OWNER’S MANUAL
FRENCH DOOR
REFRIGERATOR
lease read this owner's manual thoroughly before
operating and keep it handy for reference at all times.
LMX25964**
P/No.: MFL37933588 www.lg.com
ENGLISH FRANÇAIS ESPAÑOL
2
IMPORTANT SAFETY INFORMATION
Basic Safety Precautions ........................................3
CFC Disposal ..........................................................4
How to Connect Electricity ......................................5
PARTS AND FEATURES
Special Features .....................................................6
Key Parts and Co ponents ....................................7
INSTALLATION
Choose the Proper Location ...................................8
Clearances ..............................................................8
Flooring ...................................................................9
Handle Re oval......................................................9
Door and Drawer Re oval....................................10
Connecting the Water Supply ...............................18
Connecting the Water Lines..................................18
Leveling the Refrigerator Doors ............................20
Starting..................................................................21
HOW TO USE
Control Panel Features .........................................22
The LED Display ...................................................23
Operating the Dispenser ......................................23
Adjusting the Te peratures and Display .............24
Setting the Functions ...........................................25
In-Door Ice Bin .....................................................26
Auto atic Ice aker .............................................27
Storing Foods .......................................................28
Location of Foods .................................................29
Shelf Height Adjust ent .......................................30
Utility Bin (Optional) ..............................................30
CARE AND CLEANING
Re oving and Replacing Co ponents ................31
Cleaning the Refrigerator .....................................33
General Infor ation .............................................33
Light Bulb Replace ent .......................................34
Replacing the Water Filter.....................................35
TROUBLESHOOTING
Before Calling for Service ....................................36
SPECIFICATIONS
Key Di ensions and Specifications .....................40
WARRANTY
Product Registration Infor ation ..........................41
THANK YOU!
Congratulations on your purchase
and welco e to the LG fa ily.
Your new LG French Door
Refrigerator co bines
advanced cooling technology
with si ple operation and high
efficiency. Follow the operating
and care instructions in this
anual and your refrigerator
will provide you with any years
of reliable service.
3
BASIC SAFETY PRECAUTIONS
This guide contains many important safety messages. Always read and obey all
safety messages.
w This is the safety alert sy bol. It alerts you to safety essages that infor you of hazards that can kill
or hurt you or others or cause da age to the product. All safety essages will be preceded by the safety
alert sy bol and the hazard signal word DANGER, WARNING, or CAUTION. These words ean:
wDANGER You might be killed or seriously injured if you don’t follow instructions.
wWARNING You can be killed or seriously injured if you don’t follow instructions.
wAUTION Indicates an i inently hazardous situation which, if not avoided, may
result in inor or oderate injury, or product da age.
All safety essages will identify the hazard, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.
wWARNING
To reduce the risk of fire, electric shock, or
injury to persons when using your product,
basic safety precautions should be followed,
including the following.
Read all instructions before using this appliance.
• NEVER unplug your refrigerator by pulling on the
power cord. Always grip the plug fir ly and pull it
straight out fro the outlet.
• Repair or replace i ediately all electric service
cords that have beco e frayed or otherwise
da aged. Do not use a cord that shows cracks or
abrasion da age along its length or at either the
plug or connector end.
• When oving your refrigerator away fro the wall,
be careful not to roll over or da age the power cord.
• DO NOT store or use gasoline or other fla able
vapors and liquids in the vicinity of this or any other
appliance.
• Do NOT allow children to cli b, stand, sit or hang
on doors, drawers or shelves of the refrigerator.
They could da age the refrigerator and seriously
injure the selves.
• Keep fingers out of pinch point areas; clearances
between the doors and cabinet are necessarily
s all. Be careful closing doors when children are
in the area.
• Unplug your refrigerator before cleaning or aking
any repairs.
NOTE: Service should be perfor ed by a qualified
technician.
• Before replacing a burned-out light bulb, unplug the
refrigerator or turn off power at the circuit breaker
or fuse box in order to avoid contact with a live wire
fila ent. (A burned-out light bulb ay break when
being replaced.)
