Lightolier ProSpec 26890 Manuale utente

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

ProSpec® Track Lighting System 26890

Page 1 of 1 ProSpec® Recessed Flangeless Monopoint

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Features

1. ProSpec Track Strip: Structural aluminum extrusion; average wall

thickness 0.08".

2. Mounting Frame: .012" thick galvanized corner bead. Allows for finished

plaster edge.

3. Insulated Liner: 0.040 wall high temperature extruded thermoplastic.

4. Conductors: “U” shaped copper conductor; increases contact surface and

minimizes contact resistance; provides reliable positive connection.

5. Mounting Brackets: 18 ga. galvanized steel. Adjustable to accommodate

1/2" to 3/4" ceiling thicknesses.

6. Knockouts: Allows power feed from above using 3/8" or 1/2" (trade size)

connector (by others).

Finish

All painted finishes are baked enamel.

Electrical

(2) circuits. Each circuit is 120V, 60 Hz. Each circuit has dedicated neutral for

maximum control flexibility. Track is continuously grounded throughout. Electrical

conductors are concealed in an insulated liner in the track. Intended for wiring

to branch circuit building wire with ground, in accordance with national and

local codes.

Labels

cULus

Ordering Information

Catalog No. Finish Mounting Compatibility

26890WH

26890BK

Matte White

Matte Black

Intended for recessing into drywall type ceilings with

plaster skim coat. Accommodates ceiling thicknesses

of 1/2" to 3/4".

ProSpec track luminaires, 500W Max. NOT

FOR USE with ProSpec PAR56 or PAR64 track

mounted units.

SECTION A-A

1.33

7 1/16

[179.4]

3 13/16

[97.3]

9 9/16

[242.9]

3 7/16

[86.6]

4 1/4

[108.2]

3 3/8

[85.7]

10 1/4

[259.7]

5 9/16

[141.6]
