Logitech Ultimate Ears 6000 Manuale utente

Setup Guide

Ultimate Ears™ 6000

UE 6000 UE 6000

2 3

AAA

Setup Guide

Ultimate Ears™ 6000

2 4

Package contents

1. Headphones

2. Detachable audio cable with in-line

remote

3. Travel case

4. Sharing splitter

5. 2 AAA alkaline batteries

(pre-installed)

6. Documentation

Know your product

1. Adjustable headband

2. Memory foam cushions

3. Battery LED

4. On/O slider

5. Volume up

6. Media/calling controls

•One click:

Play/pause (audio)

Call answer/hang up (phone)

•Double click:

Next track (audio)

•Triple click:

Previous track (audio)

•One click, then click and hold:

Fast forward (audio)

•Two clicks, then click and hold:

Rewind (audio)

•Click and hold:

Activate/deactivate voice dial1

7. Volume down

8. Microphone

9. Battery door release (Press button

toopen battery door.)

10. Battery compartment

11. 3.5 mm input

1 Function varies by phone. Activates Siri® on iPhone® 4S.

UE 6000 UE 6000

4 5

Set up your product

1. Pull the tab to activate batteries.

2. Move the slider to “On.” The Battery

LED turns green to indicate Active Noise

Cancellation mode.

3. Connect the headphone to begin

listening to music.

Product features

Answering a call

• On your phone, the music fades and a

ring tone sounds.

• You can pick the call up on your phone

or press the center button.

• To hang up, press the center button.

Sharing your music

1. Remove the cap.

2. Plug in the sharing splitter and connect.

Listen to music together.

Active Noise Cancellation

Battery LED

No light: headphone o

Green: Power on; batteries good

Red: Low power; change the batteries

If the power runs out, Active Noise

Cancellation ends. The headphones

continue to play music. Replace batteries

for optimal performance

Storage

The headphone folds easily for storage.

UE 6000 UE 6000

6 7

Visit Product Central

There’s more information and support

online for your product. Take a moment to

visit Product Central to learn more about

your new Ultimate Ears headphone.

Browse online articles for setup help,

usage tips, or information about additional

features.

Connect with other users in our Community

Forums to get advice, ask questions, and

share solutions.

At Product Central, you’ll ﬁnd a wide

selection of content:

• Tutorials

• Troubleshooting

• Support community

• Software downloads

• Online documentation

• Warranty information

• Spare parts (when available)

Go to www.logitech.com/support/ue6000

Troubleshooting

No sound or faint sound

• Check the cable connection. Make sure

the straight connector is connected

to the headphone and the angled

connector is connected to your device.

• Try increasing the volume for the

headphone and your media application.

• Restart your media application.

• If the Battery LED is red, replace the 2

AAA alkaline batteries.

Headphones not working with a computer

• Specify audio settings for your operating

system:

Windows® (Control Panel)

•Voice playback and recording:

Computer’s soundcard

•Sound playback: Computer’s speakers

Mac® OS X (Preferences)

•Sound input: Internal microphone

•Sound output: Internal speakers

Refer to your operating system

documentation. For more information,

go to www.logitech.com/support/

ue6000.

What do you think?

Please take a minute to tell us.

Thank you for purchasing our product.

www.logitech.com/ithink

www.logitech.com/support/ue6000

United States +1 646-454-3200

may be registered. Apple, Mac, and the Mac logo are trademarks of Apple Inc., registered in the U.S. and other countries.

Microsoft, Windows, and the Windows logo are trademarks of the Microsoft group of companies. All other trademarks are

the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual.

Information contained herein is subject to change without notice.

620-004307.002

www.logitech.com

POWER TO THE MUSIC
