LevelOne KVM-0213 Manuale utente

Ver. 1.0.0-0803

KVM-0213

2-Port PS/2 Cable KVM Switch

LevelOne

User Manual

English

Package Contents

1. KVM-0213

2. User Manual

3. Quick Installation Guide

Requirements

Console

A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be

using on any computer in the installation

A PS/2 Mouse

A PS/2 Keyboard

Computers

The following equipment must be installed on each computer that is to be connected to the

system:

A VGA, SVGA or Multisync video port

A 6-pin Mini-DIN (PS/2 style) mouse port

A 6-pin Mini-DIN (PS/2 Style) keyboard port

Hardware Review

1. Port LEDs

2. KVM Cables

3. Speaker Jack

4. Console Ports

5. PS/2 mouse connector

6. PS/2 keyboard connector

7. Speaker Plug

8. Video Connector 3

Installation

Important

1. Before you begin, make sure that the power to all the devices you will be connecting has

been turned off. You must unplug the power cords of any computers that have the

Keyboard Power On function. Otherwise, the switch will receive power from the computer.

2. To prevent damage to your equipment, make sure that all the devices you will be

connecting are properly grounded.

Installing your new KVM-0213 involves the following steps:

1. Plug your keyboard, monitor, and mouse into the Console ports on the KVM-0213. Each

port is labeled with an appropriate icon.

2. Plug your speakers into the KVM-0213’s speaker jack. *This step is optional

3. Plug the attached KVM cables’ keyboard, monitor, mouse, and speaker connectors into

their respective ports on the computers you are installing.

After you have finished attaching the cables, turn on the power to the computers.

Note: The KVM-0213’s Power On default is to link to the first computer you turn on.

Operation

Hotkey Port Selection

All hotkey port switches begin with tapping the Scroll Lock key twice.

[Scroll Lock] [Scroll Lock]

Invokes Auto Scan Mode

Starts Auto Scan. Press and release the [Left Shift] key, and then press the [Right Shift] key.

[Left Shift] [Right Shift]

Scan Interval

Sets theAuto Scan interval to n second intervals - where n is a number from 1 – 4.

[Left shift] [Right shift] [S] [n]

The n stands for the number of seconds that the focus dwells on a port

before switching to the other one. Replace the n with a number

between 1 and 4 when entering this hotkey combination. (See the

table, below.)

Scan Interval Table

n Sec.

1 3 Sec.

2 5 Sec. (Default)

3 10 Sec.

4 20 Sec.

Troubleshooting

Symptom Possible Cause Action

Keyboard needs to be reset. Unplug the keyboard from

the Console

Keyboard Port, then plug it

back in.

Keyboard Not Responding

Switch needs to be reset. Turn off the computers.

Unplug the KVM cables. Wait

five seconds; then plug the

cables back in and turn the

computers on.

Pressing Hot Keys Gets No

Response

Hotkey sequence input

incorrectly.

Resend the Hotkey

command – press and

release each key in the

sequence individually.

Mouse Not Detected, or

Does Not Respond Correctly

Mouse needs to be reset. Unplug the mouse from the

Console

Mouse Port, then plug it back

in.

Video Problems Resolution and/or

Bandwidth set too high.

Select a lower resolution

and/or bandwidth.

Specifications

Function KVM-0213

Computer Connections 2

Port Selection Hotkey

Keyboard 1 x 6-pin Mini-DIN Female (Purple)

Video 1 x HDB-15 Female (Blue)

Mouse 1 x 6-pin Mini-DIN Female (Green)

Console

Ports Speaker 1 x Mini Stereo Jack Female (Green)

Keyboard 2 x 6-pin Mini-DIN Male (Purple)

Video 2 x HDB-15 Male (Blue)

Mouse 2 x 6-pin Mini-DIN Male (Green)

Connectors

KVM

Ports

Speaker 2 x Mini Stereo Plug Male (Green)

LEDs Selected 2 (Green)

Cable

Length Computers 1.2m

Emulation Keyboard/ Mouse PS/2

Video 2048 x 1536; DDC2B

Scan Interval 3, 5, 10, 20 Seconds

Operating Temp. 0-50°C

Storage Temp. -20-60°C

Environment Humidity 0-80% RH, Non-condensing

Housing Plastic

Weight 0.41 kg

Physical

Properties Dimensions

(L x W x H) 8.1 x 6.3 x 2.35 cm
