Kogan H2 Manuale utente

H2 TRUE WIRELESS

EARPHONES

KATWSH2WHTRA

• Use the product only within temperatures between 0°C - 45°C. Excessively high or low

temperatures may cause the product to malfunction.

• Always keep the product dry; avoid contact with water or humid environments.

• Avoid dropping or throwing the product to prevent damage.

• Ensure both earphones are powered off before cleaning.

• Always use the product at a safe and comfortable volume level. Usage for long periods

at high volume could lead to permanent hearing loss.

• The built-in battery is non-removable; do not attempt to replace this yourself. Please

contact help.Kogan.com for assistance if you experience battery issues.

• Only dispose of the product in an environmentally friendly manner at an e-waste

facility; this product cannot be disposed of in domestic garbage collection.

• Keep out of reach of children, as the small size of the product components present a

swallowing hazard.

Important Notice:

• Ensure the product is fully charged before initial use.

• Use a reputably branded adaptor complying to local safety requirements to charge this

product. This product is rated at 5V/250mA.

• If your device cannot find “Kogan H2 Earphones” during Bluetooth scanning, ensure

that your device is set to ‘Discoverable’ over Bluetooth. After initial pairing, the earbuds

will be automatically paired for repeated use. The earbuds may need to be re-paired

after a long period without use.

• If only one ear bud has sound output while in music mode, please restart the earbuds,

or re-pair them manually.

SAFETY & WARNINGS

Charging point

Function button

Microphone

Charging USB port

Status LED

OVERVIEW

Gently slide into your ears; the tails of the earbuds should be in line with your mouth for

optimal microphone placement.

Adjust the earbuds so that they are firmly in place, even when your head is moved.

BEFORE FIRST USE

Syncing

Open charging dock case, two earbuds will power on and sync with each other

automatically

Pairing with a smart device

Once successfully synced, the earphones are ready to pair with your Bluetooth enabled

device.

Turn on the Bluetooth function on your device (computer, smartphone, etc) and search for

the earphones in the Bluetooth menu. The earphones will appear as “Kogan H2 Earphones”

in Bluetooth menu. Once selected you will hear a voice notification when pairing is

successful.

Once the connection is successful, you can start using the wireless earphones.

To disconnect, simply put the earphones back in the charging case and the earphones will

automatically disconnect from any paired devices.

To reconnect the earphones with the same device, remove the earphones from the

charging case and the earphones will automatically connect to your device. Ensure that the

Bluetooth function on your device is turned on.

To prevent the earphones from automatically connecting to a device, remove the

earphones from the Bluetooth menu of that device.

To enjoy calls, music and audio output from your device to the earphones, ensure that the

media connection for both calls and media files is activated in the Bluetooth menu.

OPERATION

Open

Note:

Ensure both the charging case and the earphones are fully charged before first use.

Power off

The earbuds will power off automatically after being reinserted to the charging dock.

Charging

Without external power supply, the status LED will display solid red while charging the

earphones and will turn off after fully charged.

With external power supply, the status LED flash in blue while charging and will remain

solid blue after fully charged.

It takes about 1.5h to fully charge the earbuds and charging dock batteries.

Charging USB

Status

LED

More Functions

Incoming call

To answer call, tap function button once

To reject call, tap function button twice

Playing music

To pause music, tap function button once

To play the previous song, touch and hold the left earbud function

button for 2 seconds

To play the next song, touch and hold the right earbud function

button for 2 seconds

To increase volume, tap the function button of the left earbud twice

To decrease volume, tap the function button of the right earbud

twice

Voice assistant

To activate a compatible voice assistant (such as Siri), touch the

function button three times

Single earbud usage

The earbuds can be used individually (each earbud pairs to

separate cell phone)

Open charging dock cap, take out either earbud

and have to close the cap, wait for 10 seconds and

then turn on cell phone Bluetooth and set it as

open detection, when "Kogan H2 Earphones"

appears in available devices, press to connect. The

LED will be off.

It will automatically connect to the cell phone, if it connected previously.

Function button

Take out

(use the right

earbud as

example)

Manual earbud re-pairing

Ensure that the earbuds are not connected to any other Bluetooth devices.

Place both earbuds back into the charging case, close the lid, then reopen the case and

remove the earbuds.

Place both earbuds within 10cm of one another, syncing will automatically complete within 1

minute.

Close lid

Operation range

10 metres

Charging time

1 .5 hours

Call time

3 hours

Music time

4 hours

Charging input

5V-250mA

Battery type

Polymer Li-Ion Battery

Earbud weight

3.5g + 3.5g

SPECIFICATIONS
