KitchenAid KSRS25QDAL00 Manuale utente

CABINET PARTS

For Models: KSRS25QDWH00, KSRS25QDAL00

(White) (Almond)

3−97 Printed In U.S.A. (RCG) Part No. 4379750

REFRIGERATOR

CABINET PARTS

For Models: KSRS25QDWH00, KSRS25QDAL00

(White) (Almond)

4379750

Illus. Part

No. No. DESCRIPTION

Cabinet (Not A

Serviceable Part)

2174748

Front Roller (2)

489456

Screw

981122

Roller (Rear) (2)

489427

Screw

2155013

Clip, Grille

489242

Screw

2176796

Insert, Air Baffle

2156056

Shim

2171868

Shim, Hinge Top

489284

Screw

Hinge Cover

1129262

White

2150343

Almond

2171851

Hinge Bottom (2)

Filler, Wrapper

1110708

White

1110709

Almond

Grille

2155486

White

2155487

Almond

489367

Screw

2171865

Hinge, Top (2)

489337

Screw

937360

Service Cord

940139

Drain Fitting

2172932

Tube, Extension

1108439

Clip, Drain Tube

2172957

Flapper, Drain

Extension

2176140

Cover, Unit

Hinge Cover

1119787

White

1119789

Almond

549193

Clamp, Service

Cord

489084

Screw

2155311

Door Closer,

Lower Cam (2)

489420

Screw

REFRIGERATOR LINER PARTS

For Models: KSRS25QDWH00, KSRS25QDAL00

(White) (Almond)

4379750

Illus. Part

No. No. DESCRIPTION

Liner (Not A

Serviceable Part)

2172954

Escutcheon, Meat

Pan Control

2161489

Slide Meat

Pan Control

658944

Stud

2171846

Release Valve

2172943

Stud (2)

487559

Screw

1110718

Stud (10)

1116794

Ladder, Shelf (2)

486298

Screw (2)

487539

Screw

2179375

Rack, Wine & Egg

1123919

Bracket Retainer

489290

Screw (2)

2161467

Air Diffuser

Assembly

2161470

Air Diffuser

Cover

2150331

Cover, Conduit

2162085

Socket

842534

Clip, Air Duct

2155290

Reservoir

527949

Light Bulb

2174436

Light Lens

488280

Screw (2)

CONTROL PARTS

For Models: KSRS25QDWH00, KSRS25QDAL00

(White) (Almond)

4379750

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

2172930

Control Box

2172948

Tube Barrier,

Thermostat

489214

Screw (3)

1123923

Light Switch

2161461

Thermostat (FC)

2169269

Adaptive Defrost

Control

489398

Screw (2)

2161460

Thermostat (R.C.)

2172940

Window

2172906

Grommet, Light Bar

2161466

Slide, Thermostat

489084

Screw (2)

2179920

Light Bar (RC)

489290

Screw (2)

2162085

Light Socket

2172931

Heat Shield

946059

Light Bulb

2172953

Control Box

Harness

1115374

Clip, Wiring

1115375

Clip, Wiring

2161486

Escutcheon,

Control Box

2179921

Light Bar (FC)

2172941

Window

REFRIGERATOR SHELF PARTS

For Models: KSRS25QDWH00, KSRS25QDAL00

(White) (Almond)

4379750 5

REFRIGERATOR SHELF PARTS

For Models: KSRS25QDWH00, KSRS25QDAL00

(White) (Almond)

4379750

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

2174023

Shelf Assembly,

Cantilever (2)

2174253

Button, Humidity

2174252

Slide, Humidity

2174273

Gasket, Side (2)

2161490

Cover, Meat Pan

(Includes 6, 7,

13, 14, 15 & 20)

1125705

Gasket, Cover

(Front)

2172956

Gasket, Cover

(Rear)

2174148

Glass, Cover

2174250

Cover, Crisper

(Includes 2,

3, 4, 11, 12,

13, 14 & 19)

