Linksys WAP55AG - Wireless A+G Access Point Manuale utente

Dual-Band Wireless

A + G Access Point

he Linksys Dual-Band Wireless A+G Access Point gives you

universal wireless connectivity. It's the best way to add wire-

less capability to your existing wired network, or to add

bandwidth to your wireless installation.

The Dual-Band Wireless A+G Access Point actually contains two

separate wireless connectivity radio transceivers, which support all

three popular wireless networking specifications. The first trans-

ceiver uses the 2.4GHz radio band, supporting both the widely-used

and inexpensive Wireless-B (802.11b) standard at 11Mbps, and the

new, almost five times faster, Wireless-G (draft 802.11g) at

54Mbps. The second radio operates in the 5GHz band, and sup-

ports Wireless-A (802.11a) networking, also at 54Mbps. Since the

two radios operate in different bands, they can work simultaneous-

ly, blanketing your wireless zone with high-speed bandwidth.

To protect your data and privacy, the A+G Access Point can encrypt

all wireless transmissions. The MAC Address filter lets you decide

exactly who has access to your wireless network while Dynamic

Frequency Selection (DFS) puts your network on the cleanest chan-

nel in your location. Configuration is a snap with the web brows-

er-based configuration utility.

With the Linksys Dual-Band Wireless A+G Access Point, you'll

have the best of all worlds -- Wireless-B for legacy compatibility,

and both Wireless-G and Wireless-A for high-speed access.

• Performance Investment Protection: Compatibility with

Wireless-A (802.11a), Wireless-B (802.11b) and Wireless-G

(draft 802.11g) Standards

• Ideal Wireless Solution for Enterprise customers

• MAC Address Filtering and up to 152-bit WEP Encryption

• Built in Web UI for easy configuration from any Web Browser

• Firmware upgradeable through Web-browser

• Quick Setup and Easy for Deployment

• Free Technical Support - 24 Hours a Day, 7 Days a Week, Toll-

Free U.S. Calls

•3-Year Limited Warranty

Dual-Band Wireless A + G Access Point

Model No.: WAP55AG

Add Universal Wireless Access (A, B, and G) to

your wired network!

Features

Benefits

• Dual-band, tri-standard Access Point commu-

nicates with Wireless-A (802.11a), Wireless-B

(802.11b), and Wireless-G (draft 802.11g)

wireless networks

• Protect your wireless investment while

preparing your infrastructure for the future

• Advanced features: SNMP manageability, and

Dynamic Frequency Selection (DFS)

• Powerful security: Up to 152-bit wireless data

encryption (WEP), and wireless MAC address

filter

Instant Wireless®Series

Package ContentsSpecifications

Model Number WAP55AG

Standards IEEE 802.11a, IEEE802.11b, draft IEEE

802.11g, 802.3, IEEE 802.u

Ports One 10/100 RJ-45 Port, One Power Port

Buttons One Reset Button

Cabling Type Ethernet Network Cable

LEDs Power, Diag

LAN: Link/Act, Full/Col, 100

802.11a: Act, Link

802.11g: Act, Link

Transmit Power 802.11a: Max. 16dBm

802.11g: typical 14dBm

802.11b: typical 16dBm

Security Features MAC address filtering, WEP Encryption

WEP Key Bits 64/128/152-Bit

Environmental

Dimensions 7.32" x 1.89" x 6.89"

(186 mm x 48 mm x 175 mm)

Unit Weight 14.11 oz. (0.4 kg)

Power External, 5V DC, 2.5A

Certifications FCC

Operating Temp. 32ºF to 104ºF (0ºC to 40ºC)

Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)

Operating Humidity 10% to 85%, Non-Condensing

Storage Humidity 5% to 90%, Non-Condensing

• Dual-Band Wireless Access Point

• Setup CD-ROM with User Guide

• Power Adapter

• Ethernet Network Cable

• Quick Installation Guide

• Registration Card

• One Pentium Class PC (200 MHz or Faster

Processor) with

• 64 MB RAM

• Internet Explorer 4.0 or Netscape

Navigator 4.7 or Higher for Web-based

Configuration

• CD-ROM Drive

• 802.11a, 802.11b, or draft 802.11g

Wireless Adapter with TCP/IP Protocol

Installed

Minimum Requirements

WAP55AG-DS-30204NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts, visit our Worldwide Web Site

www.linksys.com