NOTE: So e odels have LED interior lighting and
service should be perfor ed by a qualified
technician.
NOTE: Setting either or both controls to the OFF
position does not re ove power to the light circuit.
• When you are finished, reconnect the refrigerator to
the electrical source and reset the control
(Ther ostat Refrigerator Control, or Freezer
Control, or Freezer Control, depending on the
odel) to the desired setting.
• This refrigerator ust be properly installed in
accordance with the Installer Instructions that
were taped to the front of the refrigerator.
• After your refrigerator is in operation, do not touch
the cold surfaces in the freezer co part ent when
hands are da p or wet. Skin ay adhere to the
extre ely cold surfaces.
• In refrigerators with auto atic ice akers, avoid
contact with the oving parts of the ejector
echanis or with the heating ele ent that
releases the cubes. DO NOT place fingers or hands
on the auto atic ice aking echanis while the
refrigerator is plugged in.
• Do not modify or extend the power cord length.
It will cause electric shock or fire.
ENGLISH
4
BASIC SAFETY PRECAUTIONS (CONT.)
• Do not use drier to dry the inside, nor light a candle to
re ove odor.
• Install in places away fro the fire such as the place
where fla able gas is leaked.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
ental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
• DO NOT refreeze frozen foods which have
thawed co pletely. The United States
Depart ent of Agriculture in Ho e and Garden
Bulletin No. 69 says:
…You ay safely refreeze frozen foods that have
thawed if they still contain ice crystals or if they are
still cold—below 40°F (4°C).
…Thawed ground eats, poultry, or fish that have
any off-odor or off-color should not be refrozen
and should not be eaten. Thawed ice crea
should be discarded. If the odor or color of any
food is poor or questionable, dispose of it. The
food ay be dangerous to eat.
Even partial thawing and refreezing reduces the
quality of foods, particularly fruits, vegetables,
and prepared foods. The eating quality of red
eats is affected less than that of any other
foods. Use refrozen foods as soon as possible to
save as uch of their quality as you can.
CFC DISPOSAL
Your old refrigerator ay have a cooling syste
that used CFCs (chlorofluorocarbons). CFCs are
believed to har stratospheric ozone.
If you are throwing away your old refrigerator,
ake sure the CFC refrigerant is re oved for
proper disposal by a qualified servicer. If you
intentionally release this CFC refrigerant, you can
be subject to fines and i prison ent under
provisions of environ ental legislation.
wDANGER
Risk of hild Entrapment
Discarded or abandoned refrigerators are
dangerous, even if they will sit for just a few
days. If you are disposing of your old refrigerator,
please follow the instructions below to help prevent
accidents.
Before you throw away your old refrigerator or
freezer:
• Take off the doors.
• Leave the shelves in place so that children ay
not easily cli b inside.
5
HOW TO CONNECT ELECTRICITY
IMPORTANT: Please read carefully.
wWARNING
Electrical Shock Hazard
For personal safety, this appliance must be
properly grounded. Have the wall outlet and
the circuit checked by a qualified electrician to
make sure the outlet is properly grounded.
RECOMMENDED GROUNDING METHOD
The refrigerator should always be plugged into
its own individual properly grounded electrical
outlet rated for 120 volts, 60 Hz, AC only, and
fused at 20 a peres. This provides the
best perfor ance and also prevents overloading
house wiring circuits which could cause a fire
hazard fro overheated wires. It is
reco ended that a separate circuit serving
only this appliance be provided.
Use a receptacle which cannot be turned off with
a switch or pull chain. Do not use an extension
cord. Where a standard two-prong wall outlet is
encountered, it is your personal responsibility
and obligation to have it replaced with a properly
grounded three-prong wall outlet.
Do not, under any circumstances, cut or
remove the third (ground) prong from the
power cord.
Do not use an adapter plug.
NOTE: So e odels have LED interior lighting and
service should be perfor ed by a qualified technician.
