSTRUCTIONS

English

Food Processor Features

Medium (4 mm)

Shredding Disc

Fine (2 mm)

Slicing Disc

Stainless Steel

Multipurpose Blade

Dough Blade

Die-Cast Metal Base

2-Piece

Food Pusher

Work Bowl Cover

with Ultra Wide

Mouth Feed Tube

Work Bowl

950 ml (4 cup)

Mini Bowl and

Mini Blade

Medium (4 mm)

Slicing Disc

Spatula/

Cleaning

Tool

2.4 liters (10 cup)

Chef's Bowl

Citrus

Press

2-Piece

Cone

Disc Stem

Egg Whip

English

Food Processor Features

Work Bowl Cover with

Ultra Wide Mouth Feed Tube

One of the industry’s largest, the

Ultra Wide Mouth feed tube

accommodates large items –

like tomatoes, cucumbers, and

potatoes – with a minimum of

sectioning or slicing.

2-Piece Food Pusher

For smaller items, remove the small

pusher from the central tube in the

large pusher. The small pusher and

feed tube make it easy to process

herbs, nuts, single carrots and celery.

The small pusher can also be used as

a convenient 115 g measuring cup.

2.8 Liters Work Bowl

The tough polycarbonate bowl

provides capacity for large jobs.

Chef’s Bowl

Place the 2.4 liters Chef’s Bowl

inside the Work Bowl, and slice or

shred a food item while keeping the

Work Bowl clean for another

ingredient.

Mini Bowl and Mini Blade

950 ml bowl and stainless steel

blade are perfect for small chopping

and mixing jobs.

Fine (2 mm) Slicing Disc

Disc produces approximately

1.6 mm slices of most foods, from

delicate strawberries to partially

frozen meats.

Medium (4 mm) Slicing Disc

Disc produces approximately

3.2 mm slices slices of most foods.

Medium (4 mm) Shredding Disc

Disc produces approximately

3.2 mm shreds of most firm fruits,

vegetables, and cheese.

Disc Stem

Stem fits over the power shaft on

the base and into the bottom of a

slicing or shredding disc.

Stainless Steel

Multipurpose Blade

Versatile blade chops, minces,

blends, mixes, and emulsifies in a

matter of seconds.

Dough Blade

The dough blade is specially

designed for mixing and kneading

yeast dough.

Egg Whip

The egg whip will quickly whip

cream and egg whites for

meringues, mousses, soufflés, and

desserts.

Citrus Press

Press consists of a

Strainer Basket,

2-Piece Cone, and

Lever Arm. Use the

removable outer cone for

larger items, such as

grapefruit, and the inner cone for

lemons and limes.

Heavy-Duty Base

The base features the “O”, “I”, and

Pulse Buttons along with the power

shaft, which rotates the blades and

discs.

Spatula/Cleaning Tool

Special shape facilitates food

removal from bowls, discs, and

blades.

Chef’s Accessory

Case

Stylish and durable

slim-line case

organizes and protects

blades, discs, and accessories.

English

Preparing the Food Processor for Use

Before First Use

Before using your Food Processor for

the first time, wash the work bowl,

work bowl cover, chef’s bowl, mini

bowl, feed tube pusher, discs, and

blades either by hand or in the

dishwasher (see “Care and Cleaning”

on page 15).

Work Bowl Assembly

1. Place the Food Processor base on

a dry, level countertop with the

controls facing forward. Do not

plug in the unit until it is

completely assembled.

2. With the handle just to the left of

center, place the work bowl on

the base, fitting the center

opening over the power shaft.

3. Grasp the work bowl handle and

turn the bowl to the right until it

locks into position.

4. Insert the desired accessory into

the work bowl. See pages 7–11

for accessory instructions.

5. Place the work bowl cover on the

work bowl with the feed tube

just to the left of the work bowl

handle. Grasp the feed tube and

turn the cover to the right until it

locks into place.

NOTE: Do not attach the cover to

the work bowl before the work bowl

is locked on the base. Damage to

the work bowl may result.

6. Fit the 2-piece food pusher into

the feed tube.

Continued on next page

English

Preparing the Food Processor for Use

7. Plug into a proper electrical outlet

(see

“

Electrical Requirements” on

page 3).

NOTE: Your Food Processor will not

operate unless the work bowl and

work bowl cover are properly locked

on the base, and the pusher is

inserted to the maximum fill line on

the feed tube.

Do not remove the work bowl

from the base without first removing

the work bowl cover. Damage to the

work bowl may result.

Multipurpose Blade and

Dough Blade Assembly

Place the blade on the power shaft.

Rotate the blade so it falls into place

on the shaft.

Slicing and Shredding Disc

Assembly

1. Place the disc stem on the power

shaft.

English

Preparing the Food Processor for Use

2. Fit the disc over the metal pin

on the disc stem, then rotate

the disc until it falls fully onto

the stem.

Mini Bowl Assembly

1. Place the mini bowl inside the

work bowl over the power shaft.

Rotate the mini bowl until it falls

into place. When properly seated

in the work bowl, the mini bowl

cannot be rotated.

2. Fit the mini blade on the power

shaft. It may be necessary to

rotate the blade until it falls into

place.

The mini bowl can also be placed

in the chef’s bowl in a similar

manner.

3. To remove the mini bowl after

processing, lift the bowl using

the two finger grips located

along the top edge of the bowl.

Chef’s Bowl Assembly

Place the chef’s bowl inside the

work bowl over the power shaft.

