Contours™Options™Tandem Stroller Instruction Sheet

Hoja de instrucciones de la carriola Contours™Options™Tandem

Feuille d'instructions pour Poussette Tandem Contours™Options™

Avoid serious injury from falling or sliding out. Always use Restraint

System. Your child's safety depends on you. Proper stroller use cannot be

assured unless you follow these instructions. DO NOT USE STROLLER

UNTIL YOU READ AND UNDERSTAND THESE INSTRUCTIONS.

IMPORTANT SAFETY INFORMATION:

How to Keep Your Child Safe While Using this Stroller

•Adult Assembly Required.

•NEVER LEAVE YOUR CHILD UNATTENDED WHILE IN STROLLER.

Accidents can happen quickly while your back is turned. You must

always keep your child in view while your child is in the stroller,

even when sleeping. Do not use this product as a bed. Your child

may become tangled in straps or pads and suffocate.

•Always use restraint systemto keep child fromstanding up or

falling out of the stroller. Do not use product without full 5 point

Harness Restraint. Removing the shoulder straps will not

adequately restrain child.

•Always place the child in the front seat before placing another in

the back seat.When removing children, always remove the child

in the back seat first before removing the child in the front. Failure

to do so may cause the stroller to become unstable and tip.

•Always lock the stroller open before allowing your child in or near

the stroller.This prevents injuries caused by stroller collapsing.

•

Onlyuse this stroller with children who weigh less than 40 lbs. (18.14

kg)or are less than 40” (1 meter)tall,per seat.

This stroller can hold a

maximum of 80 lbs (36.28 kg.) dual occupancy, and use by larger

children may cause it to tip.

•Use this stroller in the reclined position until child can sit up

unassisted.

•Always set the wheel brakes when stroller is not moving,especially

on an incline.This prevents the stroller from rolling away.

•Always fasten the canopyonto the seat back when using the

stroller in the reclined position.

What to Avoid While Using this Stroller

•Always balance the weight of the stroller evenly. To prevent the

stroller from becoming unstable or tipping:

• Do not place parcels or accessory items on the stroller canopy,

seat, or over the handle.

• Do not put more than 10 lbs. (4.54 kg) in the basket.

WARNING

Continued on next page

• Do not allow children to play with or hang onto the stroller.

• When using this product with only1child,onlyuse the seat or

car seat adapter in the front position.

•Never use this stroller on stairways or escalators.

•DO NOT lift by Front Bars.

•Make sure children are clear of any moving parts if you adjust the

stroller, otherwise they may be injured.

•THIS IS NOT AN EXERCISE STROLLER! Do not use this product

while running, jogging, in-line skating or participating in other

athletic activities.

•DO NOT put child in basket.

•Take care when folding and unfolding to prevent finger pinching.

• Product may become unstable if a parcel bag, other than the one

recommended by the manufacturer is used.

•DO NOT allow children to climb into stroller unassisted. Stroller

may tip over and injure child.

• Only use replacement parts supplied by the manufacturer.

How to Use this Stroller with Your Infant Car Seat

•AVOID SERIOUS INJURY FROM FALLS:

• DO NOT place carseat in stroller seat. Carseat will not be secure.

• DO NOT use seat and infant car seat adapter in same seating

location at the same time.

• This product is only to be used with certain Infant Car Seats. See

below for list of compatible Infant Car Seats.

• When using this product with your Infant Car Seat, infant must

always be secured in the car seat with the car seats harness.

• To ensure your Infant Car Seat is properly installed on the stroller,

make sure it is:

• Facing the person pushing the stroller.

• Tightly secured to the stroller with the red restraint straps.

• If at any time your Infant Car Seat does not secure properly to the

stroller, or if you have questions about assembly or use of the

stroller, Do Not use this product. Call Kolcraft at 1-800-453-7673.

•Make sure the stroller is fullyunfolded and the car seat adapter is

securelylatched before attaching your Infant Car Seat. This

prevents finger pinching and injuries caused by stroller collapsing.

•Onlytransport infants that are within the size and weight

limitations of your Infant Car Seat,as described in the instruction

manual provided by the Infant Car Seat manufacturer.

3Continued on next page

•WHEN USING ONLY ONE INFANT CAR SEAT ADAPTER THE

FOLLOWING INFANT CAR SEATS CAN BE USED:

•

WHEN USING TWO INFANT CAR SEAT ADAPTERS FOR TWINS

THE FOLLOWING INFANT CAR SEATS CAN BE USED TOGETHER:

•If your Infant Car Seat is not one of the models listed above,DO

NOT use your infant car seat with this stroller.Other Infant Car

Seat models will not fit properlyand may result in serious injuryto

your child.

•

DO NOT USE THE FOLLOWING CAR SEATS WITH THIS STROLLER!

This list is not inclusive.

Baby Trend®, Britax®, Century®, Chicco®, Combi®, Cosco®, EvenFlo®,

Gerry®, Graco®, Peg Perego®and Safety 1st®are trademarks of their

respective owners. They are not associated with Kolcraft Enterprises,

Inc. and no approval by them is to be implied.

