Kogan KAMN32FCSA Manuale utente

32” FULL HD CURVED

FREESYNC GAMING MONITOR

1920 X 1080, 75HZ

KAMN32FCSA

• Read all instructions before using this monitor and retain this user guide for future

reference.

• This monitor is designed with ventilation holes on the back of the casing. Do not cover

or block them.

• Do not insert any object or spray any liquid into the vents.

• Avoid placing the monitor near heaters, stoves, fireplaces or other sources of heat, as

well as in rooms lacking adequate ventilation.

• Do not position the monitor in unsafe locations. If the monitor falls, it may be damaged

and may injure nearby people.

• Unplug the monitor if it is not going to be used for an extended period.

• Do not place heavy objects on the monitor, its power cord or any connected cable.

• Do not open the back panel of the monitor as it contains a high-voltage current even

when not plugged in.

• There is a polariser layer (not a protective film) on the surface of the screen. Do not peel

it off or the monitor may be damaged.

The terms HDMI and HDMI High-Definition Multimedia

Interface and the HDMI logo are trademarks or registered

trademarks of HDMI Licensing Administrator, Inc. in the

United States and other countries.

SAFETY & WARNINGS

Monitor

Stand arm

Stand base

M4x10mm Screw (x2)

VESA screws (x4)

HDMI cable

Power cable

User guide

COMPONENTS

Monitor Controls

1. Power button

• Press and hold the power button for 6 seconds to turn your monitor on/off.

• If the monitor has gone to sleep, press the power button to wake up the display.

• In addition to its power function, the power button also serves as a directional button.

When navigating the on-screen menu, you can use the power button to move up,

down, left, and right, just like a joystick. This makes it easy to navigate through the

monitor's settings and options.

OVERVIEW

Monitor Ports

HDMI port

VGA port

Audio in (3.5mm)

Power input port

1. Carefully remove the monitor, stand

arm and stand base from the box.

2. Attach the stand base to the stand

arm using the M4 screws provided.

3. Insert the connection block into the

rear of the monitor and push down

until firmly connected.

4. Lift the monitor up and remove the

bottom foam. Stand the monitor up

on the installed base.

STAND ASSEMBLY

WARNING: The panel of the monitor is fragile. Keep the foam

underneath the monitor screen while assembling the stand.

VESA mounting pattern 75 x 75mm, screw size M4.

Note: VESA mount and mounting accessories are not included.

1. Open the box, take out the monitor with protective foam attached and gently place

it on a desktop or table. Remove all components and the protective foam from the

back of the monitor.

If the monitor is already attached to the stand, press the quick release button to

remove the stand plate and detach the stand.

2. Assemble the mount as per the instructions provided with the mount.

VESA MOUNT

Stand base

Monitor

Stand arm

Stand

plate

Mount (not

included)

Power Cable

Connect the included power cable to the monitor power port, then connect the other end to

a power outlet.

Earphones (Audio Out)

Earphones, headphones or other audio devices can be connected to the 3.5mm audio port

(Audio Out) on the monitor. The monitor may need to be set as the PC’s default sound

output device.

CONNECTIVITY

Power cable

Earphones

(not included)

HDMI

In order for the monitor to receive HDMI signals from the computer, use the HDMI cable to

connect the monitor to the computer.

VGA

Connect a computer, DVD/Blu-ray player or console to the monitor using a VGA cable.

HDMI cable

(included)

VGA cable

(not included)