Rotate the chef’s bowl until it falls

into place. When properly seated in

the work bowl, the chef’s bowl

cannot be rotated.

The chef’s bowl can only be used

with the slicing and shredding discs

– the multipurpose blade cannot be

used. To remove the chef’s bowl

after processing, lift the bowl using

the two finger grips located along

the top edge of the bowl.

Continued on next page

English

Preparing the Food Processor for Use

Egg Whip Assembly and Use

The egg whip is designed to whip

egg whites or heavy cream to create

toppings or soft meringues. For the

best results, at least 237 ml (125 g/

1 cup) of heavy cream or 3 egg

whites should be whipped at a time.

Whipping smaller quantities may not

result in maximum volume.

To assemble:

The egg whip consists of 4 pieces –

the egg whip stem, stem cover, whip

paddle, and cap.

1. Place the egg-whip stem on the

power shaft. Slowly turn the stem

until it drops fully onto the shaft.

2. Align the L-shaped notch on the

whip paddle with the small post

on the stem cover, and slide the

paddle onto the cover. Turn

slightly to lock paddle.

3. Fit the stem cover and paddle

over the egg whip stem. Push

downward to engage the ridges

of the stem with the gears of the

paddle.

4. Fit the egg whip cap over the egg

whip stem. Push downward to

lock it into place.

5. Place the work bowl cover on the

work bowl with the feed tube

just to the left of the handle.

Make sure the center pin of the

egg whip fits into the center

opening of the cover. Grasp the

feed tube and turn the cover to

the right to lock it into place.

Insert the pusher into the feed

tube. The egg whip is now ready

to operate.

6. Press the “I” Button and whip

ingredients to the desired texture

and volume. Press the “O” Button

when finished.

To disassemble:

1. Unplug the base from the

electrical outlet. Remove the work

bowl cover with a clockwise turn.

2. Lift the egg whip assembly off

the power shaft. Remove

whipped ingredients from the

work bowl.

3. Pull the cap from the egg whip

assembly. Push downward on the

stem pin to remove stem from

the stem cover. Turn the egg

whip paddle to unlock, and slide

the paddle from the stem cover.

Citrus Press Assembly and Use

1. Position and lock the work bowl

on the base.

2. Place the strainer basket in the

bowl with the locking clip to the

left of the work bowl handle.

3. Turn the basket counter-clockwise

until the clip locks into the handle.

Cap

Stem

Whip

Paddle

Stem

Cover

Altri manuali per 5KFPM770

Indice

Altri manuali KitchenAid Robot da cucina

KitchenAid

KitchenAid KFP0718 Manuale utente

KitchenAid

KitchenAid 5KFPM770 Guida rapida

KitchenAid

KitchenAid KFPM650 Guida rapida

KitchenAid

KitchenAid KFP1333 Istruzioni operative

KitchenAid

KitchenAid PRO LINE KPFP850 series Manuale utente

KitchenAid

KitchenAid KFP740 Guida rapida

KitchenAid

KitchenAid 5KFP1644 Manuale utente

KitchenAid

KitchenAid 5KCF0104 Manuale utente

KitchenAid

KitchenAid 5KFC3516EER Manuale utente

KitchenAid

KitchenAid 5KFP0925 Manuale utente

KitchenAid

KitchenAid KFC3516 Manuale del proprietario

KitchenAid

KitchenAid KSM1FPA Manuale utente

KitchenAid

KitchenAid 5KFC3515 Manuale utente

KitchenAid

KitchenAid KSM12FPA Manuale utente

KitchenAid

KitchenAid 5KFP0921A Manuale utente

KitchenAid

KitchenAid 5KFC0516 Manuale utente

KitchenAid

KitchenAid KFC3516PK0 Manuale utente

KitchenAid

KitchenAid 4KFP730 Guida rapida

KitchenAid

KitchenAid 5KSM2FPA Manuale utente

KitchenAid

KitchenAid KFC3511 Manuale utente

KitchenAid

KitchenAid KSM2FPA Manuale utente

KitchenAid

KitchenAid KFP0924 Manuale utente

KitchenAid

KitchenAid 5KFP1333 Manuale utente

KitchenAid

KitchenAid KFPW760QER - 700 Watt Ultra Wide Mouth Food... Manuale utente

Manuali Robot da cucina popolari di altre marche

INNOLIVING

INNOLIVING INN-727 Manuale utente

Berkel

Berkel C32 Manuale utente

Beko

Beko CHP5554W Manuale utente

QUIGG

QUIGG KM 2017Wi.20 Manuale utente

Lakeland

Lakeland PRESS AND CHOP 31557 Manuale utente

Bosch

Bosch MMR08 GB Series Manuale utente

HOFFEN

HOFFEN Chef Express T9532 Manuale utente

Garland

Garland 852 ZG Manuale utente

Robot Coupe

Robot Coupe CL50 Gourmet Manuale utente

SAPIRHOME

SAPIRHOME SP-1111-K Manuale utente

Moulinex

Moulinex DJ3051 Manuale utente

Bosch

Bosch MUM5 Manuale utente

cecotec

cecotec Mambo Touch Manuale utente

Black & Decker

Black & Decker hc 300 Istruzioni per l'installazione

Gorenje

Gorenje SBR 1000 DV Manuale utente

Arzum

Arzum AR 1128 Manuale utente

Saturn

Saturn ST-FP0069 Manuale utente

Vitek

Vitek VT-1641 W Manuale utente