2179523

Glass, Cover

2174272

Gasket (Front)

2174274

Gasket (Rear)

2174478

Eyelet, Roller

2174388

Roller

489211

Screw

2179227

Crisper Pan

(Includes 13,

14, 18, 19 & 21)

2179231

Meat Pan

(Includes 13,

14, 19 & 22)

2174076

Window, Crisper

489261

Screw

2176095

Deflector

Cap, Crisper Pan

2174259

Right Side

2174258

Left Side

2174362

Window, Meat Pan

2164372

Egg Bin

2164373

Egg Carrier

2164374

Cover

2174387

Frame And Roller

Asm. (Cantilever)

2174021

Shelf & Roller

Assembly

489439

Screw

2168792

Carriage

2179486

Roller, Front (2)

2179487

Roller, Rear (2)

2168793

Round Pan

2174363

Divider (1/2)

2174364

Divider (1/4)

FREEZER LINER PARTS

For Models: KSRS25QDWH00, KSRS25QDAL00

(White) (Almond)

4379750 7

FREEZER LINER PARTS

For Models: KSRS25QDWH00, KSRS25QDAL00

(White) (Almond)

4379750

Illus. Part

No. No. DESCRIPTION

Liner (Not A

Seviceable Part)

2174493

Shelf, Top

Compartment

2179258

Door, Ice

Compartment

940014

Hole Plug

946356

Stud, R.S. Front

842534

Clip, Air Duct (2)

1115317

Support, Stud (4)

946355

Support, Stud (2)

2176134

Grommet (2)

Slide, Container

1119237

Left Side

1119293

Right Side

2174267

Shelf

489100

Screw (4)

2155572

Cover, Wiring

489176

Screw

Shelf Track

2171778

Right Side (3)

2171777

Left Side (3)

487042

Screw

1115373

Switch, Rocker Arm

489242

Screw

2171700

Basket, Middle

2171767

Front, Basket

2171702

Basket, Upper

2171766

Front, Basket

2171701

Basket, Lower

1115386

Stud, Shelf (4)

2171705

Light Lens

1106982

Stud, R.S. Rear

2162085

Socket, Light

527949

Bulb, Light

MOTOR AND ICE CONTAINER PARTS

For Models: KSRS25QDWH00, KSRS25QDAL00

(White) (Almond)

4379750 9

MOTOR AND ICE CONTAINER PARTS

For Models: KSRS25QDWH00, KSRS25QDAL00

(White) (Almond)

4379750

Illus. Part

No. No. DESCRIPTION

1118386

Bracket, Motor

2155263

Motor, Dispenser

2152713

Soleniod Assembly

2149100

Guide, Solenoid

1115374

Clip, Wiring

2169490

Wiring Assembly,

Ice Dispenser

489399

Screw

983663

Coupling, Motor

489242

Screw

2162085

Socket, Light

1115339

Cover, Motor

2152702

Ice Container

983668

Coupling, Conveyor

1118480

Stop, Cone

1119074

Feeder Cone

1119005

Spacer, Step (3)

1119007

Spacer, Flat (2)

1119006

Blade, Rotary

1119012

Blade, Rotary

1119013

Blade, Rotary

489235

Washer, Plain

1119009

Blade, Fixed (2)

2157405

Block, Blade

489229

Roll Pin

1119003

Conveyor

2171681

Drum

1118470

Drive Bar

2171682

Floating Baffle

1119018

Nut, Bearing

2155231

Control Arm

1119020

Spring, Return

1119021

Retainer Clip, Rod

488886

Screw

2157407

Housing, Crusher

1119017

Deflector, Ice

489234

Washer, Plain

489236

Retainer Ring

2152700

Housing, Filler

2152021

Sleeve−Auger

2171708

Front Cover,

Ice Container

527949

Light Bulb

2171706

Light Lens,

Dispenser
