Korenix JetNet 5010G Series Manuale utente
JetNet 5010G/4510(f)/4010/3010G Series
Industrial Switch
Quick Installation Guide
www.korenix.com
V1.1
Introduction
JetNet 5010G: The JetNet 5010G is a 10-port Managed Gigabit Industrial Ethernet switch
equipped with 7-port 10/100TX and 3 combo ports for Gigabit copper and SFP for gigabit
uplink.
JetNet 4510: The JetNet 4510 is a Managed industrial Fast Ethernet Switch, equipped with
7 ports 10/100TX and 3 Fast Ethernet Copper / 100-FX combo ports.
JetNet 4510f: The JetNet 4510f is a Managed industrial Fast Ethernet Switch, equipped with
7 ports 10/100TX ,1 port 10/100TX/100-FX combo port and 2 100FX ports.
JetNet 4010: The JetNet 4010 is a Web Managed industrial Fast Ethernet Switch, equipped
with 7 ports 10/100TX and 3 Fast Ethernet Copper / 100-FX combo ports.
JetNet 3010G: The JetNet 3010G is a 10-port Gigabit Industrial Ethernet switch equipped
with 7-port 10/100TX and 3 Copper/ SFP combo ports for gigabit uplink.
For Managed switch, the software supports full L2 management features, ring redundancy,
network control, security and alert features. It also supports RS-232 console for out of band
management. For Web Managed Switch, the SNMP is not included in Feature list.
Hardware Installation
4JetNet series Industrial Switch.
4Quick Installation Guide
4CD User Manual
4Wall Mount plate and Mounting kit
4RS-232 DB9 to RJ-45 console cable
(Only for Managed Switch JetNet 5010G/4510/4510f/4010)
Mounting the unit
You can mount the din-rail clip on the rear of JetNet
series on the DIN rail.
3.1 Connect the PWR1 / PWR2, and the unit will be powered on. PWR1 / PWR2 LED will
turn Blinking to show unit booting up. When the unit is ready, the PWR1 / PWR2 LED turn
Green to show current input.
3.2 Connect the 10/100M Ethernet Port: Connect the network nodes to the JetNet series with
4-pair CAT5 UTP cable. The 10/100M interfaces support auto MDI/MDIX.
3.3 Connect the 100Mbps(JetNet 4510(f)/4010) /Gigabit (JetNet 5010G/3010G) TX of combo
ports: Connect the network node to the JetNet series with 4-pair CAT5 UTP cable. The
100Mbps / Gigabit TX interfaces support auto MDI/MDIX as well.
3.4 Connect the SFP transceiver: Plug in SFP ber transceiver. We recommend using
Korenix certicated SFP mini GBIC transceiver. Cross-connect the transmit channel at each
end to the receive channel at the opposite end as illustrated in the gure below.
V+ V- V+ V-
Power1 Power2 Accept 12~24AWG wire. The switch
provides auto polarity reverse
Power the unit and connect to network
Grounding JetNet
There is one grounding screw on the bottom side of JetNet Switch. Connect the frame
grounding of JetNet Switch to the grounding surface to ensure safety and prevent noise.
！
This is a Class 1 Laser/LED product.
Don’t stare at the Laser/LED Beam.
TX
RX
A B
TX
RX
ATTENTION
Device Management
(for Managed Switch JetNet 5010G/4510/4510f/4010)
JetNet series Industrial Managed Switch provides both in-band and out-band conguration
methods. You can congure the switch via the RS232 console with the attached console
cable. Or you can remotely manage the switch via network. You can choose Telnet/SSH,
Web/HTTPS management.
1.1 Go to Start -> Program -> Accessories -> Communication -> Hyper Terminal
1.2 Give a name to the new console connection.
1.3 Choose the COM name, and select the correct serial settings. The serial settings of
JetNet Switch are as below:
Baud Rate: 9600 / Parity: None / Data Bit: 8 / Stop Bit: 1
1.4 After connected, you can see Switch login request. Type the username and password
then you can login. The default username is “admin”, password is “admin”.
1.5 Follow the manual to congure the software features.
1. Preparation for console management: Attach the RS-232 DB9 connector to your PC’s
COM port. Connect the RJ-45 connector to the console port of the JetNet Switch.
2. Preparation for Web management: Before you attempt to use the embedded web interface
to manage switch operation, verify that your JetNet Switch is properly installed on your
network and that every PC on this network can access the switch via the web browser.
