Linksys USB2HUB4 - ProConnect USB Hub Manuale utente

USB 4-Port Hub

USB 2.0

Connect up to four USB 2.0 or 1.1 devices to a sin-

gle USB port!When the USB 4-Port Hub connects

USB 2.0 devices to a USB 2.0 port, you get data

rates up to 480Mbps—perfect for graphics, multime-

dia, or gaming applications.

The Plug-and-Play USB 4-Port Hub is fully backward

compatible with earlier USB devices. It is also hot-

swappable, so you can connect or disconnect USB

devices on the fly. The Hub supports all USB devices,

including digital cameras, scanners, game controllers,

keyboards,portable data storage,mice,modems,print-

ers, and more.

Toaddeven more USB peripherals,you can daisy-chain

the USB 4-Port Hub to additional Hubs, up to a maxi-

mum of 127 USB devices.

• Compatible with USB 2.0 and 1.1 Peripherals

• Data Transfer Rates of up to 480Mbps Using USB 2.0

Devices on USB 2.0-Equipped Computers

• Plug-and-Play—No Drivers Required

• Hot-Swappable Connectivity

• Connect up to 127 USB Devices by Daisy-Chaining

USB Hubs

• Free Technical Support—24 Hours a Day, 7 Days a

Week,Toll-Free US Calls

• 1-Year Limited Warranty

• Data Transfer Rate Up to 480Mbps When a USB

2.0 Device is Connected to a USB 2.0-Equipped

Computer

• Backward Compatible with USB 1.1 Devices

• Hot-Swappable—Add or Remove Devices with

the Computer On

• Use Four USB Devices Simultaneously from

Any USB-Ready PC

• Works with Any USB Device: Digital Cameras,

Scanners, Network Adapters, Portable Data

Storage, and More!

• Low-Cost and Easy Expansion for Desktop and

Notebook Computers

• Plug-and-Play Installation

USB 4-Port Hub

USB 2.0

Model Number: USB2HUB4

Connect Up to Four USB 2.0 or USB 1.1

Peripherals to Your Computer

Features

Benefits

IInnssttaannttUUSSBB22..00

CCoonnnneeccttiivviittyy——TThheeEEaassyy

WWaayyttooAAddddUUSSBBDDeevviicceess

ProConnect®Series

Package Contents

USB 4-Port Hub

USB 2.0

• One USB4-Port Hub USB 2.0

• One USB Cable

• One Power Adapter

• One User Guide and Registration Card

DS-USB2HUB4-061302NC JL

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Sales Information (800) 546-5797

World Wide Web* http://www.linksys.com

Japan (03) 5259-5137

Philippines (632) 638-5580

Singapore (65) 6555-8555

Thailand 717-0770

United Kingdom 0870 7393939

*Visit our website for the most current contact information.

Specifications

Model Number USB2HUB4

Standards OHCI, UHIC, USB 1.1 and 2.0

Ports One USB Type B Root Port

Four USB Type A Device Ports

Speed (Mbps) Up to 480 (High Speed)

Maximum Number 127 (when multiple hubs are daisy-chained

of Devices together)

Cabling Shielded USB 2.0 Cable

LEDs Power

Activity

Current 500 mA (Maximum) per Device Port

Environmental

Dimensions 3.15" x 2.3" x 1.05"

(80 mm x 58.36 mm x 26.6 mm)

Unit Weight 2.5 oz. (0.07 kg)

Power 5V DC, 2.4 A

Certifications FCC Class B, CE Mark,VCCI

Operating Temp. 32ºF to 158ºF (0ºC to 70ºC)

Storage Temp. -4ºF to 176ºF (-20ºC to 80ºC)

Operating Humidity 0% to 95%, Non-Condensing

Storage Humidity 0% to 95%, Non-Condensing

USB-Ready PC with the following:

• One Free USB Port

• Microsoft Windows 98, 2000, Millennium,

or XP

Minimum Requirements
