Linksys EFROU44 - EtherFast 10/100 Analog Router Manuale utente

EtherFast®Series.

EtherFast

10/100 4-Port

Analog Router

User Guide

router.qxd 12/16/99 12:22 PM Page 2

trademark of Linksys. Microsoft, Windows, and the Windows logo are reg-

istered trademarks of Microsoft Corporation. All other trademarks and

brand names are the property of their respective proprietors.

LIMITED WARRANTY

Linksys guarantees that every EtherFast 10/100 4-Port Analog Router is

free from physical defects in material and workmanship under normal use

starting at the date of purchase. If the product proves defective during this

one year warranty period, call Linksys Customer Support in order to

obtain a Return Authorization number.Warranty is for repair or replace-

ment only. Linksys does not issue any refunds. BE SURE TO HAVE YOUR

PROOF OF PURCHASE AND BAR CODE ON HAND WHEN CALLING.

RETURN REQUESTS CANNOT BE PROCESSED WITHOUT PROOF OF

PURCHASE AND BAR CODE.When returning a product, mark the Return

Authorization number clearly on the outside of the package and include

your original proof of purchase and bar code.

IN NO EVENT SHALL LINKSYS’ LIABILITY EXCEED THE PRICE PAID

FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDEN-

TAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE

OF THE PRODUCT, ITS ACCOMPANYING SOFTWARE, OR ITS DOCU-

MENTATION. Linksys makes no warranty or representation, expressed,

implied, or statutory, with respect to its products or the contents or use of

this documentation and all accompanying software, and specifically dis-

claims its quality, performance, merchantability, or fitness for any particular

purpose. Linksys reserves the right to revise or update its products, soft-

ware, or documentation without obligation to notify any individual or entity.

Please direct all inquiries to:

Linksys P.O. Box 18558, Irvine, CA 92623

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules.These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can radi-

ate radio frequency energy and, if not installed and used according to the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particu-

lar installation. If this equipment does cause harmful interference to radio

or television reception, which is found by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of

the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment or device

• Connect the equipment to an outlet other than the receiver’s

• Consult a dealer or an experienced radio/TV technician for

assistance

903

router.qxd 12/16/99 12:22 PM Page 4

Contents

Introduction 2

Features 3

PlanningYour Network 7

Cabling Rules 8

Hardware Setup 9

Connecting Nodes and Uplinking 10

Protocol Setup for Windows 98 and 95 12

Internet Settings 14

Configuring the Router 15

Status Windows 18

Allowed Access Times 20

Router Identity 21

Set Router Clock 22

Customize Menu 23

Save or Reset Settings 24

Reboot Router 25

Upgrade Router 26

Change Password 27

Getting Help 28

Command Line Interface 29

LEDs 30

Appendix 31

Twisted Pair Cabling 31

Windows NT Setup 33

Unsupported Advanced Features Setup 35

Trouble Shooting 38

Specifications 40

Customer Support 41

router.qxd 12/16/99 12:22 PM Page 6

router.qxd 12/16/99 12:22 PM Page 7

Introduction

Congratulations on your purchase of a Linksys

EtherFast 10/100 4-Port Analog Router -- the perfect

stand-alone solution for multi-user LAN-to-Internet

connectivity. The EtherFast 10/100 4-Port Analog

Router from Linksys is the quickest and easiest way to

connect up to four external 56K modems to your

10/100 network. The 10/100 4-Port Analog Router

comes with 4 specially-designed RJ-45 modem ports

and 4 10/100 RJ-45 ports -- connect your workstations

directly to the router, or uplink to other hubs and

switches for expanded Internet sharing.

The user-friendly Web interface gets you off to a run-

ning start -- every user on the network will be able to

access the Internet in just minutes. The 10/100 4-Port

Analog Router connects up to four external modems to

seperate dial-up ISP accounts. Connect four 56Kbps

modems and you can enjoy blazing 224Kbps band-

width.

