Linksys RVS4000 Manuale operativo

PRODUCT DATA

BUSINESS SERIES

4-Port Gigabit Security Router

with VPN

Model: RVS4000

Secure, smart Gigabit networking for

growing business

Protection of your network is a mission critical activity. At Linksys, we build powerful

security into every product, to keep your wired and wireless networks safe. Linksys

Small Business Series systems have advanced ﬁrewall, encryption and authentication

features to protect you from network threats – threats that can seriously disrupt or

damage your business by stealing your valuable data, slowing down your network and

interfering with business-critical applications. Our systems ensure maximum application

availability enabling you to meet corporate governance and business continuance

requirements.The Linksys Small Business Series is the affordable, reliable, high quality

networking solution that helps you do business smarter.Secure and easy to install and

maintain, it’s built to grow with your business.

With broadband speeds increasing beyond 20Mbps, many of the existing 10/100 gateways

do not have the processing power to support these higher data rates, becoming the

bottleneck in the network.The RVS4000 10/100/1000 4-Port VPN Router operates at Gigabit

speeds to meet the demands of today’s networks. It features Linksys’proven SPI Firewall with

an integrated Intrusion Detection and Prevent System (IDS/IPS).

Its built-in 4-port, full-duplex 10/100/1000 Ethernet switch can connect up four PCs directly,

or additional hubs and switches.The QoS features provide consistent voice and video quality

throughout your business.

In addition the RVS4000 features a Virtual Private Network (VPN) security engine that creates

encrypted “IPSec tunnels”through the Internet.The IPSec VPN tunnels enable remote users from

at home, or on the road to easily, and securely connect to the ofﬁce network through a typical

wired or wireless broadband connection.When used with another RVS4000 or other Linksys VPN

router,“branch-to-branch” connections can be established allowing users in a remote ofﬁce to

connect to the corporate network.

Gigabit networking to

support high-bandwidth

applications

SPI Firewall, and Intrusion

Protection secure the work

from outside threats

QuickVPN IPSec VPN tunnel

support provides secure

remote user connectivity

QoS provide improved

quality voice/video quality

RVS4000

PRODUCT DATA

BUSINESS SERIES

Features

IPSec VPN tunneling for

remote user and

branch-to-branch

connectivity

Stateful Packet Inspection

Firewall with network

address translation (NAT)

4-Port 10/100/1000 switch

with automatic rate

negotiation and automatic

MDI/MDIX detection

IDS/IPS network intrution

detection and protection

services with email alerts

- Free signature updates are

provided for one year

User deﬁneable access

control lists (ACL) for

restricting inbound and

outbound trafﬁc ﬂows

QoS support

DHCP Client (WAN) and

Server (LAN) with Dynamic

DNS support

Easy installation and

conﬁguration through the

Web Interface and QuickVPN

sofware

SNMP v1 and v2c support

•

4-Port Gigabit Security Router with VPN

Speciﬁcations

Model RVS4000

Standards IEEE802.3, 802.3u, 802.1x, RFC791 (IP Protocol)

Ports Ethernet, Power

Buttons Reset

Cabling Type UTP CAT 5

LEDs Power, Diag, IPS (Blinks RED - Internal attack, Green - external),

LAN 1-4, Internet

Operating System Linux

Performance

NAT Throughput 800 Mb/s

Setup/Conﬁg

WebUI Built in Web UI for Easy browser-based conﬁguration (HTTP/HTTPS)

Management

SNMP Version SNMP Version 1, 2c

Event Logging Event Logging: Local, Syslog, E-mail Alerts

Web F/W upgrade Firmware Upgradable Through Web-Browser

Diags: Flash, etc. Diags: Flash, RAM

Security

Access Control IP and MAC based Access Control List (ACL)

Firewall Stateful Packet Inspection (SPI) ﬁrewall

Content Filtering URL blocking, keyword blocking

IPS (Intrusion Prevention System) IP Sweep Detection, Application Anomaly Detection

(HTTP, FTP, Telnet, RCP), P2P Control, Instant Messenger Control,

L3-L4 Protocol (IP, TCP, UDP, ICMP) Normalization, L7 Signature Matching

Signature Update Manual download from the web (Free download for 1 year)

Secure Management HTTPS, Username/Password

802.1x Port-based Radius Authentication (EAP-MD5, EAP-PEAP)

QoS

Prioritization types Port-based and Application-based Priority

Queues 4 queues

Network

VLAN Support Port-based VLAN

DHCP DHCP Server, DHCP Client, DHCP Relay Agent

DNS DNS Relay, Dynamic DNS (DynDNS, TZO)

NAT PAT, NAPT, ALG support, NAT Traversal

DMZ Software conﬁgurable on any LAN port

VPN 5 QuickVPN Tunnels for remote client access

5 IPSec Gateway-to-Gateway Tunnel for branch ofﬁce connectivity

3DES Encryption

MD5/SHA1 Authentication

IPSec NAT-T

VPN Passthrough of PPTP, L2TP, IPSec

Routing Static and RIP v1,v2

PRODUCT DATA

BUSINESS SERIES

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more

than 50 countries, supported by

12 Linksys Regional Ofﬁces throughout

the world.For a complete list of local

Linksys Sales and Technical Support

contacts, visit our Worldwide Web Site

at www.linksys.com.

Check the product package and contents for speciﬁc features supported.Speciﬁcations are subject to change without notice. Linksys is a registered trademark or

product names are trademarks or registered trademarks of their respective holders.

Model: RVS4000

Environmental

Dimensions 6.69 x 1.61 x 6.69”

W x H x D (170 x 41 x 170 mm)

Unit Weight 0.84 lbs (0.38 kg)

Power 12V 1A

Certiﬁcation FCC class B, CE, ICES-003

Operating Temp. 32 to 104ºF (0 to 40ºC)

Storage Temp. -4 to 158ºF (-20 to 70ºC)

Operating Humidity 10% to 85% Noncondensing

Storage Humidity 5% to 90% noncondensing

Package Contents

RVS4000 4-Port Gigabit Security Router with VPN

User Guide on CD-ROM

Network Cable

Power Adapter

Stands

Registration Card

Quick Install Guide

Minimum Requirements

Network Adapter With Ethernet Network Cable and TCP/IP Protocol Installed Per PC

Web-Based Conﬁguration Java/Cookies/SSL-Enabled Web Browser

•

RVS4000-DS-60706NC-RR
