Linksys USBBT100 Manuale operativo

Model No.

Product Data

Wireless

USBBT100

Add Bluetooth connection capability to your PC!

Add Bluetooth 1.1

connectivity to your

USB-equipped

notebook or desktop

computer

Use your mobile

phone to connect

your notebook

computer to the

Internet, while the

phone is still in your

pocket

Wirelessly connect to

local devices such as

mobile phones, PDAs,

printers, headsets,

other computers,

mice, keyboards, and

Synchronize data

between your PC

and PDA, and keep

your mobile phone's

address book up to

date

The Linksys USB Bluetooth Adapter adds local wireless

connectivity to your USB-equipped computer. Bluetooth

technology lets you connect various electronic devices

together wirelessly, eliminating the need for wires all over

your desktop, and easily connecting your notebook to

peripherals in an airport lounge without all the cable clutter.

With the USB Bluetooth Adapter plugged into a USB port on

your notebook or desktop computer, you'll be able to

connect with other Bluetooth-enabled devices to

synchronize the data in your PDA, transfer files to other

computers, send files to printers or fax servers, use a wireless

mouse, keyboard, or telephony headset, or use your mobile

phone as a link to the Internet, all without cables.

Up to seven Bluetooth 1.1 compatible devices can connect

to the USB Bluetooth Adapter simultaneously, creating your

own “Personal Area Network”. The Adapter itself is powered

directly from the USB port, so there's no need for an external

power supply. To keep your data secure, Bluetooth

technology uses 128-bit encryption and a “frequency

hopping” scheme that's almost impossible to intercept.

Bluetooth peripherals broadcast their availability and offer

their specific services to local authorized systems. The

Bluetooth management and connectivity software included

with the USB Bluetooth Adapter makes it easy to discover

and connect to these nearby devices. Enter a whole new

world of wireless connectivity with the Linksys USB Bluetooth

Adapter.

USB Adapter

Bluetooth

Model No.

Product Data

Model No.

Linksys

A Division of Cisco Systems, Inc.

18582 Teller Avenue

Irvine, CA 92612 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit

our Worldwide Web Site at www.linksys.com.

USBBT100

Package Contents

• Bluetooth USB Adapter

• USB Extension Cable

• Setup CD-ROM with User Guide

• Quick Installation

• Registration Card

Bluetooth

Minimum Requirements

• 200MHz or Faster PC

• 64 MB of RAM

• Available USB port

• CD-ROM Drive

• Windows 98SE, Me, 2000, or XP

Specifications

Model Number USBBT100

Standards Bluetooth 1.1, USB 1.1

Operating

Frequency 2.4 ~ 2.4835GHz

LEDs One LED

Transmitted Power 13~17 dBm (Class 1)

Antenna 1.2 dBi

Receive Sensitivity -80 dBm @ 0.1% BER

Power Consumption Typical: 110 mA

Transmit: 200 mA

Receive: 80 mA

Idle: 26 mA

Security Features 128-bit Encryption

Transmission Speed 721Kbps (Max)

Wireless Technology Frequency Hopping Spread Spectrum

Environmental

Dimensions 2.95" x 0.12" x 0.33"

W x H x D (75 mm x 3 mm x 8.5 mm)

Unit Weight 0.99 oz. (0.028 kg)

Certifications FCC

Operating Temp. 0ºC to 70ºC (32ºF to 104ºF)

Storage Temp. -20ºC to 90ºC (-4ºF to 158ºF)

Operating Humidity 10% to 90%, Non-Condensing

Storage Humidity 10% to 90%, Non-Condensing

Warranty 1-Year Limited

USBBT100-DS-30908NC JL

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2003

USB Adapter

Features

• Compliant with Bluetooth v1.1

Specification

• Supports USB 1.1 with up to

721Kbps Transfer Rate

• 128-bit Encryption and

Authentication Ensure Safe,

Secure Communications

• Connect up to 7 Bluetooth

Devices

• Wireless Connection Distance

up to 100 Meters

• Low Power Consumption

• Compatible with Microsoft

98SE, Me, Windows 2000, and
