Kodak P520 EASYSHARE Manuale utente
www.kodak.com/go/digitalframesupport 1
ENGLISH
See the extended user guide – for more information about using your frame, visit
www.kodak.com/go/digitalframesupport. See the frame package for package contents.
Front View
2
1
3
1 LCD screen
2 Quick Touch Border (right side, tap only)
3 Quick Touch Border (bottom, tap/slide)
To use the Quick Touch Borders,
see page 5.
Kodak EasyShare P520 digital frame
Kodak EasyShare P720/P725/P820 digital frames
2
1
3
2www.kodak.com/go/easysharecenter
Back/Side View
1 On/Off button 5 Reset button
2 Stand attachment slot 6 Wall mounting holes, 3 (see page 10)
3 Frame stand (see page 3) 7 USB connector (to camera/USB device)
4 Memory card slot - SD, MS, xD, MMC 8 Memory card slot - SD/SDHC
9 Power connector
45
7
8
3
1
2
P820 digital frame
6
45
7
8
3
1
2
6
P520/P720/P725 digital frames 9
9
www.kodak.com/go/digitalframesupport 3
1Getting started
Setting up your picture frame
Attaching the frame stand
■Make sure the tab on the stand is secure in the slot
on the back of the frame.
■Your frame displays pictures in landscape
orientation. To change to portrait , see page 9.
Attaching the power cable
CAUTION:
Do not use this power cable with other devices, including digital
cameras.
Tab
Slot
Your power cable may look different from
the one pictured. Use the plug that
accommodates your type of power outlet.
Getting started
4www.kodak.com/go/easysharecenter
Turning on your frame
Setting your language
The language screen appears the first time you turn on your frame.
■Slide, or tap below small arrows, to highlight your
language, then tap Save.
To change the language at a later time:
■Tap (Home) → (Settings), then highlight
Language.
The language screen appears.
Highlight your language, then tap Save.
To use the Quick Touch Borders, see page 5.
Power button
Save
Slide
Tap below small arrows
Getting started
www.kodak.com/go/digitalframesupport 5
Using your frame’s Quick Touch Borders
Tap next to or
below a button to
select it.
Tap a border to
display the icons.
Tap (Close) to
dismiss them.
Touch tips
Home
Play Slide show
Close
*Quick Touch
OK
Done
Tap and slide on the Quick
Touch Borders* only.
Tap below buttons
Slide on bottom
border only
Slide to highlight
menus, pictures,
videos, options.**
Tap OK to select
them.
Slide to scroll:
Scroll through images—Like turning the pages of a book, slide left ←to go forward, slide right →to go back. For
faster scrolling through larger numbers of pictures, touch and hold (3 seconds), then slide to the end of the border.
Scroll through menus—Slide right →to scroll down, slide left ←to scroll up.
Borders
** Tap below small arrows at the ends of the scroll bar to move the highlight one picture, menu, or item at a time.
Tap next to buttons
No slide here
Important:The screen is not touch-sensitive. Do not touch it.
Only use your finger to touch the borders. Sharp or metal objects may damage the border or screen
Don’t hover,
borders can be
sensitive.
Getting started
6www.kodak.com/go/easysharecenter
Enjoying your pictures immediately!
■To view your pictures or play a slide show,
insert a memory card, or connect a camera or other
USB device (see page 8).
If you are at the Home screen, see page 12 to start
your slide show.
To change the slide show order, see page 13.
Getting started
www.kodak.com/go/digitalframesupport 7
Inserting a memory card
■To insert a card, push the card firmly into the slot until it stops.
■To remove a card from:
– top card slot, push in the card to release it.
– side card slot, pull out the card.
IMPORTANT:
Do not insert a micro or mini memory card without an adapter.
MultiMedia Card
SD/SDHC
Memory Stick
xD
SD/SDHC
P520/P720/P725 digital frame P820 digital frame
Getting started
8www.kodak.com/go/easysharecenter
Connecting a digital camera or other USB device
P520/P720/P725 digital frame
P820 digital frame
USB cable
included with
your USB device
USB devices include a camera, flash drive, card reader, etc. (sold separately)
Getting started
www.kodak.com/go/digitalframesupport 9
Turning off your frame
■Standby mode—Press the power button .
■Power off—Unplug the power cable.
Changing your frame orientation
Your frame is set up to display pictures in landscape orientation. You can turn the
stand to change it to portrait but you must also change the setting.
Change the stand position: Remove the stand, turn
it 90 °, and replace as shown.
Change the setting:
1Tap (Home)
→ (Settings).
2Slide to highlight Set viewing options, then tap OK.
Slide to highlight Frame orientation, then tap OK.
Slide to highlight Portrait, then tap OK.
3Tap (Back) to exit.
Getting started
10 www.kodak.com/go/easysharecenter
Mounting your frame on the wall
Use wall-anchoring hardware (not included) to mount your frame securely to your wall.
To change to portrait orientation ,
turn your frame 90°and use the wall
mounting holes at the top.
Wall mounting holes
(on back of frame)
Secure power cable
with attached clip