Since it also comes equipped with 4 dual-speed RJ-45

ports, your 10/100 Analog Router gives you all the

same features as a dual-speed hub. Whether you’ve got

a 10BaseT Ethernet or a 100BaseTX Fast Ethernet

network, the 10/100 Analog Router will automatically

adjust each port to run at the correct speed. The

10/100 Analog Router has a dynamic uplink feature

for increased expandability, 11 intelligent diagnostic

LEDs, and an ease-of-use that is unsurpassed. Backed

with free technical support and a one-year warranty,

the EtherFast 10/100 Analog Router is the best way to

connect your network to the Internet!

router.qxd 12/16/99 12:22 PM Page 8

The 10/100 Analog Router’s features include:

• Share 4 External Modems and 4 ISP Accounts On

Your 10/100 TCP/IP Network -- 4 RJ-45 LAN Ports

and 4 Serial Modem Connections

• Connects 4 Modems at Up To 56Kbps for an

Amazing Maximum Bandwidth of 224 Kbps

• Works With Virtually All V.90 and Hayes Compatible

External Modems

• Also Supports 4 10/100 Ethernet Connections

• Stand-Alone DHCP Server

• Easy-to-Use Web Interface

• Each Dual-Speed RJ-45 Port Automatically Senses

and Negotiates Between 10Mbps and 100Mbps

Network Connections

• Fully Functional IP Router

• Uplink Option For Expansion to Other Hubs or

Switches

• Helpful User Guide Features Instructions For Setting

Up the Right Protocols For Flawless Network and

Interent Sharing

• IPX Routing

• Fast Ethernet Power Offers Hot Performance for

Games, Multimedia, and File Transfers

• View Performance, Activity, and Utilization Statistics

For All 4 Modems On the Router Using the Web

Interface

• 11 Easy-to-Read LED Displays

• Free Technical Support

• Free Firmware Upgrades

• 1 Year Limited Warranty

router.qxd 12/16/99 12:22 PM Page 9

About Fast Ethernet

As the demand for desktop video, multimedia devel-

opment, imaging, and other speed-intensive applica-

tions continues to rise, the need for high performance,

fault tolerant LAN technology will become more criti-

cal.

Standard Ethernet, which has been the most popular

networking technology to date with a maximum data

throughput of 10 Megabits per second, is becoming

insufficient to handle the latest video, multimedia, and

other speed-intensive Client/Server LAN applications.

Among the solutions to the problem of network speed,

Fast Ethernet has emerged as the most viable and

economical. Capable of sending and receiving data at

100 Megabits per second, it is more than fast enough

to handle even the most demanding video and other

real-time applications.

Although there are a number of different competing

Fast Ethernet implementations, 100BaseTX is by far

the most popular. Operating on two pairs of Category

5 unshielded twisted-pair (UTP) cabling, 100BaseTX

supports high speed signaling and is relatively inex-

pensive. Because it uses four wires for data transmis-

sion and the same packet format, packet length, error

control, and management information as 10BaseT,

100BaseTX can be made to communicate with slower

10BaseT equipment when routed through a switch.

This backward compatibility is one of 100BaseTX's

major advantages over other forms of Fast Ethernet; it

allows critical, speed-dependent network segments to

be upgraded to 100BaseTX speeds as needed without

re-wiring, refitting, and retraining an entire site.

Networks can now mix both slow and fast network

segments for different users or departments.

router.qxd 12/16/99 12:22 PM Page 10

Publishing, R&D, video, multimedia, or accounting

departments can enjoy a 100Mbps pace, while other

corporate segments can operate at slower and more

affordable 10Mbps speeds.

Every 10/100 RJ-45 port on your Analog Router is

capable of running at either 10Mbps or 100Mbps,

allowing you to mix and match economical 10BaseT

hardware with high performance 100Mbps network

cards, hubs, switches, and other equipment.

BeforeYou Begin

Before you install your EtherFast 10/100 4-Port

Analog Router, you should take careful consideration

and ensure that several requirements have been met on

your network.

The router supports 10Mbps or 100Mbps connections.

It also supports multiple external modem connections.

Please be sure that your network adapters are installed

properly and working, you have a separate telephone

line and an Internet Service Provider (ISP) account for

every modem you plan to use. You must have or obtain

the access phone number, user account and the pass-

word for each of your ISP accounts. If you were using

a Proxy software previously to connect to the internet,

use the instructions that came with the software to

remove the software from your computer. The modem

router will not work properly if proxy software has

been previously installed.

Workstations on your network must have TCP/IP

installed and configured to obtain an IP address auto-

matically using Dynamic Host Control Protocol

(DHCP). If you are using Windows 95, Windows 98 or

Windows NT, detailed instruction about setting up

TCP/IP on Windows 98 or 95 workstations are includ-

router.qxd 12/16/99 12:22 PM Page 11

ed in this guide on page 12. Suggested settings and

instructions for Windows NT are included in the

appendix. Setup, configuration, and troubleshooting of

the TCP/IP protocol under any other operating system

is solely up to the user

Each workstation connected to Analog Router must be

running a Web browser (Netscape Navigator 3.0 or

newer, or Internet Explorer 3.0 or newer) in order to

connect to the Internet. Any browser you use to con-

figure the Analog Router must support HTML 3.2 or

later, and it must support Java and frames.