When you are finished, reconnect the refrigerator to
the electrical source and reset the control
(Ther ostat, Refrigerator Control, or Freezer Control,
depending on the odel) to the desired setting.
USE OF EXTENSION CORDS
Because of potential safety hazards under
certain conditions, we strongly recommend
against the use of an extension cord.
However, if you still elect to use an extension
cord, it is absolutely necessary that it be a UL-listed
(USA), 3-wire grounding-type appliance
extension cord having a grounding-type plug
and outlet and that the electrical rating of the
cord be 20 a peres ( ini u ) and 120 volts.
Use of an extension cord will increase the
clearance needed for the back of the
refrigerator.
NOTE: Before perfor ing any type of installation,
cleaning, or re oving a light bulb, turn the control
(Ther ostat, Refrigerator Control or Freezer Control,
depending on the odel) to OFF and then disconnect
the refrigerator fro the electrical source. When you
are finished, reconnect the refrigerator to the
electrical source and reset the control (Ther ostat,
Refrigerator Control or Freezer Control, depending on
the odel) to the desired setting.
SAVE THESE INSTRUCTIONS
ENGLISH
6
SPECIAL FEATURES
CONTROL PANEL LED DISPLAY SCREEN
Simple electronic controls are user-friendly.
The LED screen shows refrigerator and freezer
temperatures, displays water filter status,
dispenser information, and more.
ICE PLUS
When this feature is activated, the freezer section
will run at the coldest temperature for a 4- hour
period to increase ice production.
FILTERED WATER AND ICE DISPENSER
The water dispenser offers fresh, chilled, filtered
water through the door. The dispenser offers cubed
ice or water.
DOOR ALARM
A warning alarm sounds at 30-second intervals
when the refrigerator or freezer door is left open
for more than 60 seconds.
IN-DOOR ICE BIN
The icemaker automatically produces 80–130
ice cubes in a 4-hour period to keep the ice
dispenser fully supplied. The in-door design
creates more shelf space.
CRISPERS
LG’s crispers preserve humidity and
help vegetables stay crisp.
1
3
4
5
6
1
4
3
5
6
7
KEY PARTS AND COMPONENTS
In addition to the special features and co ponents outlined in the Special Features section,
there are several other i portant co ponents that are referenced in this anual.
ADJUSTABLE REFRIGERATOR SHELVING
The refrigerator co part ent shelves are
adjustable to allow flexibility for storage needs.
MODULAR DOOR BINS
Three interchangeable bins can be arranged to
suit your storage needs.
LED INTERIOR LAMPS
FIXED DOOR BIN
INTERIOR LAMP
1
2
3
4
5
4
1
5
2
3
ENGLISH
8
CHOOSE THE PROPER LOCATION
wWARNING
Excessive Weight Hazard
Two or more people are required when
moving and unpacking the appliance.
• Store and install the refrigerator where it will not
be exposed to te peratures below freezing or
exposed to outdoor weather conditions.
• Install this appliance in an area where the
te perature is between 55°F (13°C) and 110°F
(43°C). If the te perature around the appliance
is too low or too high, cooling ability ay be
adversely affected.
• If this refrigerator is installed where the
te perature is above 110°F (43°C), the
freezing capacity is co pro ised and the cost
of electricity used increases.
• To reduce the risk of electric shock, do not
install the refrigerator in a wet or da p area.
• Select a place where a water supply can be
easily connected for the auto atic ice aker
and dispenser.
• Unstable installation ay cause vibration and
noise. If the floor is not even, ake the
refrigerator level by rotating the height adjusting
screws.
• Properly ground the refrigerator to confor with
all governing codes and ordinances.
wAUTION
Avoid placing the unit near heat sources,
direct sunlight, or moisture.
CLEARANCES
• Too s all a distance fro adjacent ite s ay
result in lowered freezing capability and
increased electricity consu ption charges.
Allow at least 24 in. (61 c ) in front of the
refrigerator to open the doors.