3.5 Connect the SC/ST type transceiver (JetNet 4510f): Cross-connect the ber cable at
each end to the receive channel at the opposite end as illustrated in the gure below.
3.6 Should you need to connect the Digital Input or Relay Output, please refer to the wiring
method introduced in JetNet series Manual.
(for Managed Switch JetNet 5010G/4510/4510f/4010)
TX TX
RX RX
Note: Ensure the Fiber cable matching
the type of ber Transceiver
3. Should you need to manage the switch by Telnet/SSH, please refer to the chapter 3 of
JetNet series Manual.
Korenix Customer Service
KoreCARE is Korenix Technology’s global service center, where our professional staffs are
ready to answer your questions at any time.
2.1 Launch the web browser (Internet Explorer or
Mozila Firefox) on the PC.
2.2 Type http://IP_Address (The default IP
address is 192.168.10.1.) then press Enter.
Ex. http://192.168.10.1
2.3 The login screen will appear next. Key in the user
name and the password. The default user name and
password is admin/admin.
2.4 Click OK, and then the welcome page of the
web-based management interface will appear.
2.5 At the left column of the web management
interface are the software feature, right column will
list the available settings.
概述
JetNet 5010G: JetNet 5010G 是一款工业千兆管理型以太网交换机，配备7个10/100TX口和3
个千兆电口/Gigabit SX/LX SFP combo可选千兆口模块。
JetNet 4510: JetNet 4510是一款工业百兆管理型交换机，配备7个10/100TX电口和3个百兆光
(SFP)/电(RJ45)可选埠。
JetNet 4510f: JetNet 4510f是一款工业百兆管理型交换机，配备7个10/100TX电口, 1个百兆
光(SFP)/电(RJ45)可选埠和2个百兆光口。
JetNet 4010: JetNet 4010是一款工业百兆网管型交换机，配备7个10/100TX电口和3个百兆光
(SFP)/电(RJ45)可选埠。
JetNet 3010G: JetNet 3010G 是一款10口千兆工业以太网交换机，配备7个10/100TX口和3个
千兆电口/Gigabit SX/LX SFP combo可选千兆口模块。
针对管理型交换器, 内部软件支持全部2层交换机网管功能, 环网冗余, 网络控制,安全管理及
报警功能, 在外部还提供一个RS-232的控制管理埠。针对网管型交换器, 不包含SNMP網管功
能。
硬件安装
4JetNet 以太网交换机
4快速安装向导
4CD用户手册
4壁挂安装配件
4RS-232 DB9转RJ-45控制线
(针对管理型交换器 JetNet 5010G/4510/4510f/4010)
设备安装
将JetNet 系列机身后面的导轨夹卡在导轨上。
CH
3.1 将电源连接到PWR1 / PWR2, 电源灯会亮。并且其PWR1 / PWR2 指示灯变成闪烁表示设
备正在启动，当指示灯变成绿色，表示设备已经准备就绪。
V+ V- V+ V-
Power1 Power2 使用12~24AWG wire. 交换器支持
正负极反接自动调整
电源及网络连接
JetNet交换器接地
JetNet 交换器的机身底部有一个接地线的螺母，将JetNet 交换器的地线接脚接地，以策安全
防止干扰。
3.2 连接10/100M以太网口：使用4-pair CAT5 UTP双绞线将网络各节点连接到JetNet 系列。
10/100M以太口自适应MDI/MDIX。
3.3 连接百兆(JetNet4510/4010)/千兆(JetNet5010G/3010G)TX口：使用4-pair CAT5 UTP双绞
线将网络各节点连接到JetNet 系列。百兆/千兆TX口支持自适应MDI/MDIX。注意: 相同端口
号码的光(SFP)/电(RJ45)可选埠只能择一使用。
3.4连接SFP光纤收发器：插入SFP光纤收发器模块。我们建议使用惠通科技认证的SFP mini
GBIC收发器。注意， TX和RX光口要求交叉相连，下图是光口连接示意图。
！
This is a Class 1 Laser/LED product.
Don’t stare at the Laser/LED Beam.