•Britax®Baby Safe™

•Century®535/580/590 Series

•Century®Assura®Series

•Century®Avanta™Series

•

Century

Smart Fit

Series

•

Century

Vanté

™

•

Century

Smart Fit

Series

•

Century

Take 2

•

Combi

Tyro™

•

Cosco

TLC

•

Cosco

Dream Ride

•

Cosco

®Eddie Bauer®Caress

•

Evenflo

On-My-Way

™

•All Gerry®Infant Car Seats

•

Fisher Price

Stay in View

™

•Kolcraft®Secura

•Kolcraft®Infant Rider®

•Baby Trend®Flex-Loc

•Baby Trend®Latch-Loc

•Britax®Handle with Care®

•Britax®The Companion

•

Chicco

Key Fit

•Combi®Connection™

•

Cosco

Arriva

Series

•

Cosco

Designer

•

Cosco

First Ride DX

•

Cosco

Eddie Bauer

Opus

•

Cosco

Turn-A-Bout

•

Evenflo

Cozy Carry

™

•

Evenflo

Discovery

™

•Evenflo®Embrace™

•

Evenflo

Portabout

™

•

Graco

Safe Seat

™

•

Graco

Snug Ride

™

Series

•

PegPerego

Primo Viaggio

•

PegPerego

SIP

•

Safety 1st

Designer

•

Safety 1st

Starter

™

•Baby Trend®Flex-Loc

•Baby Trend®Latch-Loc

•Britax®The Companion

•Combi®Connection™

•

Cosco

Arriva

Series

•

Cosco

First Ride DX

•

Cosco

Turn-A-Bout

•

Evenflo

Cozy Carry™

•

Evenflo

Discovery™

•Evenflo®Embrace

™

•

Evenflo®Portabout™

•

Graco

Safe Seat™

•

Graco

Snug Ride™Series

•

PegPerego

Primo Viaggio

•

Safety 1st®Designer®22

•

Safety 1st®Starter™

To Open Stroller

Remove any cardboard inserts or plastic

ties used to protect the product during

shipment.

Release the locking latch on the

Stroller

Frame

Unfold to full open position.

Remove the sticker from the Front Wheel

Assembly. Remove and discard both

screws from the Front Wheel Assembly.

Rotate Front Wheel Assembly upward,

until you hear a click.

Secure the Front Wheel Assembly into

the stroller frame with 2 notched

Pins

Parts List

How to Assemble Your Stroller

Stroller Frame

with Basket

Front

Wheels (2)

Rear Wheels (2)

Washers (2) Cotter Pins (2) Hub Caps

(2)

Basket Tube Stroller Handle

Reversible

Seats (2)

Front Bars (2) Infant Car Seat Adapter

(2) (Select Models) Screws (6)

Pins (2)

Brake Assembly with Rear Axle

Infant Neck

Rolls (2)

(Select Models)

iPod®Mini

Adapter

(select models)

Thick iPod®

Protection Pad

(select models)

Thin iPod®

Protection Pad

(select models)

iPod®Dok

(select models)

Parent Tray

To Attach Basket

Align the

Basket Tube

with the Basket

Frame in the rear of the stroller as

shown.

Press in spring loaded buttons on

Basket

Tube

and slide into the Basket Frame

until both buttons click into place.

Unroll the basket over center bar of

stroller frame as shown.

In the middle & front of the stroller,

secure 4 sets of snaps on the basket

around the stroller frame.

Secure 6 sets of snaps at the back end of

the basket around the

Basket Tube

shown.

To Attach Stroller Handle

1Slide the

Stroller Handle

down onto the

stroller frame, until the holes on each

side of the

Stroller Handle

can be seen

in the frame.

Secure the

Stroller Handle

with a screw

on each side of the frame.

To Attach Parent Tray

Place the

Parent Tray

onto the bar

underneath the

Stroller Handle

and align

the

Parent Tray

into the 4 holes. The

Parent Tray

should be positioned so the

lid opening is towards the handle.

Secure the

Parent Tray

to the bar with 4

screws as shown.

To remove

Parent Tray

, unscrew from

frame. For cleaning,

Parent Tray

is top

rack dishwasher safe.

WARNING

Do not place more than 3 lbs. (1.36

kg) in this tray to avoid tipping!

Do not place hot liquids in this tray.

Hot liquids can burn your child.

Screws (4)

Button

To Attach Front Wheels

Align

Front Wheel

as shown.

Push

Front Wheel

up into the Front

Wheel Assembly until a “Click” is heard.

Repeat for other wheel. Tug firmly on

each wheel assembly to be sure wheels

are securely in place.

NOTE: To remove

Front Wheels

, twist

top of Front Wheel Assembly as shown,

and pull wheel off.

To Assemble Rear Wheels

Turn stroller over as shown. Remove

protective sleeve from ends of brake

assembly with rear axle.

Position

Brake Assembly

as shown, with

brake levers pointing towards stroller

handle.

Push both brake assemblies onto rear

leg tubes at the same time until spring

loaded buttons click into place.

