Linksys WUSB54GS EU Manuale operativo
Model No.
Product Data
Wireless
WUSB54GS
The easy way to connect your PC to a
high-speed wireless network.
Now with SpeedBooster Technology!
High-speed wireless net-
working for your desktop or
notebook via USB 2.0
Wireless communica-
tions are protected
by up to 128-bit data
encryption
New SpeedBooster
technology increases
Wireless-G perfor-
mance by up to 35%
Easy, no-tools setup
on any desktop or
notebook computer
with USB support
Connect your USB-equipped desktop or notebook computer to
a wireless network at incredible speeds with the Linksys Wireless-
G USB Network Adapter with SpeedBooster. Using your high-
speed USB 2.0 port, the Adapter delivers incredible data rates
without the trouble of opening up the case of your computer.
The Wireless-G USB Network Adapter with SpeedBooster incor-
porates the next generation of Wireless-G. In standard Wireless-
G (802.11g) mode, the USB Adapter can connect to wireless
networks at an amazing 54Mbps. With our new SpeedBooster
technology enabled, your "real-world" wireless network perfor-
mance increases by up to 35%! Unlike other speed-enhanc-
ing technologies, SpeedBooster is 802.11 compliant, fully
compatible with standard Wireless-G, and a ""good neighbor""
to other wireless devices and technologies, using a single
2.4GHz channel as specified by the official wireless standard.
And with SpeedBooster you'll see an overall speed improve-
ment even when running a mixed network of SpeedBooster
and regular Wireless-G devices.
To install, simply plug the Adapter into any available USB port.
(It's compatible with both USB 1.1 and 2.0 ports, but 2.0 will
yield the fastest speeds.) It gets its power through the USB con-
nection, so no power cord is necessary. The included Setup
Wizard walks you through configuring the Adapter to your wire-
less network settings, step by step. The Adapter is also compat-
ible with the Wireless-B (802.11b) network standard, with data
rates up to 11Mbps. And your wireless communications can
be protected by 128-bit encryption, so your data stays secure.
USB Network Adapter
Wireless-G
with SpeedBooster
Model No.
Product Data
Model No.
Linksys
A Division of Cisco Systems, Inc.
18582 Teller Avenue
Irvine, CA 92612 USA
E-mail: [email protected]
Web: http://www.linksys.com
Linksys products are available in more than 50
countries, supported by 12 Linksys Regional Offices
throughout the world. For a complete list of local
Linksys Sales and Technical Support contacts, visit
our Worldwide Web Site at www.linksys.com.
WUSB54GS
Package Contents
• Wireless-G USB Network Adapter with
SpeedBooster
•USBCable
• Setup CD-ROM with User Guide
• Quick Installation
• Registration Card
Wireless-G
Minimum Requirements
• PC with 400MHz or Faster Processor:
• 128MB RAM Memory
• CD-ROM Drive
• Avaliable USB Port
• Windows 2000 or XP with Service Pack 1
(or later)
Specifications
Model Number WUSB54GS
Standards IEEE 802.11b, 802.11g, USB 1.1, USB 2.0
Ports One USB
Channels 802.11b / 802.11g
11 Channels (US, Canada)
13 Channels (Europe)
14 Channels (Japan)
LEDs Power, Link
Transmitted Power 15-17dBm (Typical)@11Mbps CCK,
15-17dBm (Typical)@54Mbps OFDM
Receive Sensitivity -67dBm@54Mbps, -82dBm@11Mbps
Security features WEP Encryption
WEP key bits 64, 128 Bit
Warranty 3 Year
Environmental
Dimensions 3.58" x 0.91" x 2.80"
W x H x D (91 mm x 23 mm x 71 mm)
Unit Weight .18 lbs. (0.08 kg)
Certifications FCC
Operating Temp. 0ºC to 55ºC
Storage Temp. -40ºC to 85ºC
Operating Humidity 10% to 85% Non-Condensing
Storage Humidity 5% to 90% Non-Condensing
WUSB54GS-DS-40814NC KL
Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2004
Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
USB Network Adapter with SpeedBooster
Features
• Compatible with 802.11g
and 802.11b (2.4GHz) Stard-
ards
• SpeedBooster technology
increases wireless perfor-
mance by up to 35%
• Supports USB 2.0 with up to
54Mbps, High-Speed Data
Transfer Rate with Automatic
Fallback
• Plug-and-Play Operation Pro-
vides Easy Setup
• Supports up to 128-bit WEP
Encryption Security