NOTE: For co plete di ensions and specifications,
see page 40.
2" (5.08 c )
9
FLOORING
• To ini ize noise and vibration, the refrigerator
MUST be installed on a solidly constructed
floor.
• To avoid vibration, the unit ust be level. If
required, adjust the leveling legs to co pensate
for unevenness of the floor. The front should be
slightly higher than the rear to aid in door
closing. The leveling legs can be turned easily
by pushing against the top of the refrigerator to
take the weight off the feet. Turn the leveling
legs clockwise to raise the unit or
counterclockwise to lower it.
• Carpeting and soft tile surfaces are not
reco ended.
• Never install the refrigerator on a platfor or
weakly supported structure.
NOTE: When oving the refrigerator for cleaning
or service, be sure to protect the floor. Always
pull the refrigerator straight out when oving it.
Do not wiggle or walk the refrigerator when trying
to ove it; floor da age could occur.
HANDLE REMOVAL
NOTE: Handle appearance ay vary fro
illustrations on this page. wAUTION
• Use special care when re oving handles to
prevent scratching the doors.
• The handle could be da aged if you hit it with
a ha er while re oving or attaching.
• When you asse ble or disasse ble a handle,
you ust push or pull with reasonable force.
NOTE: It is reco end that the doors be re oved when it is necessary to ove the refrigerator through a
narrow opening.
• To re ove the refrigerator handle, grasp the handle
tightly with both hands and forcefully slide the
handle upward. The keyhole slots on the back of the
handle allow the handle to separate fro the
ounting screws.
ENGLISH
10
HANDLE REMOVAL (CONT.)
HANDLE REINSTALLATION
DOOR AND DRAWER REMOVAL
DOOR REMOVAL
wWARNING
Electric Shock Hazard
• Disconnect electrical supply to the refrigerator
before installing. Failure to do so could result in
death or serious injury.
• Do not put hands or feet or etal sticks into the air
vents, base grille, or botto of the refrigerator. You
ay be injured or receive an electrical shock.
• Be careful when you work with the hinge, base
grille, and stopper. You ay be injured.
Before you begin, re ove food and bins fro the
doors.
If your entrance door is too narrow for the refrigerator
to pass through, re ove the refrigerator door and
ove the refrigerator sideways through the doorway.
• To reinstall the refrigerator door handle, align the
keyhole slots on the top and botto of the back of
the handle with the screws ounted on the front of
the door. Press the handle against the door front,
aking sure that the screws go into the keyhole
slots.
Holding the handle with both hands, press it fir ly
against the front of the door and slide the handle
downward.
To remove the left refrigerator door:
Pull the water tube out of the fitting while
pressing the release ring on the fitting.
NOTE : When you pull out the tube, first you
have to push the collet by opposite direction
of arrow in the upper picture and pull the tube
out by direction of arrow.
1
ollet
Altri manuali per LMX25964SS
2
Questo manuale è adatto per i seguenti modelli
2
Indice
Altri manuali LG Frigorifero
LG
LG LRTNC0915V Manuale utente
LG
LG GL-B200HRLN Manuale utente
LG
LG GF-50712 Series Manuale utente
LG
LG GS-VB655MBL Manuale utente
LG
LG VS27JT Manuale utente
LG
LG LSFXC2476 SERIES Manuale utente
LG
LG LTWS24223 Manuale utente
LG
LG GRX-274DPB Manuale utente
LG
LG LSC27910TT Manuale utente
LG
LG GR-M352YVQ Manuale utente
LG
LG LSC27910 Series Manuale utente
LG
LG Refrigerator-freezer Manuale utente
LG
LG LFC22770* Manuale utente
LG
LG LTN16385PL Manuale utente
LG
LG LSC 27960ST Manuale utente
LG
LG LFD25860 Series Manuale utente
LG
LG LSC27931SW Manuale utente
LG
LG LFC22760ST Manuale utente
LG
LG LRFD22850 series Manuale utente
LG
LG LFX21976ST Manuale utente