NOTE: If brake assemblies do not click

and hold in place, the spring button is

stuck and not protruding through the

hole in the tube. Use a screwdriver or

pliers to move the button so that it

protrudes out of the hole in the tube.

Continued on next page

Brake Levers

1 & 2

Slide

Rear Wheel

onto axle.

Slide

Washer

onto axle.

Fit straight part of

Cotter Pin

through

hole on axle as shown.

Line up tabs in the

Hub Cap

with slots in

the wheel, snap hub cap into place.

Repeat for second side.

4 - 7

To Attach Infant Car Seat Adapter (select models)

1Align

Infant Car Seat Adapter

catches

over frame hubs as shown and push

Infant Car Seat Adapter down onto the

frame hubs until a “Click” is heard. Make

sure the “Front / Frente” sticker on the

adapter is facing the front of the stroller.

The button on the frame hubs should be

seen through both

Infant Car Seat

Adapter

catches. Pull up on the Infant

Car Seat Adapter to make sure it is

securely attached.

NOTE: To remove

Infant Car Seat

Adapter

, push both buttons on the frame

hub in, then lift the Infant Car Seat

Adapter up.

Attaching a Second Infant Car Seat

Adapter (sold separately - through Consumer

Service see page 59)

Follow Steps 1 and 2, by installing the

Infant Car Seat Adapter to the frame

hubs towards the front of the stroller.

Frame Hub & Button

Infant Car Seat Adapter Catches

Front Sticker

To Attach Front Bars

Seat Catch Hole

Front Bar Pin

Front Bar Release Button

Align

Front Bar

pins over the holes on

the Seat Catch and push in, until a

“Click” is heard on both sides. Repeat

this Step for other

Front Bar

To let a child in/out of a

Reversible Seat

push on one side, of the

Front Bar

release button and pull the Front Bar

out. The Front bar will now swivel

outward. Repeat Step 1 to reinsert

Front Bar

To remove

Front Bar

, push both

Front

Bar

realease buttons and pull out.

Repeat Step 1 to reinsert.

CAUTION

To prevent injury to your child, take

care when inserting bar into frame.

Altri manuali per Contours Options

Indice

Lingue:

Altri manuali Kolcraft Passeggino

Kolcraft

Kolcraft Contours Options Optima S82-R3 Manuale utente

Kolcraft

Kolcraft S69-R1 Manuale utente

Kolcraft

Kolcraft Jeep Cherokee Sport Series Manuale utente

Kolcraft

Kolcraft Umbrella Stroller Manuale utente

Kolcraft

Kolcraft J is for Jeep Wrangler Sport Manuale utente

Kolcraft

Kolcraft Tour Sport Universal Umbrella Manuale utente

Kolcraft

Kolcraft Contours Options Manuale utente

Kolcraft

Kolcraft Tender Vibes B27-R4 Manuale utente

Kolcraft

Kolcraft S53-R1 Manuale utente

Kolcraft

Kolcraft Universal Express Rider Manuale utente

Kolcraft

Kolcraft Jeep S47J-R7 Manuale utente

Kolcraft

Kolcraft Jeep Overland Limited Manuale utente

Kolcraft

Kolcraft cloud PLUS Manuale utente

Kolcraft

Kolcraft Jeep Liberty S45J-R7 Manuale utente

Kolcraft

Kolcraft Jeep Wrangler All-Weather UmbrellaStroller Manuale utente

Kolcraft

Kolcraft Jeep Wrangler Manuale utente

Kolcraft

Kolcraft Jeep S45J-A-R3 Manuale utente

Kolcraft

Kolcraft Jeep Wrangler All-Weather Umbrella Stroller Manuale utente

Kolcraft

Kolcraft Jeep Overland Limited Manuale utente

Kolcraft

Kolcraft SPRINT X Manuale utente

Kolcraft

Kolcraft Jeep Wrangler Sport S088-R3 Manuale utente

Kolcraft

Kolcraft Contours Options LT Manuale utente

Kolcraft

Kolcraft Jeep Manuale utente

Kolcraft

Kolcraft Contours Options 3 Manuale utente

Manuali Passeggino popolari di altre marche

Hauck

Hauck Priya Trioset Manuale utente

CHILDHOME

CHILDHOME CWQDN Manuale utente

Dreamer Design

Dreamer Design Rebound GST Manuale utente

Britax

Britax STEELCRAFT AGILE Manuale utente

Graco

Graco 7427 Manuale utente

Comfort

Comfort COMPASS Manuale utente

OBaby

OBaby Aura Manuale utente

Tutek

Tutek Tirso Manuale utente

Babify

Babify Dual Plus Manuale utente

Graco

Graco Stroller Manuale utente

Special Tomato

Special Tomato Jogger Manuale utente

Chicco

Chicco CORTINA TOGETHER TWO-PASSENGER STROLLER Manuale utente

Otto Bock

Otto Bock Kimba neo Manuale utente

Milly Mally

Milly Mally ROYAL Guida rapida

Hauck

Hauck DUETT 3 PRAM Manuale utente

BOB

BOB DUALLIE Manuale utente

Nuna

Nuna Pepp Manuale utente

Britax

Britax B2 Manuale utente
