KREAFUNK aGlow Manuale utente
aGLOW
Operation manual
Bedienungshandbuch
Manual de instrucciones
Manuel d’utilisation
Brugermanual
Portable Bluetooth Speaker Box
2
3
English 4
Deutsch 16
Español 16
Français 22
Dansk 28
This product is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU. The declaration of conformity may be consulted at:
www.kreafunk.com/declaration-of-conformity/
FCC-ID: 2ACVCKREAFUNK1
4English
English
Operation manual
5
English
TABLE OF CONTENTS
1. Main features and Technical Parameters
2. Product illustration
3. Key functions
4. BT playback
5. Audio input mode
6. Power supply and Emergency Power Bank
7. Night Light function
8. Troubleshooting
9. Packing Accessories
Read the instruction manual before use.
6English
1. Main features and
Technical Parameters
1. BT audio player
2. Hands free function
3. Power Bank function
4. Ø3.5mm audio input interface
5. Audio Max power: 5W*1
6. Frequency response: 20Hz-
20kHz
7. Max. power consumption: 1W
8. Built-in high capacity
rechargeable Lithium ion-
Battery.
9. Input: 5V/1A
10. Output:5V/1A
11. Charging time: around 7 hours
12. Continue playing music about
18 hours when the built-in
lithium battery is fully charged.
13. Nightlight about 15 hours when
built-in lithium battery is fully
charged.
14. Water resistance level: IPX4
2. Product Illustration
1. Chargin Indicator
2. State Indicator
3. Micro USB
4. USB 5V Output
5. AUX Line-in
6. Light ON/OFF
7. Volume Up / Next
8. Volume Down / Previous
9. Multifunction
1
2
3
4
5
6
7
8
9
7
English
3. Key functions
No Current
mode
Function
operating
Button Operation Indicator
1Power o Power on Long press
for 2
seconds
Status indica-
tor is ON
2 Power on Power o Long press
for 5
seconds
Status indica-
tor is OFF
3 Power on BT pairing Manually
paired
Blue status
indicator
is ashing
rapidly
4 Power on BT pair
success-
fully
Automatically
paired
Blue status
indicator
is ashing
slowly
5 Power on Call back Double click
6 Call mode Answer
call
Short press
once
7 Call mode Reject call Long press
8English
8 Talk mode End call Short press
once
9 BT mode Volume Up Long Press
10 BT mode Volume
Down
Long Press
11 BT mode Previous
song
Short Press
once
12 BT mode Next song Short Press
once
13 BT mode Pause/
Play/Mute
Short press
circcle
14 Any mode Charging Red charging
indicator is
as
15 Any mode Battery is
full
Red charging
indicator
become
always on
16 Any mode Power
Bank
function
Green
chargin indi-
cator On
9
English
17 BT mode Audio input Audio cable
is pluged into
the audio
input
Green status
indicator
is ON
18 Audio
mode
BT mode Unplug The
audio cable
Blue status
indicator
is ON
19 Any mode Night light
ON/OFF
Short press
circle
20 On Mode Dimmer Long press The bright-
ness is
ascending og
descenting
regulation
4. BT playback
1. Press and hold the button for 2 seconds to turn on the aGLOW. A blue
LED status indicator will ash to indicate that the product is activated.
2. Turn on the BT function on your mobile phone or BT device and search
for devices in the BT menu.
3. When “aGLOW” appears on the BT device list, select “aGLOW” to
establish pairing and connect. (If a passkey is required, enter 0000).
When the pairing and connection is successful, you will hear a “BIP”
10 English
and the LED indicator is
now slowly ashing blue. The
aGLOW is now ready to play
your favorite tunes. Short press
to play music.
4. When the connection between
your device and the aGLOW is
successful, and the speaker
is playing, the music will be
stopped when you receive an
incoming call. One shortpress
at the will answer the call
and use the aGLOW as a hands
free device. One long press at
/ will adjust the volume.
Please keep within 1-meter
distance during the phone
call. Short-press to hang
up the phone. The aGLOW will
automatically return to playing
music. To reject the incoming
call, press and hold for 2
seconds. To redial the previous
call number, short-press
twice.
5. If the pairing is unsuccessful
or if there is no ash indicator
showing, please repeat step 1
to 3 for re-connection.
5. Audio input mode
MP3, iPOD, mobile phone or other
audio products, which features mini
Jack cable, can be used. The green
indicator should now be on.
1. Insert 3.5mm /mini jack audio
cable into the audio input port.
2. Press and hold / to
adjust thevolume.
3. In ‘audio line-in’ mode, short-
press to play/pause. The
skip / next-function is not
available in this mode. Please
control music through your
music device.
4. Pull out the audio cable to
disconnect the aGLOW. The
