Linksys EG005W - Instant Gigabit Workgroup Switch Manuale utente

Gigabit 5-Port

Workgroup Switch

he Gigabit 5-Port Workgroup Switch provides non-block-

ing, wire speed switching for your 10, 100, and 1000

megabit network clients. Drop this switch in place of your

current workgroup hub or switch, and you can upgrade your

high-requirement workstations to full Gigabit speeds as neces-

sary, while continuing to service other clients at their current

speeds. Or build your network from the ground up, with appro-

priate link speeds for each user's requirements.

Apply this switching power to your current hub-based Ethernet

network, and your data traffic efficiency will improve several

times over. Connect your Gigabit-equipped workstations to the

Switch's 10/100/1000 ports for full-duplex, dedicated bandwidth

of up to 2000Mbps! It's perfect for graphics, multimedia, and

other applications that have to move large files across the net-

work quickly.

With the Gigabit 5-Port Workgroup Switch, you can connect your

existing 10/100 Ethernet network to your Gigabit server back-

bone without any additional equipment. All ports are auto-nego-

tiating, and have automatic MDI/MDI-X crossover detection, so

you don't have to worry about the cable type. Address learning

and aging is supported, as well as 802.3x flow control with

head-of-line blocking prevention to keep your high-speed clients

from bogging down in lower-speed traffic.

The Gigabit 5-Port Workgroup Switch from Linksys is the perfect

solution for your desktop Gigabit and 10/100 networking needs.

• 5 RJ-45 10/100/1000Mbps auto-sensing half/full duplex

switched ports

• All ports suppport auto MDI/MDI-X cable detection

• Fully compliant with IEEE 802.3, 802.3u, 802.3x, 802.3ab

• Non head-of-line blocking architecture

• Full-duplex IEEE 802.3x flow control and half-duplex back-

pressure with intelligent port-based congestion detection

and broadcast rate control

Gigabit 5-Port Workgroup Switch

Model No.: EG005W

Connects network devices together, managing

the flow of data between them.

Features

Benefits

• Five 10/100/1000Mbps, half/full duplex,

switched ports

• Forwards and filters packets at non-blocking,

full wire speed

• All ports have auto speed negotiation and auto

MDI/MDI-X crossover detection

• Supports address learning and aging, 802.3x

flow control and head-of-line blocking preven-

tion

Instant Gigabit®Series

Package ContentsSpecifications

Model Number EG005W

Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab

Ports 5 RJ-45 10/100/1000 Mbps ports

Cabling Type Category 5e Recommended

LEDs Power, Link/Act, Speed, FDX

Environmental

Dimensions 7.32" x 1.89" x 6.06"

(186 mm x 48 mm x 154 mm)

Unit Weight 1.1 lbs. (0.5 kg)

Power External Power Supply 12V DC, 2A. Input

110 V AC Consumption 18W

Certifications FCC Part 15 Class A

Operating Temp. 32ºF to 122ºF (-1ºC to 50ºC)

Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 20% to 95%, Non-Condensing

• One Gigabit 5-Port Workgroup Switch

• One AC Power adapter

• One registration card

• One User Guide

• 200Mhz or Faster Processor

• 64MB RAM Recommended

• Ethernet or Gigabit Network Adapter

• Cat5e Ethernet Network Cable

Minimum Requirements

DS-EG005W-30214NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts, visit our Worldwide Web Site

www.linksys.com