After the router settings are saved, all you need to do

in order to access the internet is open your browser.

The router will do the rest.

router.qxd 12/16/99 12:22 PM Page 12

Planning Your Network

The rules that govern how nodes and hubs are distrib-

uted across a network are important to ensure the

integrity of your data. Cabling specifications, distance

limits, and other topology rules must be followed in

order to avoid collisions or data loss.

The Analog Router is equipped with 4 10/100 UTP

ports that can automatically adjust to either 10Mbps or

100Mbps speeds. Each port can operate at either

speed, completely independent of the other ports

speeds, and can be connected to a workstation, file

server, print server, hub, or another node with twisted-

pair cabling.

Although there are different grades of cabling, you

must use EIA 568 Category 5 unshielded twisted-pair

(UTP) for each connection you make, and each cable

should not exceed 100 meters, (328 feet), in length.

Fast Ethernet networks require Category 5 cabling.

Category 5 cabling can be obtained at most computer

stores, or you can crimp your own.

router.qxd 12/16/99 12:22 PM Page 13

Indice

Altri manuali Linksys Router di rete

Linksys

Linksys BEFVP41 - EtherFast Cable/DSL VPN Router Manuale utente

Linksys

Linksys WRV54G - Wireless-G VPN Broadband Router... Manuale utente

Linksys

Linksys SFE1000P Manuale operativo

Linksys

Linksys WRT160N - Wireless-N Broadband Router... Guida rapida

Linksys

Linksys EF3508 Manuale utente

Linksys

Linksys RVL200 Manuale utente

Linksys

Linksys VELOP LN1100 Series Manuale utente

Linksys

Linksys Instant Broadband Series Manuale utente

Linksys

Linksys MAX-STREAM EA8300 Manuale utente

Linksys

Linksys WRT54G - Wireless-G Broadband Router... Guida rapida

Linksys

Linksys WRT54GH Manuale utente

Linksys

Linksys WRT160N - Wireless-N Broadband Router... Manuale utente

Linksys

Linksys SPA2102-AN - Single Port Router Manuale utente

Linksys

Linksys BEFSR41 - EtherFast Cable/DSL Router Manuale utente

Linksys

Linksys MAX-STREAM EA9250 Manuale utente

Linksys

Linksys WET54G - Wireless-G EN Bridge Manuale utente

Linksys

Linksys MAX-STREAM Manuale utente

Linksys

Linksys RV082 Istruzioni operative originali

Linksys

Linksys HomeLink HPB200 Manuale utente

Linksys

Linksys Velop Plug-in WHW01P Manuale utente

Linksys

Linksys WET54GS5 - Wireless-G EN Bridge Istruzioni operative originali

Linksys

Linksys EA8500 Manuale utente

Linksys

Linksys WET54Gv2 Manuale utente

Linksys

Linksys WRVS4400N - Small Business Wireless-N Gigabit Security... Manuale utente

Manuali Router di rete popolari di altre marche

Allnet

Allnet ALL0333AU Manuale utente

HomeSeer

HomeSeer HT-SEL Manuale utente

Sercomm

Sercomm Genesis OC3505D Manuale utente

Billion

Billion BIPAC 5102 Series Manuale utente

TP-Link

TP-Link TD-8817 Manuale utente

Motorola

Motorola MR1900 Manuale utente

Digi

Digi IX14 Manuale utente

Cisco

Cisco NCS 540 Manuale

XAVi

XAVi X8821e Manuale utente

BEC

BEC 6200WZL Manuale utente

MikroTik

MikroTik hAP ac3 Series Manuale utente

Korenix

Korenix JetNet 5428G Series Manuale utente

NETGEAR

NETGEAR FS526T - Switch Manuale utente

Korenix

Korenix JetNet 5710G Series Manuale utente

Automated Logic

Automated Logic ZN551 Manuale del proprietario

Cisco

Cisco ASR 1000 Series Manuale dell'operatore

EnGenius

EnGenius ESR-9710 Manuale utente

Cisco

Cisco 805 Series Istruzioni operative e di sicurezza