TX
RX
A B
TX
RX
ATTENTION
3.5 连接 SC/ST 类型光纤收发器(JetNet 4510f)：SC/ST 类型光纤收发器TX和RX光口要求交
叉相连，下图是光口连接示意图
设备管理
(针对管理型交换器 JetNet 5010G/4510/4510f/4010)
JetNet 系列工业千兆管理型交换机支持带内带外两种设置模式。你可以通过RS232 Console
埠对交换机进行设置。或通过网络远程管理交换机。你可以选择Telnet/SSH或Web/HTTPS方
式进行管理。
1.1 开始 - 程序 - 附件 - 通讯 - 超级终端。
1.2 为新连接命名。
1.3 选择COM口，及正确的串口设定。JetNet 交换器 的串口参数如下：
波特率: 9600 / 奇偶校验: None / 数据位: 8 / 停止位: 1。
1.4 连接以后，你会看到交换机的请求登录命令。键入用户名及密码即可登录。
默认的用户名是“admin”, 密码是“admin”。
1.5 参考操作指南完成功能设定。
1. 用控制台方式进行管理的准备工作：将RS-232 DB9接头连接到PC的COM口，将RJ-45接头
连接到JetNet 以太网交换器的Console口。
2. 用Web方式进行管理的准备工作：在你准备通过内置的Web接口对交换机进行管理之前，
先检查JetNet 交换器是否正确接入网络，且各台PC可以通过Web浏览器访问交换机。
3.6 如果您需要连接DI或继电器报警输出，请参考JetNet 系列用户手册进行接线。
(针对管理型交换器 JetNet 5010G/4510/4510f/4010)
TX TX
RX RX
注意: 光纤缆线对应的光纤收发器
类型须相同
2.1 启动Web浏览器(Internet Explorer 或Mozila
Firefox) 。
2.2 在地址栏键入IP地址如：“http://IP_Address”
(默认IP地址为192.168.10.1.) ，回车。
Ex. http://192.168.10.1
2.3 则出现登录框。键入用户名及密码。默认用户名
和密码是admin/admin。
2.4 单击OK, 就会出现WEB管理的欢迎接口。
2.5 Web管理接口的左侧是功能菜单，显示了所有
可用功能设置选项。
3. 如果你需要通过Telnet/SSH对交换机进行管理，
请参考JetNet 系列操作指南第3章内容。
科洛理思售后服务
KoreCARE 是科洛理思科技全球服务中心，我们专业的技术人员随时准备解答您的疑问。
科洛理思全球服务中心E-mail：[email protected]
Einleitung
JetNet 5010G: Der JetNet 5010G ist ein industrieller administrierbarer Gigabit Ethernet
Switch , mit 7 x 10/100TX Ports und 3 x /Gigabit Kombi-Ports für SFP-Module.
JetNet 4510: Der JetNet 4510 ist ein industrieller Web administrierbarer 100Mbps Ethernet
Switch, mit 7 x 10/100TX Ports und 3 x 10/100-TX Ports bzw.
JetNet 4510f: Der JetNet 4510f ist ein industrieller Web administrierbarer 100Mbps Ethernet
Switch, mit 7 x 10/100TX Ports, 1 port 10/100TX/100-FX Kombi-Port und 2 x 100FX Ports.
JetNet 4010: Der JetNet 4010 ist ein industrieller Web administrierbarer 100Mbps Ethernet
Switch, mit 7 x 10/100TX Ports und 3 x 10/100-TX Ports bzw.
JetNet 3010G: Der JetNet 3010G ist ein industrieller 10-port Gigabit Switch, mit 7 x
10/100TX Ports und 3 x /Gigabit Kombi-Ports für SFP-Module.
Für administrierbarer Switch, Die Software unterstützt volles L2 Netzwerk Management, den
Korenix Super Ring bzw, umfassende Einstellmöglichkeiten bzgl, Sicherheit und Alarmierung.
Es hat außerdem eine RS-232 Schnittstelle für einen schnellen Vorort-Zugriff auf den Switch.
Für Web administrierbarer Switch, SNMP ist nicht im Feature-Liste aufgenommen.
Inbetriebnahme
4JetNet Switch.
4Kurzanleitung für die Inbetriebnahme
4CD Handbuch
4Platte für die Wandmontage incl. Befestigungsmaterial
4RS-232 DB9 auf RJ-45 Adapterkabel
(Administrierbarer Switch
JetNet 5010G/4510/4510f/4010 nur)
Montage des Geräte
Sie können den JetNet Switch auf eine DIN-Schiene
montieren.
DE
