KTI Networks KGS-500 Ver.D Manuale utente

5-Port 10/100/1000Base-T

Gigabit Ethernet Switch

KGS-500 Ver.D

Specifications:

FCC Part 15'Class B

CISPR 22 Class B

Katron Technologies Inc.

15F-7, No. 79, Sec. 1, Hsin Tai Wu Rd.,

Hsi-chih, Taipei Hsien, Taiwan.

Te l :886-2-2698-3878

Fax:886-2-2698-3873

E-mail:[email protected]

URL:http://www.ktinet.com.tw

KTI Networks Inc.

7400 Harwin Dr., Suite 120 Houston,

Texas 77036 U.S.A.

Te l :713-266-3891

Fax:713-914-0555

E-mail:[email protected]

URL:http://www.ktinet.com

Trademarks: All brand names are trademarks or registered

trademarks of their respective holders.

This information is subject to change without prior notice.

080110

Key Features :

 Provides 5 10/100/1000Mbps Gigabit Ethernet ports

 All ports support auto-negotiation and auto-MDI/MDI-X detection

 Supports full/half-duplex transfer mode for 10/100Mbps

 Supports full-duplex transfer mode for 1000Mbps

 Wire speed reception and transmission

 Store-and-Forward switching method

 Self learning for active MAC addresses up to 4K entries

 Comprehensive front-panel diagnostic LEDs

 Supports IEEE 802.3x flow control for full-duplex mode and backpressure flow control for

half-duplex mode

Standards IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T

Cables 10Base-T: Cat.3, 4, 5 or higher ( 100 meters max. )

100Base-TX: Cat.5, 5e or higher ( 100 meters max. )

1000Base-T: Cat.5e or higher ( 100 meters max. )

Number of Ports 5 x 10/100/1000Mbps auto-MDI/MDI-X ports with RJ-45 connector

Network Data Ethernet: 10Mbps (Half-duplex) 20Mbps (Full-duplex)

Transfer Rate Fast Ethernet: 100Mbps (Half-duplex) 200Mbps (Full-duplex)

Gigabit Ethernet: 2000Mbps (Full-duplex)

MAC Address Table 4K entries

LEDs Per Unit: Power

Per Port: Link/ACT, 100M/1000M

Environment Operating temperature: 0oC ~ 40oC

Storage temperature: -10oC ~70oC

Relative Humidity: 10% ~ 90%RH non-condensing

Dimension 155 x 109 x 33 mm (WxDxH)

Power +5VDC/2A

Power 5 watts. (max.)

Consumption

Approval FCC Class B, CE mark Class B
